Datalogic DSM04XX FIXED SCAN MODULE - Cable Connectivity - 23.60" (599.44 mm) Scan Distance - 1D, 2D - LED - Imager - USB - Black - - (DSM0422-WA)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- UPC/EAN/JAN
- P2 / P5 add-ons
- Code 39
- Italian Pharmacode 39
- Code 128
- C128 ISBT
- I 2 of 5
- Standard 2 of 5
- Interleaved 2 of 5
- Industrial 2of 5
- Datalogic 2of5
- IATA; Code 11
- Codabar
- ABC Codabar
- EAN 128
- Code 93
- MSI/Plessey
- RSS-14
- BC412
- Databar Limited
- Databar Omnidirectional
- Databar Expanded
- IATA
- Trioptic
- Matrix 2/5
- Telepen
- Composite codes CC-A
- CC-B
- CC-C
- Aztec Code
- China Han Xin Code
- Data Matrix
- MaxiCode
- Micro QR Code
- QR Code
- Australian Post
- British Post
- China Post
- IMB
- Japanese Post
- KIX Post
- Korea Post
- Planet Code
- Postnet
- Royal Mail Code (RM4SCC)
- EAN/JAN Composites
- GS1 DataBar Composites
- GS1 DataBar Expanded Stacked
- GS1 DataBar Stacked
- GS1 DataBar Stacked Omnidirectional
- MacroPDF
- MicroPDF417
- PDF417
- UPC A/E Composites
- Withstands repeated drops from 3 ft onto a concrete surface.
Connectivity Technology: Cable
Scanning Capability: 1D,2D
Barcode Symbology Supported:
1D:
All standard 1D codes including:
2D:
Postal Codes:
Stacked Codes:
Light Source: LED
Image Sensor Type: Imager
Scan Mode: Trigger/Sense
Scanning Distance: 23.60" (599.44 mm)
Field of View (Horizontal): 52°
Field of View (Vertical): 40°
Reading Angle (Skew): 60°
Reading Angle (Pitch): 60°
Reading Angle (Roll): 180°
Image Formats: BMP,JPEG
Maximum Ambient Light: 100000 lux
Drop Specification:
Minimum Print Contrast: 25%
Minimum Element Resolution (Code 39): 3 mil (0.08 mm)
Maximum Element Resolution (Code 39): 20 mil (0.51 mm)
Minimum Element Resolution (DataMatrix): 10 mil (0.25 mm)
Maximum Element Resolution (DataMatrix): 15 mil (0.38 mm)
Image Sensor Resolution: 1280 x 960
Illumination Type: LED
Illumination Color: White
Features: Beep,Notification LED,Grayscale Image Capture
Host Interface: USB
Operating Temperature: -4°F (-20°C) to 122°F (50°C)
Storage Temperature: -40°F (-40°C) to 158°F (70°C)
Humidity (Non-condensing): 5% to 95%
Form Factor: Fixed Mount
Rugged: Yes
Color Family: Black
Product Color: Black
Product Material: Resin
Durability: Water Resistant,Dust Resistant,Impact Resistant,Drop Resistant
Weight (Approximate): 4.62 oz (131 g)
Ingress Protection (IP) Rating: IP54
Application/Usage: Retail,Self-checkout,Ticketing,Manufacturing,Healthcare,Transportation,Logistics,Kiosk,Laboratory
Platform Supported: Android,Linux,PC,Windows,Smartphone
- Laser-free design provides high-performance scanning without the risk of eye injury
- Perfect for applications that require direct association with a workstation or a notebook
[custom-specifications]
| Specifications | |
| Manufacturer | Datalogic S.p.A |
| Manufacturer Part Number | DSM0422-WA |
| Manufacturer Website Address | http://www.datalogic.com |
| Brand Name | Datalogic |
| Product Model | DSM04XX |
| Product Name | DSM04XX FIXED SCAN MODULE |
| Product Type | Barcode Scanner |
| Technical Information | |
| Connectivity Technology | Cable |
| Scanning Capability | 1D,2D |
| Barcode Symbology Supported | 1D: All standard 1D codes including:
2D:
Postal Codes:
Stacked Codes:
|
| Light Source | LED |
| Image Sensor Type | Imager |
| Scan Mode | Trigger/Sense |
| Scanning Distance | 23.60" (599.44 mm) |
| Field of View (Horizontal) | 52° |
| Field of View (Vertical) | 40° |
| Reading Angle (Skew) | 60° |
| Reading Angle (Pitch) | 60° |
| Reading Angle (Roll) | 180° |
| Image Formats | BMP,JPEG |
| Maximum Ambient Light | 100000 lux |
| Drop Specification |
|
| Minimum Print Contrast | 25% |
| Minimum Element Resolution (Code 39) | 3 mil (0.08 mm) |
| Maximum Element Resolution (Code 39) | 20 mil (0.51 mm) |
| Minimum Element Resolution (DataMatrix) | 10 mil (0.25 mm) |
| Maximum Element Resolution (DataMatrix) | 15 mil (0.38 mm) |
| Image Sensor Resolution | 1280 x 960 |
| Illumination Type | LED |
| Illumination Color | White |
| Features | Beep,Notification LED,Grayscale Image Capture |
| Interfaces/Ports | |
| Host Interface | USB |
| Environmental Conditions | |
| Operating Temperature | -4°F (-20°C) to 122°F (50°C) |
| Storage Temperature | -40°F (-40°C) to 158°F (70°C) |
| Humidity (Non-condensing) | 5% to 95% |
| Physical Characteristics | |
| Form Factor | Fixed Mount |
| Rugged | Yes |
| Color Family | Black |
| Product Color | Black |
| Product Material | Resin |
| Durability | Water Resistant,Dust Resistant,Impact Resistant,Drop Resistant |
| Weight (Approximate) | 4.62 oz (131 g) |
| Miscellaneous | |
| Ingress Protection (IP) Rating | IP54 |
| Application/Usage | Retail,Self-checkout,Ticketing,Manufacturing,Healthcare,Transportation,Logistics,Kiosk,Laboratory |
| Platform Supported | Android,Linux,PC,Windows,Smartphone |
[/custom-specifications]
