Product Features
Technical Overview
This switch operates at Layer 2 of the OSI model, enabling advanced features like MAC address filtering, port mirroring, and link aggregation for improved network segmentation and monitoring. The 24 Gigabit Ethernet ports auto-negotiate speed and duplex settings, reducing configuration overhead and ensuring compatibility with a wide range of devices from computers and printers to IP cameras and access points.
The switch supports jumbo frames up to 9KB for efficient large data transfers, and its non-blocking architecture provides full wire-speed performance across all ports simultaneously. Energy-Efficient Ethernet (EEE) technology reduces power consumption during low data activity, making it a cost-effective choice for environmentally conscious deployments.
Relevant factors for this section include Total Number of Network Ports, Port/Expansion Slot Details, Media Type Supported, Ethernet Technology. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The DGS-1100-24V2 combines high port density with enterprise-grade management features at an accessible price point, making it ideal for growing networks that require scalability without complexity. Its robust construction and silent fanless design ensure reliable operation in noise-sensitive environments like offices or classrooms.
These strengths make the product easier to deploy and manage in real environments, especially where reliability, usability, and day-to-day operational continuity matter. Notable benefits include Enhanced Security, Quality of Service.
Enhanced Security
Supports 802.1X port-based authentication, MAC-based access control, and DHCP snooping to prevent unauthorized access and IP conflicts.
- Port Security
- Access Control Lists
- DoS Protection
Quality of Service
Prioritizes critical traffic like VoIP or video streaming using 802.1p/DSCP classification and four hardware queues per port.
- Traffic Prioritization
- Bandwidth Management
- Low Latency
Deployment / Use Cases
This switch is well-suited for branch offices, retail stores, or educational facilities where a centralized networking hub is needed to connect multiple devices reliably. Its rack-mountable design integrates seamlessly into standard 19-inch server cabinets, while the desktop option allows for standalone placement in network closets or under desks.
Common applications include supporting IP surveillance systems with multiple cameras, creating segmented networks for guest and staff Wi-Fi, or aggregating connections in a small server room. The manageable features enable IT teams to implement VLANs for department isolation, monitor traffic patterns for troubleshooting, and ensure high availability through link aggregation for critical servers.
Office Network Core
Connects workstations, printers, and VoIP phones with managed traffic control and security policies.
Retail POS Backbone
Links point-of-sale terminals, inventory scanners, and back-office servers with reliable Gigabit throughput.
Physical Profile
Measuring 11.02" wide, 7.09" deep, and 1.73" high (280 x 180 x 44 mm), the switch fits standard 1U rack spaces or sits stably on a desktop. The steel chassis provides durability, while the weight of 2.91 lb (1320 g) makes it easy to install or reposition. Ventilation slots ensure adequate airflow for continuous operation, and the front-panel LEDs offer at-a-glance status monitoring for power, link activity, and speed per port.
- Width
- 11.02" (280 mm)
- Depth
- 7.09" (180 mm)
- Height
- 1.73" (44 mm)
- Weight
- 2.91 lb (1320 g)
Highlights
- 24 Gigabit Ethernet ports for high-density connectivity
- Managed Layer 2 support with VLAN, QoS, and security features
- 10/100/1000Base-T auto-negotiating twisted pair compatibility
- 1U rack-mountable or desktop form factor for flexible deployment
- Built-in power supply for reliable operation
- Energy-Efficient Ethernet reduces power consumption
- Supports jumbo frames up to 9KB for efficient data transfers
- Fanless silent design ideal for office environments
- Front-panel LEDs for easy status monitoring
- Steel chassis ensures durability in rack or desktop use
Specifications
| Specifications | |
|---|---|
| Manufacturer | D-Link Systems, Inc |
| Manufacturer Part Number | DGS-1100-24V2 |
| Brand Name | D-Link |
| Product Series | DGS-1100 |
| Product Model | DGS-1100-24V2 |
| Product Name | DGS-1100-24V2 Ethernet Switch |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 24 |
| Port/Expansion Slot Details | 24 x Gigabit Ethernet Network |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T |
| Network & Communication | |
| Layer Supported | 2 |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| Power Source | Power Supply |
| Physical Characteristics | |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable,Desktop |
| Height | 1.73" (44 mm) |
| Width | 11.02" (280 mm) |
| Depth | 7.09" (180 mm) |
| Weight (Approximate) | 2.91 lb (1320 g) |
| Miscellaneous | |
| Country of Origin | China |
| TAA Compliant | No |
User Manual
FAQ
How many ports does the D-Link DGS-1100-24V2 switch have?
The D-Link DGS-1100-24V2 features 24 Gigabit Ethernet ports, all supporting 10/100/1000Base-T twisted pair connections. This provides ample connectivity for workstations, printers, IP cameras, and other network devices in small to medium business environments.
Is this switch manageable, and what Layer does it support?
Yes, the DGS-1100-24V2 is a fully manageable switch operating at Layer 2. It supports advanced features like VLAN configuration, Quality of Service (QoS), port security, and link aggregation, allowing network administrators to optimize traffic flow and enhance security.
Can this switch be rack-mounted or used on a desktop?
This switch offers dual form factor flexibility: it is designed for 1U rack mounting in standard 19-inch server cabinets and can also be placed on a desktop. Its compact dimensions of 11.02" x 7.09" x 1.73" and lightweight construction make installation straightforward in either setup.
What type of cables does the DGS-1100-24V2 support?
The switch supports twisted pair cables (Cat5e, Cat6, or higher) for 10/100/1000Base-T Ethernet connections. It auto-negotiates speed and duplex settings, and includes Auto MDI/MDIX to eliminate the need for crossover cables, simplifying cable management up to 100 meters per port.
Does this switch have Power over Ethernet (PoE) capability?
No, the DGS-1100-24V2 does not support Power over Ethernet. It requires a separate power supply for operation and is designed for connecting non-PoE devices like computers, printers, and servers. For PoE needs, consider D-Link's PoE-enabled switch models in the same series.
What are the key management features of this switch?
Key management features include VLAN support for network segmentation, QoS for traffic prioritization, port mirroring for monitoring, and security options like 802.1X authentication and MAC filtering. It also supports SNMP, web-based management, and CLI for flexible configuration tailored to business needs.
