Datalogic MAGELLAN 1500i Barcode Scanner - Cable Connectivity - 1D, 2D - LED - Imager - Area, Omni-directional - USB, Serial - Black, (MG1503-30250-0200)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- Autodiscriminates all standard 1D codes including GS1 DataBar linear codes
- Aztec Code, Data Matrix, MaxiCode, QR Code
- Australian Post; British Post; Canadian Post; China Post; IMB; Japanese Post; KIX Post; Planet Code; Portuguese Post; Postnet; Royal Mail Code (RM4SCC); Swedish Post
- GS1 DataBar Composites; GS1 DataBar Composites; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; Micro PDF417, PDF417
- Optional support for Digimarc® Barcodes/GS1 DW Code
Connectivity Technology: Cable
Scanning Capability: 1D,2D
Barcode Symbology Supported:
1D Codes:
2D Codes:
Postal Codes:
Stacked Codes:
Digital Watermarks:
Light Source: LED
Image Sensor Type: Imager
Scan Pattern: Area,Omni-directional
Cable Type Included: USB
Stand Included: Yes
Reading Angle (Skew): 75°
Reading Angle (Pitch): 65°
Reading Angle (Roll): 360°
Image Formats: BMP,JPEG
Maximum Ambient Light: 86100 lux
Drop Specification:
Withstands repeated drops from 1.2 m / 4.0 ft onto a concrete surface
Minimum Print Contrast: 25%
Minimum Element Resolution (DataMatrix): 13 mil (0.33 mm)
Maximum Element Resolution (DataMatrix): 24 mil (0.61 mm)
Illumination Type: LED
Air Electrostatic Discharge (+/-): 25kV
Features: Beep,Notification LED
Host Interface: USB,Serial
Operating Temperature: 32°F (0°C) to 104°F (40°C)
Storage Temperature: -40°F (-40°C) to 158°F (70°C)
Humidity (Non-condensing): 5% to 95%
Form Factor: Hands-free
Color Family: Dual Color
Product Color: Black,White
Ingress Protection (IP) Rating: IP52
Application/Usage: Retail,Commercial Service,Healthcare
- Laser-free design provides high-performance scanning without the risk of eye injury
- Perfect for applications that require direct association with a workstation or a notebook
[custom-specifications]
| Specifications | |
| Manufacturer | Datalogic S.p.A |
| Manufacturer Part Number | MG1503-30250-0200 |
| Manufacturer Website Address | http://www.datalogic.com |
| Brand Name | Datalogic |
| Product Line | Magellan |
| Product Series | 1500i |
| Product Model | MG1503 |
| Product Name | MAGELLAN 1500i Barcode Scanner |
| Product Type | Barcode Scanner Kit |
| Technical Information | |
| Connectivity Technology | Cable |
| Scanning Capability | 1D,2D |
| Barcode Symbology Supported | 1D Codes:
2D Codes:
Postal Codes:
Stacked Codes:
Digital Watermarks:
|
| Light Source | LED |
| Image Sensor Type | Imager |
| Scan Pattern | Area,Omni-directional |
| Cable Type Included | USB |
| Stand Included | Yes |
| Reading Angle (Skew) | 75° |
| Reading Angle (Pitch) | 65° |
| Reading Angle (Roll) | 360° |
| Image Formats | BMP,JPEG |
| Maximum Ambient Light | 86100 lux |
| Drop Specification | Withstands repeated drops from 1.2 m / 4.0 ft onto a concrete surface |
| Minimum Print Contrast | 25% |
| Minimum Element Resolution (DataMatrix) | 13 mil (0.33 mm) |
| Maximum Element Resolution (DataMatrix) | 24 mil (0.61 mm) |
| Illumination Type | LED |
| Air Electrostatic Discharge (+/-) | 25kV |
| Features | Beep,Notification LED |
| Interfaces/Ports | |
| Host Interface | USB,Serial |
| Environmental Conditions | |
| Operating Temperature | 32°F (0°C) to 104°F (40°C) |
| Storage Temperature | -40°F (-40°C) to 158°F (70°C) |
| Humidity (Non-condensing) | 5% to 95% |
| Physical Characteristics | |
| Form Factor | Hands-free |
| Color Family | Dual Color |
| Product Color | Black,White |
| Miscellaneous | |
| Ingress Protection (IP) Rating | IP52 |
| Application/Usage | Retail,Commercial Service,Healthcare |
[/custom-specifications]
