Eaton 9PX8KSP 9PX 8000VA/7. 2kW Dual Conversion Online UPS - 6U Rack/Tower - 127/240V AC - Hardwired & NEMA Outlets
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This Eaton 9PX UPS employs true double conversion technology, continuously converting incoming AC power to DC and back to clean, regulated AC output. This ensures complete isolation from input power anomalies and provides zero transfer time to battery during outages. The unit supports both 127V and 240V AC input and output voltages, accommodating diverse electrical configurations.
Connectivity includes a built-in Gigabit network card (NETWORK-M2) for remote management via web, SNMP, or Telnet, plus USB and serial ports for local monitoring. The interactive LCD interface displays real-time load, battery status, and system events. Battery modules are hot-swappable and maintenance-free, utilizing sealed lead-acid chemistry with Eaton's exclusive ABM technology to extend battery life by up to 50%.
Power Conditioning
Provides full isolation from power disturbances including sags, surges, harmonics, and frequency variations, ensuring clean power to connected equipment.
- Zero transfer time to battery
- Pure sine wave output
- Input power factor correction
Key Product Advantages
The Eaton 9PX series combines industrial-grade power protection with advanced management features for critical infrastructure. Its dual conversion topology guarantees the highest level of power quality, while flexible mounting and comprehensive connectivity simplify integration into existing environments.
Extended Runtime & Scalability
Supports optional external battery modules (EBMs) to increase runtime for prolonged outages, allowing equipment to remain operational during extended power events.
- Hot-swappable battery design
- Modular expansion capability
- ABM technology for battery longevity
Advanced Monitoring & Control
The included Intelligent Power Software Suite and network management card enable remote monitoring, automated shutdowns, and energy usage reporting across distributed systems.
- Web/SNMP/Telnet management
- Real-time LCD display
- Graceful shutdown scripting
Deployment / Use Cases
The Eaton 9PX 8000VA UPS is engineered for environments where power continuity is non-negotiable. Its high capacity and dual conversion design make it ideal for protecting server racks, network closets, industrial control systems, and telecommunications infrastructure from power disruptions that can cause data loss, hardware damage, or operational downtime.
In data centers, it safeguards virtualization hosts, storage arrays, and core switches. For industrial applications, it provides clean power to PLCs, HMIs, and monitoring systems. The rack/tower convertible form factor allows installation in standard 19-inch racks or as a standalone tower, supported by included 4-post rail kits and tower pedestals.
Data Center & Server Room
Protects high-density server racks, blade enclosures, and network gear with pure sine wave output and scalable runtime options.
- 6U rack-mount design
- Supports 127V/240V input
- Network management for remote sites
Industrial & Manufacturing
Ensures uninterrupted operation of control systems, sensors, and communication equipment in harsh electrical environments.
- Wide input voltage range
- Hardwired and NEMA outlets
- High-temperature operation to 40°C
Physical Profile
This UPS features a sturdy steel chassis with a black and silver finish, designed for durability in rack or tower configurations. Dimensions are 10.30" (H) x 17.30" (W) x 27.60" (D), occupying 6U of rack space. The unit weighs 225 pounds, requiring proper handling and support. Front-panel indicators include four LEDs for status at a glance, and the interactive LCD provides detailed system information.
- Width
- 17.30" (439.42 mm)
- Depth
- 27.60" (701.04 mm)
- Height
- 10.30" (261.62 mm)
- Weight
- 225 lb (102058.28 g)
What's in the Box
The package includes all necessary components for immediate deployment in rack or tower mode.
Highlights
- 8000VA/7200W dual conversion online UPS for maximum power protection
- 6U rack/tower convertible design with included rail kit and pedestals
- 127V and 240V AC input/output voltage support
- Hardwired and NEMA L6-30R/L14-30R receptacle options
- Hot-swappable, maintenance-free sealed lead-acid batteries
- Built-in Gigabit network card for remote management
- Interactive LCD display with real-time status monitoring
- Intelligent Power Software Suite for monitoring and shutdowns
- Energy Star certified and RoHS compliant
- 3-year limited warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | 9PX8KSP |
| Brand Name | Eaton |
| Product Model | 9PX |
| Product Name | 9PX 8000VA Tower/Rack Mountable Dual Conversation Online UPS |
| Product Type | Double Conversion Online UPS |
| Technical Information | |
| Plug/Connector Type | Hardwired |
| Receptacle Type | NEMA L6-30R,NEMA L14-30R,Hardwired |
| Receptacle Detail | 1 x NEMA L6-30R,2 x NEMA L14-30R |
| Power Description | |
| Load Capacity (VA) | 8 kVA |
| Load Capacity (Watt) | 7.20 kW |
| Input Voltage | 127 V AC,240 V AC |
| Output Voltage | 127 V AC,240 V AC |
| Circuit Breaker | Yes |
| Controls/Indicators | |
| Status Indicators | 4 x LEDs |
| Interfaces/Ports | |
| Serial Port | Yes |
| USB | Yes |
| Network (RJ-45) | Yes |
| Battery Information | |
| Battery Characteristics | Maintenance-free, Sealed |
| Battery Chemistry | Lead Acid |
| Hot Swappable | Yes |
| Environmental Conditions | |
| Maximum Operating Temperature | 104°F (40°C) |
| Physical Characteristics | |
| Product Color | Black,Silver |
| Height | 10.30" (261.62 mm) |
| Width | 17.30" (439.42 mm) |
| Depth | 27.60" (701.04 mm) |
| Rack Height | 6U |
| Form Factor | Rack/Tower |
| Weight (Approximate) | 225 lb (102058.28 g) |
| Miscellaneous | |
| Package Contents | 9PX 8000VA Tower/Rack Mountable Dual Conversation Online UPS 4-post Rail Kit Tower Pedastals RS-232 Cable USB Cable Intelligent Power Software Suite CD |
| Software Included | Intelligent Power Software Suite |
| Energy Star | Yes |
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What is the power capacity of this Eaton UPS?
This Eaton 9PX UPS has a load capacity of 8000 VA (8 kVA) and 7200 watts. It is designed to support high-density IT equipment, servers, and industrial systems requiring clean, uninterrupted power.
Can this UPS be mounted in a standard server rack?
Yes, this UPS is designed for both rack and tower deployment. It occupies 6U of rack space and includes a 4-post rail kit for secure mounting in standard 19-inch server racks. Tower pedestals are also included for standalone use.
What input and output voltages does this UPS support?
The UPS supports both 127V AC and 240V AC input and output voltages. This flexibility allows it to integrate into various electrical environments without requiring external transformers or reconfiguration.
What types of outlets or connections are provided?
Connection options include hardwired terminals plus NEMA L6-30R and L14-30R receptacles. Specifically, there is one NEMA L6-30R outlet and two NEMA L14-30R outlets, accommodating different plug types for distributed loads.
How is the battery designed, and is it replaceable?
The UPS uses maintenance-free, sealed lead-acid batteries that are hot-swappable. This allows battery modules to be replaced without shutting down connected equipment. Eaton's ABM technology with 3-stage charging helps extend battery life by up to 50%.
What management and monitoring features are included?
Management features include a built-in NETWORK-M2 Gigabit network card for remote access via web, SNMP, or Telnet; USB and serial ports for local connections; and an interactive LCD interface for real-time status. The Intelligent Power Software Suite enables graceful shutdowns, event logging, and energy reporting.
What power capacity is listed for this UPS?
The listed power specification is 8 kVA, which helps position the unit for the right load level and installation role.
What voltage details are listed?
The listed power specification is 127 V AC,240 V AC, which helps position the unit for the right load level and installation role.
