Epson B11B250201 WorkForce DS-870 Sheetfed Scanner - 65 ppm Color/Mono - 600 dpi Optical - 30-bit Color/Grayscale - Duplex - 100-Sheet ADF
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The DS-870's technical architecture centers on its high-speed scanning engine that achieves 65 pages per minute for both color and monochrome documents, translating to 130 images per minute in duplex mode. This performance is supported by a 600 dpi optical sensor that provides true hardware resolution without software interpolation, ensuring sharp text and accurate image reproduction.
Color fidelity is maintained through 30-bit color depth processing, which captures over 1 billion colors for lifelike document reproduction, while the 30-bit grayscale depth preserves 1,073 shades of gray for superior black-and-white document scanning. The scanner handles diverse media types including plastic cards, ID cards, embossed cards, business cards, and standard paper documents up to 8.50 inches wide and 20 feet long, accommodating everything from standard letter documents to continuous form documents.
Key Product Advantages
High-Speed Productivity
With 65 ppm scanning speed for both color and mono documents, the DS-870 dramatically reduces document processing time compared to slower scanners, enabling workgroups to digitize large document batches quickly and efficiently.
- 65 ppm color and mono scanning
- 130 ipm duplex throughput
- 100-sheet ADF for extended operation
Professional Image Quality
The 600 dpi optical resolution combined with 30-bit color and grayscale depth ensures documents are captured with exceptional detail and color accuracy, making it suitable for archival-quality scanning and color-critical applications.
- 600 dpi optical resolution
- 30-bit color depth
- 30-bit grayscale depth
Versatile Media Handling
Beyond standard paper documents, the scanner accommodates plastic cards, ID cards, embossed cards, and business cards, making it a comprehensive solution for mixed-document environments that require flexible media handling.
- Plastic card compatibility
- ID card scanning
- Business card processing
Deployment / Use Cases
The Epson WorkForce DS-870 is specifically designed for workgroup environments where multiple users need reliable, high-volume scanning capabilities. Its 65 ppm throughput makes it ideal for departments that regularly process invoices, contracts, patient records, student documents, or legal paperwork, transforming physical documents into searchable digital files that can be archived, shared, or integrated into document management systems.
In healthcare settings, the scanner efficiently digitizes patient forms, insurance cards, and medical records while maintaining HIPAA compliance through secure document handling. Legal offices benefit from its ability to scan lengthy case files and evidentiary documents with consistent quality. Educational institutions use it for digitizing student records, administrative forms, and research materials. The scanner's compact design allows it to fit in shared workspaces, reception areas, or departmental hubs without occupying excessive desk real estate.
Physical Profile
The DS-870 features a compact sheetfed design measuring 8.50 inches high, 11.60 inches wide, and 8.30 inches deep, occupying significantly less desk space than traditional flatbed scanners. Weighing 7.90 pounds, it remains stable during operation while remaining portable enough for occasional relocation between workstations or departments. The durable construction ensures reliable performance in busy office environments, with a design that minimizes moving parts for reduced maintenance requirements.
- Width
- 11.60" (294.64 mm)
- Depth
- 30-bit
- Height
- 8.50" (215.90 mm)
- Weight
- 7.90 lb (3583.38 g)
What's in the Box
The scanner ships complete with everything needed for immediate deployment in your work environment.
Highlights
- 65 pages per minute scanning speed for both color and monochrome documents
- 600 dpi optical resolution for sharp, detailed document capture
- 30-bit color depth and 30-bit grayscale depth for superior image quality
- Duplex scanning processes both sides of documents in a single pass
- 100-sheet automatic document feeder for extended unattended operation
- Handles plastic cards, ID cards, embossed cards, and business cards
- Compact sheetfed design uses less desk space than flatbed scanners
- USB connectivity with Mac OS and Windows compatibility
- Three-year limited warranty for long-term reliability
- RoHS compliant for environmentally responsible operation
Specifications
| Specifications | |
|---|---|
| Manufacturer | Epson Corporation |
| Manufacturer Part Number | B11B250201 |
| Brand Name | Epson |
| Product Line | WorkForce |
| Product Model | DS-870 |
| Product Name | DS-870 Color Duplex Workgroup Document Scanner |
| Product Type | Sheetfed Scanner |
| Technical Information | |
| Optical Resolution (dpi) | 600 |
| Scan Color | Color,Grayscale,Monochrome |
| Color Depth | 30-bit |
| Grayscale Depth | 30-bit |
| Maximum Mono Scan Speed (ppm) | 65 |
| Maximum Color Scan Speed (ppm) | 65 |
| Maximum Mono Scan Speed (ipm) | 130 |
| Maximum Color Scan Speed (ipm) | 130 |
| Media Type | Plastic Card,ID Card,Embossed Card,Business Card,Paper Document |
| Media Size | Custom Size - 8.50" (215.90 mm) x 20 ft (6096 mm) |
| ADF Capacity | 100 Sheets |
| Duplex Scanning | Yes |
| Scanning Modes | Duplex |
| Interfaces/Ports | |
| USB | Yes |
| Software | |
| Operating System Supported | Mac OS,Windows |
| Physical Characteristics | |
| Height | 8.50" (215.90 mm) |
| Width | 11.60" (294.64 mm) |
| Depth | 8.30" (210.82 mm) |
| Weight (Approximate) | 7.90 lb (3583.38 g) |
| Miscellaneous | |
| Package Contents | DS-870 Color Duplex Workgroup Document Scanner Start Here poster SuperSpeed USB 3.0 cable AC adapter with power cable |
| Country of Origin | Indonesia |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What is the maximum scanning speed of the Epson DS-870 scanner?
The Epson WorkForce DS-870 scans at 65 pages per minute for both color and monochrome documents. In duplex mode, this translates to 130 images per minute since both sides of each document are scanned simultaneously. This high-speed performance makes it suitable for workgroups that need to process large volumes of documents efficiently without creating bottlenecks in document digitization workflows.
What types of media can the DS-870 scanner handle?
This scanner accommodates a wide range of media types including standard paper documents, plastic cards, ID cards, embossed cards, and business cards. It supports custom media sizes up to 8.50 inches wide and 20 feet long, making it versatile enough for everything from letter-sized documents to continuous form documents. The 100-sheet automatic document feeder is designed to handle mixed media batches efficiently.
Does the DS-870 support duplex scanning?
Yes, the DS-870 features automatic duplex scanning capability that processes both sides of documents in a single pass through the scanner. This doubles throughput efficiency compared to single-sided scanning and eliminates the need to manually flip documents. The duplex function works for both color and monochrome scanning at the full 65 ppm speed, making it ideal for double-sided documents like contracts, reports, and forms.
What operating systems are compatible with this scanner?
The Epson WorkForce DS-870 is compatible with both Mac OS and Windows operating systems. It connects via USB interface, typically using USB 3.0 for optimal data transfer speeds. The scanner works with standard scanning software included with these operating systems as well as third-party document management applications, ensuring easy integration into existing office IT environments without requiring specialized drivers or complex configuration.
How does the 30-bit color depth benefit document scanning?
The 30-bit color depth enables the scanner to capture over 1 billion colors, providing exceptional color accuracy and subtle tonal variations that are essential for scanning color documents, photographs, and graphics. This high color depth ensures that scanned documents maintain their original appearance with realistic color reproduction, making it suitable for applications where color fidelity matters, such as marketing materials, design documents, or archival scanning of color-critical materials.
What is included in the warranty coverage for this scanner?
Epson provides a three-year limited warranty for the WorkForce DS-870 scanner, covering defects in materials and workmanship under normal use. This extended warranty period reflects the product's reliability and durability in workgroup environments. The scanner is also RoHS compliant, meaning it meets environmental standards by restricting hazardous substances, and it's manufactured in Indonesia with environmentally friendly practices.
