Datalogic PM9501-DPM910RB PowerScan 9500 PM9501 Barcode Scanner Kit - Wireless 2D/1D Laser Imager - Area & Omni-directional Scanning - Rugged IP65
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The PowerScan 9500 PM9501 utilizes a laser light source and imager sensor to achieve high-speed scanning of both 1D and 2D barcodes. It autodiscriminates all standard 1D codes including GS1 DataBar linear codes, while supporting comprehensive 2D formats such as Data Matrix, QR Code, Aztec Code, PDF417, and multiple postal code standards. The scanner features a standard range with reading angles of 40° skew, 40° pitch, and 360° roll for versatile capture capability.
Technical specifications include a maximum ambient light tolerance of 100,000 lux, minimum print contrast of 15%, and support for BMP, TIFF, and JPEG image formats. The unit incorporates white LED illumination and provides audible beep feedback during operation. Power management is handled by a 3350 mAh Lithium Ion battery with a maximum recharge time of 4.5 hours, supporting extended shift operations.
Key Product Advantages
The PowerScan 9500 PM9501 delivers several distinct advantages for industrial barcode scanning applications. Its rugged construction meets IP65 standards for dust and water resistance, while the drop specification ensures durability in challenging environments. The scanner withstands 50 drops from 2.0 meters onto concrete surfaces, providing exceptional reliability for warehouse, manufacturing, and logistics operations.
Industrial Durability
Built to withstand harsh conditions with IP65 rating and military-grade drop resistance for reliable performance in demanding environments.
- IP65 dust and water resistance
- 50-drop durability from 2.0 meters
- Wide temperature operating range
Advanced Scanning Capability
Comprehensive barcode support with laser imaging technology for accurate reading across diverse symbologies and print qualities.
- 2D and 1D barcode support
- Area and omni-directional patterns
- 100,000 lux ambient light tolerance
Flexible Connectivity
Wireless operation with multiple interface options provides deployment flexibility across different host systems and environments.
- Wireless RF connectivity
- Multi-interface host support
- USB cable included
Deployment / Use Cases
The PowerScan 9500 PM9501 is ideally suited for applications requiring robust, mobile barcode scanning in challenging environments. Its wireless capability and durable design make it particularly valuable for operations where scanners are subject to frequent handling, drops, or exposure to dust and moisture.
Primary deployment scenarios include warehouse inventory management, where operators need to move freely while scanning pallets and shelves; manufacturing floor operations for tracking work-in-progress and components; logistics and distribution centers for parcel sorting and tracking; retail inventory management in backroom and receiving areas; and field service applications where technicians require reliable scanning equipment for asset tracking and maintenance records.
What's in the Box
The PowerScan 9500 PM9501 Barcode Scanner Kit includes all essential components for immediate deployment.
Package contents include USB. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Wireless 2D/1D barcode scanner with laser imaging technology
- Area and omni-directional scanning patterns for flexible capture
- Rugged IP65-rated construction for industrial environments
- Withstands 50 drops from 2.0 meters onto concrete surfaces
- Comprehensive barcode symbology support including Data Matrix and QR Code
- Multi-interface connectivity: Keyboard Wedge, Serial, USB, Ethernet
- 3350 mAh Lithium Ion battery with 4.5-hour recharge time
- Operating temperature range: -20°C to 50°C (-4°F to 122°F)
- Yellow and black color scheme for high visibility
- Includes USB cable and stand for flexible deployment
Specifications
| Specifications | |
|---|---|
| Manufacturer | Datalogic S.p.A |
| Manufacturer Part Number | PM9501-DPM910RB |
| Brand Name | Datalogic |
| Product Line | PowerScan |
| Product Series | 9500 |
| Product Model | PM9501 |
| Product Name | PowerScan 9500 PM9501 Barcode Scanner Kit |
| Product Type | Barcode Scanner Kit |
| Technical Information | |
| Connectivity Technology | Wireless |
| Scanning Capability | 2D,1D |
| Barcode Symbology Supported | 1D : Autodiscriminates all standard 1D codes including GS1 DataBar™ linear codes. 2D : Aztec Code; China Han Xin Code; Data Matrix; MaxiCode; Micro QR Code; QR Code Postal Codes Australian Post; China Post; IMB; Japanese Post; KIX Post; Planet Code; Portuguese Post; Postnet; Royal Mail Code (RM4SCC); Swedish Post; Stacked Codes EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; MacroPDF; MicroPDF417; PDF417; UPC A/E Composites |
| Light Source | Laser |
| Image Sensor Type | Imager |
| Scan Pattern | Area,Omni-directional |
| Scanner Range | Standard Range |
| Display Screen | Yes |
| Cable Type Included | USB |
| Stand Included | Yes |
| Reading Angle (Skew) | 40° |
| Reading Angle (Pitch) | 40° |
| Reading Angle (Roll) | 360° |
| Image Formats | BMP,TIFF,JPEG |
| Maximum Ambient Light | 100000 lux |
| Drop Specification | Cradle: Withstands 50 drops from 1.2 m / 3.9 ft onto a concrete surface PM9500: Withstands 50 drops from 2.0 m / 6.6 ft onto a concrete surface |
| Minimum Print Contrast | 15% |
| Illumination Type | LED |
| Illumination Color | White |
| Air Electrostatic Discharge (+/-) | 20kV |
| Features | Beep |
| Network & Communication | |
| Radio Frequency | Yes |
| Interfaces/Ports | |
| Host Interface | Multi-interface,Keyboard Wedge,Serial,USB,Ethernet |
| Power Description | |
| Input Current | 150 mA |
| Battery Information | |
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Battery Capacity | 3350 mAh |
| Maximum Battery Recharge Time | 4.50 Hour |
| Environmental Conditions | |
| Operating Temperature | -4°F (-20°C) to 122°F (50°C) |
| Storage Temperature | -40°F (-40°C) to 158°F (70°C) |
| Humidity (Non-condensing) | 95% |
| Physical Characteristics | |
| Form Factor | Handheld |
| Rugged | Yes |
| Color Family | Dual Color |
| Product Color | Yellow,Black |
| Miscellaneous | |
| Ingress Protection (IP) Rating | IP65 |
| Application/Usage | Ticketing,Manufacturing,Asset Tracking,Inventory,Warehouse,Logistics,Picking |
User Manual
FAQ
What types of barcodes can the PowerScan 9500 PM9501 read?
The scanner reads both 1D and 2D barcodes, including all standard 1D codes with GS1 DataBar support, and 2D formats such as Data Matrix, QR Code, Aztec Code, PDF417, MaxiCode, and multiple postal code standards. It autodiscriminates between symbologies without manual configuration.
How durable is this barcode scanner for industrial use?
The PowerScan 9500 PM9501 is built for industrial durability with an IP65 rating for dust and water resistance. It withstands 50 drops from 2.0 meters (6.6 feet) onto concrete surfaces and operates in temperatures from -20°C to 50°C, making it suitable for challenging warehouse and manufacturing environments.
What connectivity options does this wireless scanner support?
The scanner offers wireless RF connectivity for mobile operation, plus multiple wired interface options including Keyboard Wedge, Serial, USB, and Ethernet. The kit includes a USB cable for direct connection, providing flexibility for different deployment scenarios and host system requirements.
What is the battery life and recharge time for this scanner?
The scanner features a 3350 mAh Lithium Ion battery that supports extended operation between charges. The maximum recharge time is 4.5 hours, ensuring minimal downtime during shift changes or between uses in high-volume scanning environments.
Can this scanner read barcodes at different angles?
Yes, the PowerScan 9500 PM9501 supports area and omni-directional scanning patterns with reading angles of 40° skew, 40° pitch, and 360° roll. This allows operators to capture barcodes from various orientations without precise alignment, improving scanning efficiency in real-world applications.
What environmental conditions can this scanner operate in?
The scanner operates in temperatures from -4°F (-20°C) to 122°F (50°C) with 95% non-condensing humidity tolerance. It handles maximum ambient light of 100,000 lux and has air electrostatic discharge protection of ±20kV, making it suitable for diverse industrial and commercial environments.
What duplex or duty-cycle detail is listed?
the specifications are intended to help buyers confirm fit, compatibility, and expected day-to-day operation. In practical terms, the best reading of this product comes from how its hardware, connectivity, and deployment details work together.
What connectivity options are listed?
Connectivity details help confirm how the product integrates with your network, accessories, and surrounding peripherals before rollout or replacement planning. They are often the difference between a technically compatible device and one that is genuinely easy to deploy.
