Datalogic Codiscan Bluetooth Wearable Scanner - Wireless Connectivity - 43.30" (1099.82 mm) Scan Distance - 1D, 2D - LED - Bluetooth - (HS7600SR)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- Auto decodes all standard 1D codes including GS1 DataBar linear codes.
- PDF417, MicroPDF417, Data Matrix, QR Code, Micro QR Code, Aztec, MaxiCode
- US PostNet, US Planet, UK Postal, Australia Postal, Japan Postal, Dutch Postal (KIX)
Connectivity Technology: Wireless
Scanning Capability: 1D,2D
Barcode Symbology Supported:
1D / Linear Codes:
2D Codes:
Postal Codes:
Light Source: LED
Scan Mode: Trigger
Scanner Range: Standard Range
Scanning Distance: 43.30" (1099.82 mm)
Field of View (Horizontal): 42°
Field of View (Vertical): 32°
Reading Angle (Skew): 60°
Reading Angle (Pitch): 60°
Reading Angle (Roll): 180°
Maximum Ambient Light: 100000 lux
Drop Specification:
Resists multiple drops from 1.8 m / 5.9 ft onto concrete - IEC 60068-2-31:2008 - 1
Minimum Element Resolution (Code 39): 3 mil (0.08 mm)
Maximum Element Resolution (Code 39): 20 mil (0.51 mm)
Minimum Element Resolution (DataMatrix): 10 mil (0.25 mm)
Minimum Element Resolution (PDF417): 5 mil (0.13 mm)
Image Sensor Resolution: 1280 x 960
Features: Vibration,Beep,Ergonomic Design,Notification LED
Bluetooth: Yes
Battery Chemistry: Lithium Polymer (Li-Polymer)
Battery Capacity: 640 mAh
Maximum Battery Run Time: 16 Hour
Maximum Battery Recharge Time: 2.15 Hour
Operating Temperature: -4°F (-20°C) to 122°F (50°C)
Storage Temperature: -4°F (-20°C) to 140°F (60°C)
Form Factor: Wearable
Color Family: Dual Color
Product Color: Black,Green
Weight (Approximate): 1.55 oz (44 g)
Ingress Protection (IP) Rating: IP54
Application/Usage: Transportation,Logistics,Retail,Manufacturing,Warehouse,Picking,Sorting,Packing,Assembly Line,Inventory
Platform Supported: PC,Android
- Laser-free design provides high-performance scanning without the risk of eye injury
- Increases productivity by giving the opportunity to wander, without the tangle of cables
- Bluetooth technology - Allows compatibility with most of your smart devices
[custom-specifications]
| Specifications | |
| Manufacturer | Datalogic S.p.A |
| Manufacturer Part Number | HS7600SR |
| Manufacturer Website Address | http://www.datalogic.com |
| Brand Name | Datalogic |
| Product Line | CODiScan |
| Product Name | Codiscan Bluetooth Wearable Scanner |
| Product Type | Barcode Scanner |
| Technical Information | |
| Connectivity Technology | Wireless |
| Scanning Capability | 1D,2D |
| Barcode Symbology Supported | 1D / Linear Codes:
2D Codes:
Postal Codes:
|
| Light Source | LED |
| Scan Mode | Trigger |
| Scanner Range | Standard Range |
| Scanning Distance | 43.30" (1099.82 mm) |
| Field of View (Horizontal) | 42° |
| Field of View (Vertical) | 32° |
| Reading Angle (Skew) | 60° |
| Reading Angle (Pitch) | 60° |
| Reading Angle (Roll) | 180° |
| Maximum Ambient Light | 100000 lux |
| Drop Specification | Resists multiple drops from 1.8 m / 5.9 ft onto concrete - IEC 60068-2-31:2008 - 1 |
| Minimum Element Resolution (Code 39) | 3 mil (0.08 mm) |
| Maximum Element Resolution (Code 39) | 20 mil (0.51 mm) |
| Minimum Element Resolution (DataMatrix) | 10 mil (0.25 mm) |
| Minimum Element Resolution (PDF417) | 5 mil (0.13 mm) |
| Image Sensor Resolution | 1280 x 960 |
| Features | Vibration,Beep,Ergonomic Design,Notification LED |
| Network & Communication | |
| Bluetooth | Yes |
| Battery Information | |
| Battery Chemistry | Lithium Polymer (Li-Polymer) |
| Battery Capacity | 640 mAh |
| Maximum Battery Run Time | 16 Hour |
| Maximum Battery Recharge Time | 2.15 Hour |
| Environmental Conditions | |
| Operating Temperature | -4°F (-20°C) to 122°F (50°C) |
| Storage Temperature | -4°F (-20°C) to 140°F (60°C) |
| Physical Characteristics | |
| Form Factor | Wearable |
| Color Family | Dual Color |
| Product Color | Black,Green |
| Weight (Approximate) | 1.55 oz (44 g) |
| Miscellaneous | |
| Ingress Protection (IP) Rating | IP54 |
| Application/Usage | Transportation,Logistics,Retail,Manufacturing,Warehouse,Picking,Sorting,Packing,Assembly Line,Inventory |
| Platform Supported | PC,Android |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
Manufacturer-Brochure
[/custom-user-manual]
