Epson B11B262201 DS-770 II Large Format Sheetfed Scanner - 45 ppm Color & Mono - 600 dpi Optical - 24-bit Color/Grayscale - 100-Sheet ADF - Duplex
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The DS-770 II delivers scanning performance at 45 pages per minute for both color and monochrome documents, with an optical resolution of 600 dpi. This combination of speed and resolution ensures detailed capture of text, graphics, and fine lines while maintaining efficient workflow throughput.
The scanner features 24-bit color depth and 24-bit grayscale depth, providing accurate color reproduction and smooth tonal gradations in grayscale documents. The automatic document feeder holds up to 100 sheets, reducing the need for frequent reloading during batch scanning operations.
This section brings together practical product details such as Large Format, Optical Resolution (dpi), Scan Color, USB, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The DS-770 II offers several advantages for business document management, starting with its balanced combination of speed and image quality. The scanner maintains consistent 45 ppm performance regardless of whether you're scanning in color or monochrome mode, eliminating workflow bottlenecks when processing mixed document types.
Large Format Capability
Supports documents up to 8.5" wide and 20 feet long, making it ideal for technical drawings, architectural plans, and lengthy legal documents that exceed standard page sizes.
Versatile Media Handling
Accepts plain paper, business cards, ID cards, and plastic cards, providing flexibility for scanning various document types without requiring separate equipment.
Efficient Duplex Operation
Automatically scans both sides of documents in a single pass, doubling throughput for double-sided materials while maintaining the 45 ppm speed rating.
Deployment / Use Cases
The Epson DS-770 II is particularly well-suited for office environments requiring high-volume document digitization with consistent quality. Its combination of speed, capacity, and large format support makes it an excellent choice for legal firms, engineering offices, government agencies, and corporate records departments.
Common deployment scenarios include digitizing contract archives, converting technical drawings to digital formats, processing invoice batches, and creating searchable PDFs from historical documents. The scanner's compact footprint allows it to fit comfortably on office workstations while providing production-level scanning capabilities.
Legal Document Management
Efficiently digitizes case files, contracts, and legal correspondence with accurate color reproduction for highlighted text and annotations.
Engineering Documentation
Captures technical drawings and schematics up to 20 feet in length while maintaining fine line detail and annotation clarity.
Physical Profile
Measuring 11.6" wide × 6.6" deep × 6.9" high and weighing approximately 8.1 pounds, the DS-770 II maintains a compact footprint suitable for desktop use in space-constrained office environments. The sheetfed design eliminates the large flatbed surface area of traditional scanners while providing equivalent scanning capabilities for most business documents.
The scanner's construction emphasizes durability for high-volume use, with reinforced paper paths and reliable mechanical components. The Energy Star certification indicates efficient power management during both active scanning and standby periods.
- Width
- 11.60" (294.64 mm)
- Depth
- 24-bit
- Height
- 6.90" (175.26 mm)
- Weight
- 8.10 lb (3674.10 g)
What's in the Box
The scanner package includes all necessary components for immediate deployment in your office environment.
Highlights
- 45 ppm scanning speed for both color and monochrome documents
- 600 dpi optical resolution for detailed image capture
- 24-bit color depth and 24-bit grayscale depth
- 100-sheet automatic document feeder capacity
- Automatic duplex scanning for double-sided documents
- Large format support up to 8.5" × 20' documents
- USB 3.0 interface for fast data transfer
- Compatible with Windows and macOS operating systems
- Energy Star certified for energy efficiency
- 3-year limited warranty for peace of mind
Specifications
| Specifications | |
|---|---|
| Manufacturer | Epson Corporation |
| Manufacturer Part Number | B11B262201 |
| Brand Name | Epson |
| Product Model | DS-770 II |
| Product Name | DS-770 II Color Duplex Document Scanner |
| Product Type | Sheetfed Scanner |
| Technical Information | |
| Large Format | Yes |
| Optical Resolution (dpi) | 600 |
| Scan Color | Color,Grayscale,Monochrome |
| Color Depth | 24-bit |
| Grayscale Depth | 24-bit |
| Maximum Mono Scan Speed (ppm) | 45 |
| Maximum Color Scan Speed (ppm) | 45 |
| Maximum Mono Scan Speed (ipm) | 90 |
| Maximum Color Scan Speed (ipm) | 90 |
| Media Type | Plain Paper,Business Card,ID Card,Plastic Card |
| Media Size | 2" (50.80 mm) x 2" (50.80 mm),8.50" (215.90 mm) x 20 ft (6096 mm) |
| ADF Capacity | 100 Sheets |
| Duplex Scanning | Yes |
| Scanning Modes | Duplex |
| Interfaces/Ports | |
| USB | Yes |
| Software | |
| Operating System Supported | Windows 10,Windows 8,Windows 8.1,Windows 7,macOS 10.10.x,macOS 11.x |
| Physical Characteristics | |
| Height | 6.90" (175.26 mm) |
| Width | 11.60" (294.64 mm) |
| Depth | 6.60" (167.64 mm) |
| Weight (Approximate) | 8.10 lb (3674.10 g) |
| Miscellaneous | |
| Package Contents | DS-770 II Color Duplex Document Scanner Start Here Poster SuperSpeed USB 3.0 Cable AC Adapter with Power Cable |
| Energy Star | Yes |
| Country of Origin | Indonesia |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What is the maximum scanning speed of the Epson DS-770 II?
The DS-770 II scans at 45 pages per minute for both color and monochrome documents. This consistent speed applies to simplex (single-sided) scanning, with duplex (double-sided) scanning maintaining the same throughput by scanning both sides simultaneously during document feeding.
Does this scanner support large format documents?
Yes, the DS-770 II is a large format sheetfed scanner that supports documents up to 8.5 inches wide and 20 feet long. This makes it suitable for technical drawings, architectural plans, legal documents, and other materials that exceed standard letter or legal page dimensions.
What is the automatic document feeder capacity?
The automatic document feeder holds up to 100 sheets of standard weight paper. This capacity reduces the need for frequent reloading during batch scanning operations and supports efficient processing of multi-page documents without manual intervention between pages.
Does the scanner support duplex (double-sided) scanning?
Yes, the DS-770 II features automatic duplex scanning that captures both sides of a document in a single pass through the scanner. This functionality doubles throughput for double-sided materials while maintaining the 45 ppm scanning speed, making it efficient for processing contracts, reports, and other two-sided documents.
What operating systems are compatible with this scanner?
The scanner supports Windows 10, Windows 8, Windows 8.1, Windows 7, macOS 10.10.x, and macOS 11.x. Drivers are available for both TWAIN and ISIS protocols, ensuring compatibility with most document management and imaging software on these platforms.
What type of USB connection does the scanner use?
The DS-770 II connects via SuperSpeed USB 3.0, providing fast data transfer between the scanner and computer. This interface ensures that scanning speed is not limited by connection bandwidth, particularly important when scanning at 45 ppm with 600 dpi resolution and 24-bit color depth.
What sheet capacity, media size, or paper handling detail is listed?
2" (50.80 mm) x 2" (50.80 mm),8.50" (215.90 mm) x 20 ft (6096 mm).
What connectivity options are listed?
Connectivity support is listed in the product specifications, including the relevant wireless or port options when available.
