EnGenius ECS1008P Cloud Managed 8-Port Gigabit PoE+ Switch - 55W Budget - Layer 2 - Wall/Desktop Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The ECS1008P operates as a fully manageable Gigabit Ethernet switch with eight 10/100/1000Base-T ports, each supporting PoE+ (802.3at) for up to 30W per port and a total budget of 55W. It uses twisted-pair cabling for cost-effective deployments, supporting data transfers up to 100 meters per connection.
This switch implements Layer 2 switching protocols, including STP for loop prevention, IGMP snooping for multicast efficiency, and port-based VLANs for network segmentation. The internal power supply ensures stable voltage delivery to connected PoE devices, while the fanless design maintains silent operation in office settings.
Relevant factors for this section include Total Number of Network Ports, Port/Expansion Slot Details, Media Type Supported, Ethernet Technology. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The ECS1008P combines compact design with enterprise-grade management features, making it an ideal choice for growing networks that need both power and control. Its cloud management capability provides real-time visibility and configuration flexibility without requiring on-premises controllers.
Centralized Cloud Management
Remotely configure VLANs, QoS, PoE schedules, and port settings through EnGenius's cloud platform, enabling multi-site management from a single dashboard.
- Web-based interface
- No additional licenses required
- Firmware updates via cloud
Power Over Ethernet Ready
Deliver both data and power over standard Ethernet cables to simplify installations and reduce clutter from separate power adapters.
- Supports 802.3at PoE+
- 55W total budget
- Auto-sensing per port
Flexible Deployment Options
Mount the switch on a wall or place it on a desktop, with included hardware for secure installation in tight spaces like wiring closets or behind monitors.
- Wall mount kit included
- Compact footprint
- Ground screw set for safety
Deployment / Use Cases
The ECS1008P is suited for small office networks, retail environments, and light commercial deployments where reliable PoE and managed switching are required. Its 55W PoE budget can power multiple devices simultaneously, such as IP surveillance cameras, wireless access points, and VoIP phones, creating a unified network infrastructure.
In educational settings or branch offices, this switch supports segmented networks for different departments or guest access via VLANs. The cloud management feature allows IT staff to oversee multiple locations without traveling, making it cost-effective for distributed organizations.
Small Business Networking
Connect computers, printers, and servers while powering PoE devices like IP phones and cameras, all managed through a cloud interface for minimal IT overhead.
Retail & Hospitality
Deploy in point-of-sale systems, digital signage, and guest Wi-Fi networks, with wall mounting to keep cables organized and out of sight.
Physical Profile
Measuring 1.06 inches high, 4.13 inches wide, and 9.45 inches long, the ECS1008P has a compact footprint that fits easily on desktops or in wall-mounted enclosures. Its steel casing provides durability, while the fanless design ensures silent operation in noise-sensitive environments like offices or classrooms.
The switch includes a wall mount kit and ground screw set for secure installation, with ventilation slots to prevent overheating during continuous use. Weighing 3.31 pounds, it is lightweight yet robust enough for stable mounting on drywall or rack shelves.
- Width
- 4.13" (105 mm)
- Height
- 1.06" (27 mm)
- Weight
- 3.31 lb (1500 g)
- Length
- 9.45" (240 mm)
What's in the Box
The EnGenius ECS1008P ships with all necessary components for immediate deployment, including power accessories and mounting hardware.
Highlights
- 8 Gigabit Ethernet ports with PoE+ support for up to 55W total budget
- Cloud-managed via web interface for remote configuration and monitoring
- Layer 2 switching with VLAN, QoS, and STP for advanced network control
- Wall mountable or desktop form factor with included installation kit
- Fanless design for silent operation in office environments
- Supports twisted-pair cabling up to 100 meters per connection
- Internal power supply ensures stable voltage for PoE devices
- 2-year limited warranty from EnGenius
Specifications
| Specifications | |
|---|---|
| Manufacturer | EnGenius Technologies, Inc |
| Manufacturer Part Number | ECS1008P |
| Brand Name | EnGenius |
| Product Series | ECS |
| Product Model | ECS1008P |
| Product Name | Cloud Managed 55W PoE 8 Port Network Switch |
| Packaged Quantity | 1 |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 8 |
| Port/Expansion Slot Details | 8 x Gigabit Ethernet PoE+ |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T |
| Network & Communication | |
| Layer Supported | 2 |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| Power Source | Power Supply |
| Physical Characteristics | |
| Form Factor | Wall Mountable,Desktop |
| Height | 1.06" (27 mm) |
| Width | 4.13" (105 mm) |
| Length | 9.45" (240 mm) |
| Weight (Approximate) | 3.31 lb (1500 g) |
| Miscellaneous | |
| Package Contents | Cloud Managed 55W PoE 8 Port Network Switch 1 x Quick Installation Guide 1 x Power Adapter 1 x Power Cord 1 x Wall Mount Kit 1 x Ground Screw Set |
| Country of Origin | Taiwan |
| Warranty | |
| Limited Warranty | 2 Year |
FAQ
How many PoE devices can the ECS1008P power simultaneously?
The ECS1008P has a total PoE budget of 55W across all eight ports, supporting multiple PoE+ (802.3at) devices like IP cameras or access points. Each port can deliver up to 30W, so the number of devices depends on their individual power requirements; for example, it could power four 12W cameras and two 15W phones within the 55W limit.
Does this switch support VLANs and quality of service (QoS)?
Yes, as a Layer 2 manageable switch, the ECS1008P supports port-based VLANs for network segmentation and QoS for prioritizing traffic such as VoIP or video streaming. These features are configurable through the cloud management interface, allowing administrators to optimize network performance for critical applications.
Can I mount the ECS1008P on a rack?
The ECS1008P is designed for wall or desktop mounting, not standard rack mounting. It includes a wall mount kit for secure installation on vertical surfaces, but its compact dimensions (1.06" H x 4.13" W x 9.45" L) may fit on shallow rack shelves with additional brackets, though EnGenius does not specify rack-mount compatibility.
What is the warranty period for this switch?
EnGenius provides a 2-year limited warranty for the ECS1008P, covering defects in materials and workmanship under normal use. This warranty applies from the date of purchase and includes support for repairs or replacements, with terms detailed in the product documentation.
Does the switch require a separate controller for cloud management?
No, the ECS1008P does not require a separate hardware controller for cloud management. It connects directly to the internet and can be managed through EnGenius's web-based cloud platform, enabling configuration, monitoring, and firmware updates without additional devices or licenses.
What type of cables are compatible with this switch?
The ECS1008P supports twisted-pair Ethernet cables (Cat5e, Cat6, or higher) for Gigabit connections up to 100 meters. It uses standard RJ45 ports and is compatible with 10/100/1000Base-T network technology, making it work with most existing cabling infrastructure in offices or small businesses.
