Eaton EMIT01-10 Metered Input Rack PDU - 1U - 1. 92 kW - 120V - 16A - 12 Outlets - 5-20R - 10 ft Cord - Single-phase
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This metered PDU operates at 120V AC input and output, with a maximum power rating of 1.92 kW (1920 watts) and an input current of 16A. The electrical design supports single-phase power distribution, making it compatible with standard North American power systems. The unit includes hydraulic magnetic circuit breakers that provide accidental trip protection, enhancing safety and reliability.
Network management capabilities allow for real-time monitoring of power usage, load balancing, and remote configuration. The RJ-45 interface supports secure access with user authentication, password protection, and SSL encryption configurable to 1024 or 2048 bit. This enables IT administrators to manage power distribution efficiently and prevent overloads.
This section brings together practical product details such as Plug/Connector Type, Plug/Connector Detail, Receptacle Type, Input Voltage, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The Eaton EMIT01-10 offers advanced power management features that improve operational efficiency and equipment protection in rack environments. Its metering functionality provides detailed insights into power consumption, helping optimize load distribution and prevent circuit overloads.
Enhanced Safety & Protection
Hydraulic magnetic circuit breakers reduce the risk of accidental trips, while colour-coded outlets and branch circuits simplify load balancing. The eGrip plug retention system securely holds standard IEC plugs, preventing accidental disconnections.
- Accidental trip protection
- Colour-coded circuits
- Secure plug retention
Network Security & Management
Remote management via RJ-45 includes user access control, password protection, and SSL encryption up to 2048 bit. This allows secure monitoring and configuration from any network location, ensuring compliance and control.
- User access control
- SSL encryption
- Remote configuration
Deployment / Use Cases
This PDU is ideal for data centers, server rooms, and network closets where reliable, monitored power distribution is essential. Its 1U horizontal design fits standard 19-inch racks, making it suitable for environments with limited vertical space.
Common applications include powering servers, switches, storage arrays, and other rack-mounted IT equipment. The metering capability supports load balancing across phases, helping data center managers optimize power usage and plan for expansion. The network management features enable proactive maintenance and reduce downtime risks.
Data Center Power Distribution
Distribute power to multiple devices in a single rack with precise monitoring and overload protection. The 12 outlets accommodate typical server and networking setups.
Remote Site Management
Manage power for equipment in colocation facilities or branch offices remotely. The network interface allows administrators to monitor and configure the PDU without physical access.
Physical Profile
The Eaton EMIT01-10 has a compact 1U rack height, measuring 19 inches in width (482.60 mm), 1.69 inches in width (42.93 mm), and 8 inches in depth (203.20 mm). Its horizontal mounting orientation ensures easy installation in standard server racks. The slim profile minimizes space usage while providing full power distribution functionality. The unit includes a 10 ft power cord for flexible placement within the rack environment.
- Width
- 1.69" (42.93 mm)
- Depth
- 8" (203.20 mm)
- Height
- 1U
What's in the Box
The package includes the Eaton ePDU Metered EMIT01-10 12-Outlet PDU along with installation and network accessories for quick setup.
Highlights
- 1.92 kW power capacity for reliable rack power distribution
- 12 NEMA 5-20R outlets support multiple devices
- 120V input and output voltage compatible with standard North American power
- 1U horizontal rack-mount design saves space in server racks
- Network management via RJ-45 for remote monitoring and control
- Hydraulic magnetic circuit breakers with accidental trip protection
- Colour-coded outlets and branch circuits for easy load balancing
- eGrip plug retention system secures IEC plugs
- 10 ft power cord with NEMA L5-20P plug for flexible installation
- 3-year limited warranty for long-term reliability
Specifications
| Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | EMIT01-10 |
| Brand Name | Eaton |
| Product Line | ePDU |
| Product Series | Metered |
| Product Model | EMIT01-10 |
| Product Name | Metered Input Rack PDU |
| Product Type | PDU |
| Technical Information | |
| Plug/Connector Type | NEMA L5-20P |
| Plug/Connector Detail | 1 x NEMA L5-20P |
| Receptacle Type | NEMA 5-20R |
| Receptacle Detail | 12 x NEMA 5-20R |
| Power Description | |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| Power Rating (Watt) | 1.92 kW |
| Input Current | 16 A |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Physical Characteristics | |
| Mounting Orientation | Horizontal |
| Rack Height | 1U |
| Height | 19" (482.60 mm) |
| Width | 1.69" (42.93 mm) |
| Depth | 8" (203.20 mm) |
| Miscellaneous | |
| Package Contents | ePDU Metered EMIT01-10 12-Outlet PDU SPK021-Installation SPK013-Network |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | 3 Year |
FAQ
What is the power capacity of the Eaton EMIT01-10 PDU?
The Eaton EMIT01-10 has a maximum power rating of 1.92 kW (1920 watts). This capacity supports distributing power to multiple rack-mounted devices such as servers, switches, and storage units, ensuring stable operation within a 120V single-phase electrical system.
How many outlets does this PDU have and what type are they?
This PDU features 12 NEMA 5-20R outlets. These are standard 120V, 20A receptacles commonly used in North America for IT equipment. The outlets are colour-coded to facilitate load balancing across branch circuits.
What input plug and cord length are included?
The PDU includes a 10 ft power cord with a NEMA L5-20P plug. This plug type is a locking 120V, 20A connector that provides a secure connection to power sources, reducing the risk of accidental disconnection in rack environments.
Can this PDU be monitored remotely?
Yes, the Eaton EMIT01-10 includes an RJ-45 network port for remote management. It supports user access control, password protection, and SSL encryption configurable to 1024 or 2048 bit. This allows IT administrators to monitor power usage, configure settings, and receive alerts from any network location.
What rack mounting options are supported?
This PDU is designed for horizontal mounting in standard 19-inch racks with a 1U height. Its dimensions are 19" wide, 1.69" wide, and 8" deep, making it suitable for environments where rack space is limited. The horizontal orientation ensures easy installation and accessibility.
What safety features does this PDU offer?
Safety features include hydraulic magnetic circuit breakers that provide accidental trip protection, reducing nuisance trips. The eGrip plug retention system secures standard IEC plugs to prevent disconnections. Colour-coded outlets help with load balancing to avoid overloads, enhancing overall electrical safety.
What power capacity is listed for this UPS?
The listed power specification is 1.92 kW, which helps position the unit for the right load level and installation role.
What voltage details are listed?
The listed power specification is 120 V AC, which helps position the unit for the right load level and installation role.
