Digi EX50-WXS6-GLB Wi-Fi 6 Dual-Band Wireless Router - 5G/LTE Advanced Pro Cellular - 2.5GbE - PoE - 2 SIM - 320 MB/s
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The EX50 is built on a quad-core Cortex A53 processor running at 1.80 GHz, paired with 512 MB of RAM and 512 MB of flash memory for efficient handling of network traffic and VPN sessions. It supports the IEEE 802.11 a/b/g/n/ac/ax wireless standard, operating on both 2.4 GHz (ISM band) and 5 GHz (UNII band) frequencies to optimize coverage and reduce interference in crowded wireless environments.
Cellular connectivity includes LTE Advanced Pro and HSPA+ fallback, ensuring reliable mobile data access. The router's total wireless transmission speed reaches 320 MB/s, facilitating smooth data transfer for applications like video streaming, VoIP, and cloud services. VPN support is included for secure remote access, and the 2.5GbE port provides high-speed wired backbone connectivity.
Relevant factors for this section include Wi-Fi Generation, Network Band, Processor Type, Broadband Transmission Technology. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The EX50 combines advanced wireless and cellular technologies into a single, compact device, reducing the need for multiple hardware components in remote or mobile deployments. Its PoE capability eliminates separate power supplies for connected devices, lowering installation costs and enhancing reliability in power-constrained settings.
Dual-SIM Redundancy
Supports two Mini SIM cards for automatic failover between cellular carriers, ensuring uninterrupted connectivity even if one network experiences issues.
- Multi-carrier support
- Automatic switchover
- Mini SIM format
High-Speed Backhaul
Features a 2.5 Gigabit Ethernet port for connecting to high-speed internet sources or local network equipment, maximizing throughput for bandwidth-intensive tasks.
- 2.5GbE throughput
- Wired backbone support
- Future-proof connectivity
Compact Design
With dimensions of 6.22" x 6.22" x 1.38" and a weight of 1.32 lb, the router is easy to mount in tight spaces or integrate into existing network infrastructure.
- Square footprint
- Wall-mountable
- Lightweight construction
Deployment / Use Cases
The Digi EX50 is ideal for temporary sites, mobile command centers, retail pop-ups, and industrial IoT applications where reliable internet access is critical but traditional infrastructure is lacking. Its cellular and Wi-Fi capabilities make it a go-to solution for emergency response teams, construction sites, and transportation vehicles that require constant connectivity on the move.
In fixed locations, the router serves as a primary or backup internet source for small offices, branch locations, or smart buildings, leveraging PoE to power security cameras, access points, or sensors without additional electrical wiring. The VPN support enables secure connections to corporate networks, making it suitable for remote workers or distributed enterprises needing encrypted data transmission.
Physical Profile
The EX50 features a durable, compact enclosure measuring 6.22 inches in width and depth, with a height of 1.38 inches, allowing for discreet placement on desktops or wall mounting. Its approximate weight of 1.32 lb makes it portable for field use, while the square design ensures stability in various orientations. The router's finish is designed for professional environments, with ventilation to maintain optimal operating temperatures during continuous use.
- Width
- 6.22" (158 mm)
- Depth
- 6.22" (158 mm)
- Height
- 1.38" (35 mm)
- Weight
- 1.32 lb (600 g)
Highlights
- Wi-Fi 6 dual-band wireless router with IEEE 802.11 a/b/g/n/ac/ax support
- 5G and LTE Advanced Pro cellular connectivity for robust mobile internet access
- Dual Mini SIM card slots with multi-carrier support for network redundancy
- 2.5 Gigabit Ethernet port with PoE capability to power connected devices
- Quad-core Cortex A53 processor and 512 MB RAM for efficient network handling
- Total wireless transmission speed of 320 MB/s for high-throughput applications
- VPN support for secure remote access and encrypted data transmission
- Compact, square design (6.22" x 6.22" x 1.38") suitable for wall or cabinet mounting
- Flash memory capacity of 512 MB for firmware and configuration storage
- 3-year limited warranty for reliable long-term operation
Specifications
| Specifications | |
|---|---|
| Manufacturer | Digi International |
| Manufacturer Part Number | EX50-WXS6-GLB |
| Brand Name | Digi |
| Product Model | EX50 |
| Product Name | EX50 Wireless Router |
| Product Type | Wireless Router |
| Technical Information | |
| Wi-Fi Generation | Wi-Fi 6 |
| Network Band | Dual Band |
| Processor Type | Cortex A53 |
| Processor Core | Quad-core (4 Core) |
| Processor Speed | 1.80 GHz |
| Standard Memory | 512 MB |
| Wireless Specifications | |
| Broadband Transmission Technology | Cellular,Ethernet |
| Wireless LAN Standard | IEEE 802.11 a/b/g/n/ac/ax |
| ISM Band | Yes |
| UNII Band | Yes |
| ISM Maximum Frequency | 2.40 GHz |
| UNII Maximum Frequency | 5 GHz |
| Cellular Generation | 5G |
| Cellular Data Connectivity Technology | LTE Advanced Pro,HSPA+ |
| Total Wireless Transmission Speed | 320 MB/s |
| Interfaces/Ports | |
| Number of Network (RJ-45) Ports | 1 |
| PoE (RJ-45) Port | Yes |
| Number of Broadband (RJ-45) Ports | 1 |
| Network & Communication | |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| VPN Supported | Yes |
| Multi-SIM Supported | Yes |
| Number of SIM Card Supported | 2 |
| SIM Size Supported | Mini |
| Storage | |
| Flash Memory Capacity | 512 MB |
| Physical Characteristics | |
| Height | 1.38" (35 mm) |
| Width | 6.22" (158 mm) |
| Depth | 6.22" (158 mm) |
| Weight (Approximate) | 1.32 lb (600 g) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What Wi-Fi standards does the Digi EX50 support?
The Digi EX50 supports the IEEE 802.11 a/b/g/n/ac/ax wireless standards, commonly known as Wi-Fi 6. This includes dual-band operation on both 2.4 GHz (ISM band) and 5 GHz (UNII band) frequencies, providing backward compatibility with older devices while offering improved speed, capacity, and efficiency for modern networks.
Does this router support Power over Ethernet (PoE)?
Yes, the EX50 includes a PoE-capable RJ-45 port. This allows the router to deliver both data and electrical power over a single Ethernet cable to compatible devices such as IP cameras, wireless access points, or VoIP phones, simplifying installation and reducing the need for separate power adapters in networked setups.
How many SIM cards can the EX50 accommodate?
The router supports two Mini SIM cards simultaneously. This dual-SIM capability enables multi-carrier redundancy, allowing the device to automatically switch between cellular networks if one experiences downtime or poor signal, ensuring continuous internet connectivity in critical applications.
What cellular technologies are compatible with this router?
The EX50 is compatible with 5G and LTE Advanced Pro cellular networks, with fallback support for HSPA+. This range of technologies ensures high-speed mobile data access in areas with 5G coverage, while maintaining connectivity on older networks where 5G is not available, making it versatile for various geographic locations.
What is the wired Ethernet speed of the EX50?
The router features a 2.5 Gigabit Ethernet port, providing wired connectivity at speeds up to 2.5 Gbps. This high-speed port is suitable for connecting to fast internet sources, network switches, or other equipment, supporting bandwidth-intensive tasks like video streaming, large file transfers, and multiple concurrent users.
Is the Digi EX50 suitable for outdoor or industrial use?
While the EX50 is designed for robust performance, its specifications indicate a compact, indoor-friendly form factor without explicit outdoor ratings. It is well-suited for industrial IoT, mobile deployments, and indoor environments like offices or vehicles, where its cellular and Wi-Fi capabilities provide reliable connectivity in challenging or remote settings.
