Eaton 9PX11KMG2 9PX G2 11000VA/11kW Rack/Tower UPS - 4U Form Factor - 230V AC Input - 200-240V AC Output - 3 Hour Recharge
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This UPS operates on a single-phase 230V AC input and delivers a regulated output across a wide range of 200V to 240V AC, accommodating various regional voltage standards. The double conversion online topology ensures zero transfer time during power events, offering complete isolation from grid disturbances including surges, blackouts, brownouts, and line noise.
The integrated EMI/RFI noise filter further cleans incoming power, protecting connected equipment from electrical interference. An LCD display provides real-time status monitoring, while LED indicators offer at-a-glance system health checks.
This section brings together practical product details such as Plug/Connector Type, Receptacle Type, Receptacle Detail, Load Capacity (VA), so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The 9PX G2 series combines high power density with operational flexibility, featuring hot-swappable batteries that can be replaced without system downtime. This maintainability extends the UPS's service life and reduces total cost of ownership in 24/7 environments.
Comprehensive Connectivity
Multiple management interfaces including serial, USB, and EPO ports enable integration with building management systems and remote monitoring solutions. The included network card slot supports advanced monitoring and control capabilities.
- Serial Port
- USB Port
- EPO Port
- Network Card Slot
Intelligent Protection
Built-in alarms notify users of power failures, low battery conditions, overloads, UPS faults, and battery faults. Remote shutdown capabilities allow for orderly system power-down during extended outages.
- Power Failure Alarm
- Low Battery Alert
- Overload Protection
- Remote Shutdown
Deployment / Use Cases
This 11000VA UPS is engineered for environments where power continuity directly impacts operational integrity and revenue. Its substantial capacity and robust protection make it ideal for protecting server racks, network switches, POS systems, and other critical IT infrastructure.
The rack/tower dual format allows deployment in both dedicated data centers with standardized racks and smaller IT closets where tower placement may be preferred. Edge computing locations, retail operations with multiple POS terminals, and healthcare facilities with sensitive medical equipment all benefit from the clean power and runtime this unit provides.
Data Center & Server Room
Protect entire server racks with 11 kVA capacity, ensuring business continuity during power disturbances. The 4U form factor integrates seamlessly with standard data center infrastructure.
Network Infrastructure
Safeguard switches, routers, and communication equipment with pure sine wave output that prevents damage to sensitive electronics. The wide output voltage range accommodates various power distribution setups.
Physical Profile
The UPS measures 6.80" in height, 17.30" in width, and 32.60" in depth, with a substantial weight of 188.70 pounds reflecting its robust construction and battery capacity. The 4U rack height allows installation in standard server racks alongside other equipment, while included tower stands provide flexibility for standalone deployment where rack space is limited.
- Width
- 17.30" (439.42 mm)
- Depth
- 32.60" (828.04 mm)
- Height
- 4U
- Weight
- 188.70 lb (85592.88 g)
What's in the Box
The package includes everything needed for immediate deployment in either rack or tower configuration.
Highlights
- 11000VA/11kW double conversion online UPS with pure sine wave output
- Rack/tower convertible design with 4U rack height compatibility
- 230V AC input with 200-240V AC output range for versatile deployment
- 3-hour typical battery recharge time for rapid recovery
- Hot-swappable, valve-regulated lead acid batteries for maintainability
- Network management capable with included NETWORK-M3 gigabit card
- Hardwired connection with 4 x NEMA L6-30R receptacles
- Comprehensive protection against surges, blackouts, brownouts, and line noise
- LCD display with LED status indicators for real-time monitoring
- 3-year limited warranty with Energy Star certification and RoHS compliance
Specifications
| Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | 9PX11KMG2 |
| Brand Name | Eaton |
| Product Series | 9PX G2 |
| Product Model | 9PX11KMG2 |
| Product Name | 9PX G2 9PX11KMG2 11000VA Rack/Tower UPS |
| Product Type | Double Conversion Online UPS |
| Technical Information | |
| Plug/Connector Type | Hardwired |
| Receptacle Type | NEMA L6-30R,Hardwired |
| Receptacle Detail | 4 x NEMA L6-30R |
| Protection Type | Surge,Black Out,Brownout,Line Noise |
| EMI/RFI Noise Filter | Yes |
| Phase | Single Phase |
| Application/Usage | Mission Critical Equipment,IT,Edge Computing,Network,IT Equipment,Data Center,Business,Education,Government,Healthcare,Retail,Server,POS Equipment,Switch |
| Power Description | |
| Load Capacity (VA) | 11 kVA |
| Load Capacity (Watt) | 11 kW |
| Input Voltage | 230 V AC |
| Output Voltage | 200 V AC,208 V AC,220 V AC,230 V AC,240 V AC |
| Output Frequency | 50 Hz,60 Hz |
| Waveform Type | Sine Wave,Pure Sine Wave |
| Output Power Factor | 1 |
| Display & Graphics | |
| Display | LCD |
| Management | |
| Network Management | Network-M3/INDGW-M2/Relay-MS Card,Network Card |
| Alarm | Power Failure,Low Battery,Overload,UPS Fault,Battery Fault,Remote Shutdown |
| Controls/Indicators | |
| Status Indicators | LED Indicators: LED status bar |
| Interfaces/Ports | |
| Serial Port | Yes |
| USB | Yes |
| EPO Port | Yes |
| Battery Information | |
| DC System Voltage | 240 V DC |
| Battery Characteristics | Hot-swappable/Valve-regulated |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 3.10 Minute |
| Backup/Run Time (Half Load) | 9.40 Minute |
| Typical Battery Recharge Time | 3 Hour |
| Replaceable Battery | Yes |
| Environmental Conditions | |
| Maximum Operating Temperature | 104°F (40°C) |
| Thermal Dissipation | 1767 BTU/h |
| Physical Characteristics | |
| Form Factor | Rack/Tower |
| Rack Height | 4U |
| Height | 6.80" (172.72 mm) |
| Width | 17.30" (439.42 mm) |
| Depth | 32.60" (828.04 mm) |
| Weight (Approximate) | 188.70 lb (85592.88 g) |
| Miscellaneous | |
| Package Contents | 9PX G2 9PX11KMG2 11000VA Rack/Tower UPS MBP11K208G2 Maintenance Bypass NETWORK-M3 Gigabit Network Card USB Cable RS-232 Cable Cable Gland for Hardwire Connection Rack-mounting Hardware Tower Stands Quick Start Guide |
| Energy Star | Yes |
| Country of Origin | Philippines |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What is the power capacity of this Eaton UPS?
The Eaton 9PX11KMG2 provides 11000VA (11 kVA) and 11000 watts of power capacity. This substantial rating makes it suitable for protecting multiple servers, network switches, or other critical IT equipment in a single rack or location.
How long does the battery backup last during a power outage?
At full load (11 kW), the UPS provides approximately 3.10 minutes of runtime. At half load (5.5 kW), runtime extends to about 9.40 minutes. These figures allow for orderly shutdown of connected equipment or temporary ride-through of brief power interruptions.
What input and output voltages does this UPS support?
This unit requires a 230V AC input. It delivers a regulated output across a range of 200V to 240V AC, specifically supporting 200V, 208V, 220V, 230V, and 240V AC outputs. This flexibility accommodates various regional electrical standards and equipment requirements.
Can this UPS be installed in both rack and tower configurations?
Yes, the Eaton 9PX11KMG2 is designed as a rack/tower convertible unit. It has a 4U rack height for standard server rack installation, and includes tower stands for standalone deployment. The package contains all necessary mounting hardware for both configurations.
What type of batteries does this UPS use and are they replaceable?
The UPS utilizes hot-swappable, valve-regulated lead acid batteries. These batteries are user-replaceable without requiring system shutdown, minimizing downtime during maintenance. The typical recharge time after a complete discharge is approximately 3 hours.
What management and monitoring capabilities does this UPS offer?
The unit includes an LCD display for local monitoring, plus serial, USB, and EPO ports for connectivity. It supports network management through the included NETWORK-M3 gigabit network card, enabling remote monitoring, configuration, and shutdown capabilities via network interfaces.
What power capacity is listed for this UPS?
The listed power specification is 11 kVA, which helps position the unit for the right load level and installation role.
What voltage details are listed?
The listed power specification is 230 V AC, which helps position the unit for the right load level and installation role.
