Epson B11B256201 WorkForce DS-30000 Large Format Sheetfed Scanner - 70 ppm Color/Mono - 600 dpi Optical - 120 Sheet ADF - USB 3. 0
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
High-Speed Scanning Architecture
The DS-30000 achieves consistent 70 pages per minute scanning for both color and monochrome documents through its advanced CIS image sensor and RGB LED illumination system. This performance translates to 140 images per minute in duplex mode, effectively doubling throughput when scanning two-sided documents.
- 70 ppm color and monochrome scanning
- 140 ipm duplex scanning capability
- RGB LED light source for consistent illumination
Precision Imaging Technology
With 600 dpi optical resolution and 30-bit color depth, the scanner captures fine details and subtle color variations with exceptional accuracy. The 24-bit grayscale depth ensures precise reproduction of black-and-white documents, photographs, and technical drawings where tonal accuracy is critical.
- 600 dpi optical resolution
- 30-bit color depth for wide color gamut
- 24-bit grayscale depth for tonal accuracy
Key Product Advantages
The DS-30000 delivers several distinct advantages for organizations requiring reliable, high-volume document scanning. Its combination of speed, media flexibility, and image quality addresses common pain points in document management workflows while maintaining operational efficiency.
Exceptional Media Versatility
Beyond standard paper sizes, the scanner accommodates diverse media types including plastic cards, embossed cards, passports, business cards, and ID cards. The adjustable thickness handling from thin receipts to rigid plastic cards up to 6mm thick ensures comprehensive document capture without manual sorting.
- Handles media from 0.30mm to 6mm thick
- Supports plastic cards and embossed media
- Processes passports and ID cards without damage
Robust Office Integration
USB 3.0 connectivity provides fast data transfer while maintaining broad compatibility with existing office infrastructure. The scanner's compact desktop form factor fits standard workspaces without requiring specialized furniture or excessive desk real estate.
- USB 3.0 for high-speed data transfer
- Compact desktop design
- Broad OS compatibility
Deployment / Use Cases
The Epson DS-30000 excels in environments where document digitization volume and quality requirements exceed standard scanner capabilities. Its large format support and high throughput make it particularly valuable for specialized applications beyond general office document scanning.
Legal firms benefit from the scanner's ability to process oversized legal documents, evidence materials, and case files while maintaining chain-of-custody through batch scanning. Educational institutions use it for digitizing historical archives, oversized artwork, and technical drawings in libraries and administrative offices.
Architectural and Engineering Documentation
Engineering firms and architectural practices utilize the DS-30000 for digitizing blueprints, technical drawings, and schematics up to 12 inches wide. The scanner preserves fine line details and annotations critical for digital archives and CAD integration workflows.
Government and Municipal Records Management
Municipal offices and government agencies deploy the scanner for digitizing land records, property deeds, historical documents, and oversized forms. The 30,000-page duty cycle supports sustained scanning operations during records conversion projects.
Physical Profile
The DS-30000 features a compact desktop design measuring 14.61" wide × 8.19" deep × 8.62" high, occupying minimal workspace while delivering large format scanning capability. Weighing 13.45 pounds, the scanner remains stable during high-speed operation without requiring specialized mounting or reinforcement.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 8.62" (219 mm), 14.61" (371 mm), 30-bit, 13.45 lb (6100 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 14.61" (371 mm)
- Depth
- 30-bit
- Height
- 8.62" (219 mm)
- Weight
- 13.45 lb (6100 g)
What's in the Box
The scanner ships complete with all necessary components for immediate deployment in office environments.
Highlights
- 70 pages per minute scanning for both color and monochrome documents
- Large format support up to 12" wide × 18.33 ft long documents
- 120-sheet automatic document feeder for batch scanning
- 600 dpi optical resolution with 30-bit color depth
- Duplex scanning for automatic two-sided document processing
- USB 3.0 connectivity for high-speed data transfer
- 30,000-page monthly duty cycle for high-volume environments
- Handles diverse media including plastic cards and embossed documents
- Compact desktop design with minimal workspace footprint
- Compatible with Windows 7-10 and macOS 10.7-10.15 operating systems
Specifications
| Specifications | |
|---|---|
| Manufacturer | Epson Corporation |
| Manufacturer Part Number | B11B256201 |
| Brand Name | Epson |
| Product Line | WorkForce |
| Product Model | DS-30000 |
| Product Name | DS-30000 Large-Format Document Scanner |
| Product Type | Sheetfed Scanner |
| Technical Information | |
| Large Format | Yes |
| Image Sensor Type | CIS |
| Optical Resolution (dpi) | 600 |
| Scan Color | Color,Grayscale,Monochrome |
| Color Depth | 30-bit |
| Grayscale Depth | 24-bit |
| Maximum Mono Scan Speed (ppm) | 70 |
| Maximum Color Scan Speed (ppm) | 70 |
| Maximum Mono Scan Speed (ipm) | 140 |
| Maximum Color Scan Speed (ipm) | 140 |
| Media Type | Letter,Passport,Plastic Card,Embossed Card,Business Card,Postcard,ID Card |
| Media Size | A4 - 8.27" (210 mm) x 11.69" (297 mm),Custom Size - 12" (304.80 mm) x 18.33 ft (5588 mm),A3 - 11.69" (297 mm) x 16.54" (420 mm) |
| ADF Capacity | 120 Sheets |
| Minimum Media Thickness | 11.81 mil (0.30 mm) |
| Maximum Media Thickness | 0.24" (6 mm) |
| Duplex Scanning | Yes |
| Scanning Modes | Duplex |
| Duty Cycle | 30000 |
| Light Source | RGB LED |
| Interfaces/Ports | |
| USB | Yes |
| USB Standard | USB 3.0 |
| Software | |
| Operating System Supported | Windows 8,macOS 10.9.x,macOS 10.15.x,macOS 10.7.x,macOS 10.8.x,Windows 10 (32-bit/64-bit),Windows 8.1 (32-bit/64-bit),Windows 7 (32/64-bit) SP1 |
| Power Description | |
| Off-Mode Power Consumption | 100 mW |
| Standby Power Consumption | 9 W |
| Physical Characteristics | |
| Form Factor | Desktop |
| Height | 8.62" (219 mm) |
| Width | 14.61" (371 mm) |
| Depth | 8.19" (208 mm) |
| Weight (Approximate) | 13.45 lb (6100 g) |
| Miscellaneous | |
| Package Contents | Epson DS-30000 USB 3.0 High Speed Cable Power adapter Getting Started Guide |
| Country of Origin | Indonesia |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 1 Year |
User Manual
FAQ
What is the maximum document size this scanner can handle?
The Epson DS-30000 supports large format documents up to 12 inches wide and 18.33 feet long, making it suitable for technical drawings, architectural plans, and oversized legal documents. Standard sizes include A4 (8.27" × 11.69") and A3 (11.69" × 16.54"), with custom size capability for irregular documents within the maximum dimensions.
How fast does this scanner process documents?
The scanner achieves 70 pages per minute for both color and monochrome scanning, translating to 140 images per minute when processing two-sided documents in duplex mode. This high throughput is sustained by the 120-sheet automatic document feeder and robust mechanical design rated for 30,000 pages monthly duty cycle.
What types of media can the DS-30000 scan?
Beyond standard paper, the scanner handles plastic cards, embossed cards, passports, business cards, postcards, and ID cards. It accommodates media thickness from 0.30mm (11.81 mil) to 6mm (0.24"), ensuring proper feeding and image capture across diverse document types without manual adjustment between batches.
What connectivity options does this scanner offer?
The DS-30000 features USB 3.0 connectivity for high-speed data transfer to connected computers. This interface provides sufficient bandwidth for the scanner's maximum throughput while maintaining compatibility with modern office workstations and laptops without requiring additional interface cards or specialized hardware.
Which operating systems are supported?
The scanner supports Windows 7 (32/64-bit) SP1, Windows 8, Windows 8.1 (32-bit/64-bit), Windows 10 (32-bit/64-bit), and macOS versions 10.7.x through 10.15.x. Driver software and scanning utilities are available for these platforms, enabling integration with existing document management systems and workflow applications.
What is included in the warranty coverage?
Epson provides a 1-year limited warranty covering defects in materials and workmanship. The scanner is manufactured in Indonesia and complies with RoHS environmental standards, reflecting Epson's commitment to product quality and environmental responsibility throughout the product lifecycle.
What sheet capacity, media size, or paper handling detail is listed?
A4 - 8.27" (210 mm) x 11.69" (297 mm),Custom Size - 12" (304.80 mm) x 18.33 ft (5588 mm),A3 - 11.69" (297 mm) x 16.54" (420 mm).
What connectivity options are listed?
Connectivity support is listed in the product specifications, including the relevant wireless or port options when available.
