Datalogic QuickScan QD-2500 Barcode Scanner Kit - Cable Connectivity - 20.10" (510.54 mm) Scan Distance - 1D, 2D - LED - Imager - , - (QD2590-WHK1)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- Auto discriminates all standard 1D codes including GS1 DataBar linear codes.
- Aztec Code; China Han Xin Code; Data Matrix; MaxiCode; Micro QR Code; QR Code; Dot code
- Australian Post; British Post; China Post; IMB; Japanese Post; KIX Post; Planet Code; Postnet; Royal Mail Code (RM4SCC)
- EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; MacroPDF; MicroPDF417; PDF417; UPC A/E Composites.
- Digimarc Barcodes (QD2500, QM2500, QBT2500 only)
- Withstands repeated drops from 1.5 m / 5.0 ft onto a concrete surface
Connectivity Technology: Cable
Scanning Capability: 1D,2D
Barcode Symbology Supported:
1D:
2D:
Postal Codes:
Stacked Codes:
Digital Watermarking:
Light Source: LED
Image Sensor Type: Imager
Scanning Distance: 20.10" (510.54 mm)
Cable Type Included: USB
Reading Angle (Skew): 65°
Reading Angle (Pitch): 65°
Reading Angle (Roll): 360°
Motion Tolerance: 30 in/s (762 mm/s)
Image Formats: BMP,JPEG,TIFF
Maximum Ambient Light: 110000 lux
Drop Specification:
Minimum Print Contrast: 15%
Minimum Element Resolution (Code 39): 5 mil (0.13 mm)
Maximum Element Resolution (Code 39): 10 mil (0.25 mm)
Minimum Element Resolution (DataMatrix): 10 mil (0.25 mm)
Minimum Element Resolution (PDF417): 6.70 mil (0.17 mm)
Image Sensor Resolution: 1280 x 800
Illumination Type: LED
Illumination Color: Red
Air Electrostatic Discharge (+/-): 16kV
Features: Beep,Notification LED,Grayscale Image Capture
Radio Frequency: Yes
Host Interface: USB,Serial,Keyboard Wedge,Multi-interface
Battery Chemistry: Lithium Ion (Li-Ion)
Battery Capacity: 3250 mAh
Maximum Battery Recharge Time: 4 Hour
Operating Temperature: 32°F (0°C) to 122°F (50°C)
Storage Temperature: -40°F (-40°C) to 158°F (70°C)
Humidity (Non-condensing): 0% to 95%
Form Factor: Handheld
Color Family: White
Product Color: White
Durability: Water Resistant,Dust Resistant
Height: 4.96" (126 mm)
Width: 5.83" (148 mm)
Depth: 2.68" (68 mm)
Weight (Approximate): 5.11 oz (145 g)
Ingress Protection (IP) Rating: IP52
Application/Usage: Retail,Self-checkout,Commercial Service,Hospitality,Ticketing,Transportation,Government,Healthcare,Pharmacy,Manufacturing,Light/Clean Manufacturing
- LED aimer is a perfect choice for patient-facing applications
- Perfect for applications that require direct association with a workstation or a notebook
[custom-specifications]
| Specifications | |
| Manufacturer | Datalogic S.p.A |
| Manufacturer Part Number | QD2590-WHK1 |
| Manufacturer Website Address | http://www.datalogic.com |
| Brand Name | Datalogic |
| Product Line | QuickScan |
| Product Series | 2500 |
| Product Model | QD-2500 |
| Product Name | QuickScan QD-2500 Barcode Scanner Kit |
| Product Type | Barcode Scanner Kit |
| Technical Information | |
| Connectivity Technology | Cable |
| Scanning Capability | 1D,2D |
| Barcode Symbology Supported | 1D:
2D:
Postal Codes:
Stacked Codes:
Digital Watermarking:
|
| Light Source | LED |
| Image Sensor Type | Imager |
| Scanning Distance | 20.10" (510.54 mm) |
| Cable Type Included | USB |
| Reading Angle (Skew) | 65° |
| Reading Angle (Pitch) | 65° |
| Reading Angle (Roll) | 360° |
| Motion Tolerance | 30 in/s (762 mm/s) |
| Image Formats | BMP,JPEG,TIFF |
| Maximum Ambient Light | 110000 lux |
| Drop Specification |
|
| Minimum Print Contrast | 15% |
| Minimum Element Resolution (Code 39) | 5 mil (0.13 mm) |
| Maximum Element Resolution (Code 39) | 10 mil (0.25 mm) |
| Minimum Element Resolution (DataMatrix) | 10 mil (0.25 mm) |
| Minimum Element Resolution (PDF417) | 6.70 mil (0.17 mm) |
| Image Sensor Resolution | 1280 x 800 |
| Illumination Type | LED |
| Illumination Color | Red |
| Air Electrostatic Discharge (+/-) | 16kV |
| Features | Beep,Notification LED,Grayscale Image Capture |
| Network & Communication | |
| Radio Frequency | Yes |
| Interfaces/Ports | |
| Host Interface | USB,Serial,Keyboard Wedge,Multi-interface |
| Battery Information | |
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Battery Capacity | 3250 mAh |
| Maximum Battery Recharge Time | 4 Hour |
| Environmental Conditions | |
| Operating Temperature | 32°F (0°C) to 122°F (50°C) |
| Storage Temperature | -40°F (-40°C) to 158°F (70°C) |
| Humidity (Non-condensing) | 0% to 95% |
| Physical Characteristics | |
| Form Factor | Handheld |
| Color Family | White |
| Product Color | White |
| Durability | Water Resistant,Dust Resistant |
| Height | 4.96" (126 mm) |
| Width | 5.83" (148 mm) |
| Depth | 2.68" (68 mm) |
| Weight (Approximate) | 5.11 oz (145 g) |
| Miscellaneous | |
| Ingress Protection (IP) Rating | IP52 |
| Application/Usage | Retail,Self-checkout,Commercial Service,Hospitality,Ticketing,Transportation,Government,Healthcare,Pharmacy,Manufacturing,Light/Clean Manufacturing |
[/custom-specifications]
[custom-options]
| Product | Datalogic Stand, Autosense Flex, White - White |
| SKU | STD-AUTFLX-QD25-WH |
| Sale Price | $26.95 |
| Product | Datalogic Stand, Autosense Flex, Black - Black |
| SKU | STD-AUTFLX-QD25-BK |
| Sale Price | $26.95 |
| Product | Datalogic Handheld Scanner Holder - Black |
| SKU | STD-QW25-BK |
| Sale Price | $15.95 |
| Product | Datalogic Handheld Scanner Holder - White |
| SKU | HLD-Q040-WH |
| Sale Price | $15.95 |
| Product | Datalogic Handheld Scanner Holder - Black |
| SKU | HLD-Q040-BK |
| Sale Price | $20.95 |
[/custom-options]
[custom-user-manual]
Available Documentation:
Manufacturer-Brochure
Additional-pdf1
[/custom-user-manual]
| Qty | Price | Available |
|---|
