Datalogic PD9630-DCK1 PowerScan Barcode Scanner Kit - Cable USB - 1D/2D Imager - 46. 9" Scan - IP67 Rugged Handheld
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The PD9630 scanner features advanced optical specifications including a 38° horizontal and 24° vertical field of view, with reading angles of 52° skew, 52° pitch, and 360° roll. This wide-angle coverage ensures consistent scanning performance regardless of barcode orientation or positioning.
Technical resilience is built into the design with a maximum ambient light tolerance of 100,000 lux and minimum print contrast requirement of 15%. The scanner maintains reliable operation in challenging lighting conditions while accommodating lower-quality printed codes.
This section brings together practical product details such as Connectivity Technology, Scanning Capability, Barcode Symbology Supported, Host Interface, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The PowerScan PD9630 combines industrial durability with versatile scanning capabilities, making it suitable for the most demanding data capture applications. Its rugged construction and environmental protection ratings ensure reliable operation in challenging conditions.
Comprehensive Symbology Support
Automatically discriminates all standard 1D codes including GS1 DataBar linear codes, plus extensive 2D support for Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code, and multiple postal code formats.
- Auto-discrimination of 1D codes
- Wide 2D code support
- Postal code compatibility
Industrial Durability
IP67 and IP65 ingress protection ratings provide dust and water resistance, while drop testing certification confirms the scanner withstands repeated impacts from operational heights.
- IP67/IP65 rated
- Drop-tested construction
- Ruggedized design
Deployment / Use Cases
The PD9630 scanner is engineered for industrial and commercial environments where reliable barcode scanning directly impacts operational efficiency. Its cable connectivity and workstation association make it ideal for fixed scanning positions with consistent USB host connections.
Manufacturing facilities benefit from the scanner's durability and long-range scanning for inventory tracking and quality control processes. Warehouse operations utilize the omni-directional scanning for picking, sorting, and logistics applications where speed and accuracy are critical.
This section brings together practical product details such as Connectivity Technology, Scanning Capability, Barcode Symbology Supported, Host Interface, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Industrial Applications
Manufacturing lines, asset tracking systems, and inventory management in environments requiring robust scanning equipment with consistent performance.
Logistics Operations
Warehouse picking, sorting stations, and distribution centers where quick scanning of varied barcode types improves throughput and reduces errors.
Physical Profile
The handheld scanner measures 7.50" in height, 3.10" in width, and 5.50" in length with a weight of approximately 11.22 ounces. The dual-color black and yellow design provides high visibility in industrial settings while maintaining a professional appearance. The ergonomic handheld form factor supports extended use during scanning-intensive operations.
- Width
- 3.10" (78.74 mm)
- Height
- 7.50" (190.50 mm)
- Weight
- 11.22 oz (318 g)
- Length
- 5.50" (139.70 mm)
What's in the Box
The PD9630-DCK1 kit includes the PowerScan PD9630 barcode scanner with integrated USB cable for immediate connectivity to host systems.
Package contents include USB. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Cable-connected USB barcode scanner with immediate plug-and-play setup
- 1D and 2D scanning capability with comprehensive symbology support
- 46.9-inch scanning distance for flexible positioning
- LED light source with imager sensor technology
- Omni-directional scanning with wide reading angles
- IP67 and IP65 ingress protection ratings
- Ruggedized construction withstands repeated drops
- Dual-color black and yellow handheld design
- USB host interface for direct workstation connection
- Suitable for manufacturing, warehouse, and industrial applications
Specifications
| Specifications | |
|---|---|
| Manufacturer | Datalogic S.p.A |
| Manufacturer Part Number | PD9630-DCK1 |
| Brand Name | Datalogic |
| Product Line | PowerScan |
| Product Series | 9600 |
| Product Model | PD9630 |
| Product Name | PowerScan PD9630 Barcode Scanner Kit |
| Product Type | Barcode Scanner Kit |
| Technical Information | |
| Connectivity Technology | Cable |
| Scanning Capability | 1D,2D |
| Barcode Symbology Supported | 1D: Auto discriminates all standard 1D codes including GS1 DataBar™ linear codes. 2D: Aztec Code China Han Xin Code Data Matrix MaxiCode Micro QR Code QR Code Dot code Postal Codes: Australian Post China Post IMB Japanese Post KIX Post Planet Code Portuguese Post Postnet Royal Mail Code (RM4SCC) Swedish Post Digital Watermarking: Digimarc Barcodes (PD9630-HP and PD9630-DC) |
| Light Source | LED |
| Image Sensor Type | Imager |
| Scan Pattern | Omni-directional |
| Scanning Distance | 46.90" (1191.26 mm) |
| Cable Type Included | USB |
| Field of View (Horizontal) | 38° |
| Field of View (Vertical) | 24° |
| Reading Angle (Skew) | 52° |
| Reading Angle (Pitch) | 52° |
| Reading Angle (Roll) | 360° |
| Maximum Ambient Light | 100000 lux |
| Drop Specification | Withstands 50 drops from 2.5 m / 8.2 ft @ 20 °C / 68 °F Withstands 50 drops from 2.0 m / 6.6 ft @ -20 °C / -4 °F |
| Minimum Print Contrast | 15% |
| Maximum Element Resolution (DataMatrix) | 10 mil (0.25 mm) |
| Interfaces/Ports | |
| Host Interface | USB |
| Physical Characteristics | |
| Form Factor | Handheld |
| Rugged | Yes |
| Color Family | Dual Color |
| Product Color | Black,Yellow |
| Height | 7.50" (190.50 mm) |
| Width | 3.10" (78.74 mm) |
| Length | 5.50" (139.70 mm) |
| Weight (Approximate) | 11.22 oz (318 g) |
| Miscellaneous | |
| Ingress Protection (IP) Rating | IP67,IP65 |
| Application/Usage | Manufacturing,Asset Tracking,Inventory,Warehouse,Logistics,Picking,Sorting,Industrial |
User Manual
FAQ
What types of barcodes can the PD9630 scanner read?
The PD9630 scanner reads both 1D and 2D barcodes. For 1D codes, it automatically discriminates all standard linear codes including GS1 DataBar. 2D support includes Aztec Code, China Han Xin Code, Data Matrix, MaxiCode, Micro QR Code, QR Code, Dot code, and multiple postal code formats from various countries including Australian Post, China Post, IMB, Japanese Post, and others.
What is the maximum scanning distance for this barcode scanner?
The PD9630 scanner has a maximum scanning distance of 46.90 inches (1191.26 mm). This long-range capability allows flexible positioning relative to barcodes, making it suitable for applications where the scanner needs to read codes from varying distances without requiring precise alignment.
How durable is the PD9630 scanner for industrial use?
The PD9630 is built for industrial durability with IP67 and IP65 ingress protection ratings, making it dust-tight and resistant to water immersion. It withstands 50 drops from 2.5 meters at room temperature and 50 drops from 2.0 meters at -20°C. The rugged construction ensures reliable operation in challenging environments like manufacturing floors and warehouses.
What connectivity options does this scanner support?
The PD9630-DCK1 kit features cable connectivity with a USB host interface. The included USB cable provides direct connection to workstations, computers, or other host systems. This wired setup ensures stable data transmission without wireless interference concerns, making it ideal for fixed scanning positions.
What are the physical dimensions and weight of the scanner?
The handheld scanner measures 7.50 inches in height, 3.10 inches in width, and 5.50 inches in length. It weighs approximately 11.22 ounces (318 grams). The compact, ergonomic design supports comfortable extended use during scanning-intensive operations while maintaining a manageable size for handheld applications.
What applications is this barcode scanner best suited for?
The PD9630 scanner is designed for industrial and commercial applications including manufacturing, asset tracking, inventory management, warehouse operations, logistics, picking, sorting, and other scanning-intensive environments. Its durability, long scanning distance, and comprehensive symbology support make it particularly effective in settings requiring reliable performance under demanding conditions.
What duplex or duty-cycle detail is listed?
the specifications are intended to help buyers confirm fit, compatibility, and expected day-to-day operation. In practical terms, the best reading of this product comes from how its hardware, connectivity, and deployment details work together.
What connectivity options are listed?
Connectivity details help confirm how the product integrates with your network, accessories, and surrounding peripherals before rollout or replacement planning. They are often the difference between a technically compatible device and one that is genuinely easy to deploy.
