Ergotron 45-683-026 LX Pro Wall Monitor Arm - Polished Aluminum - 34" Screen - 22 lb Capacity - VESA 75 x 100 - Height Adjustable Tilt Pan Pivot
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The LX Pro Wall Monitor Arm is engineered for smooth, effortless motion. The spring-assisted lift mechanism offers continuous height adjustment, counterbalancing monitors from 4 to 22 lb with ease. The tilt range spans -15° to +70°, allowing both upright and downward viewing angles, while the pan and rotation both reach 360° for complete positional freedom.
Mounting is straightforward: the included wall plate attaches to wood studs or concrete with the provided fasteners, and the arm secures to the VESA plate (compatible with 75x75 mm and 100x100 mm patterns). The built-in cable management channels keep wiring tidy, and a rotation stop prevents the arm from hitting the wall. The polished aluminum finish resists corrosion and blends with modern interiors.
VESA Compatibility
Fits both 75x75 mm and 100x100 mm VESA patterns with included hardware.
Rotation Stop
Built-in limit prevents the arm from swinging into the wall, protecting paint and drywall.
Key Product Advantages
The LX Pro Wall Monitor Arm is built around three core benefits: ergonomic wellness, space efficiency, and dependable construction. Its gas-lift mechanism allows effortless height changes, reducing neck and eye strain during long work sessions. The modular design supports optional accessory add-ons, making it adaptable to evolving workspace needs.
The arm stows flat against the wall within 4 inches, reclaiming desk space when the monitor is pushed aside. The aluminum build and polished finish deliver long-lasting durability, backed by a 10-year limited warranty. Key features include:
Deployment / Use Cases
The Ergotron LX Pro Wall Monitor Arm is ideal for commercial offices, home workspaces, healthcare stations, and any environment where monitor positioning needs to be quick and precise. Its wall-mounted design frees up desk real estate, making it especially useful in compact or shared cubicles.
Common deployments include: sit-stand workstation conversions where the arm provides independent height adjustment, collaborative spaces where the 360° pan allows easy screen sharing, and multi-monitor setups where pairing two LX Pro arms creates an immersive panoramic configuration. The rotation stop ensures safe operation near walls or partitions.
Open-Plan Offices
- Frees desk surface
- Quick adjust for shared desks
- Cable management keeps workspace clean
Home Workstations
- Reduces screen glare via tilt/pan
- Supports up to 34" monitors
- Polished aluminum matches modern decor
Physical Profile
The LX Pro Wall Monitor Arm is crafted from polished aluminum, giving it a sleek, professional appearance that complements both contemporary and traditional interiors. The arm's finish resists fingerprints and corrosion. When fully retracted, the arm sits just 4 inches from the wall, preserving floor space. The included wall plate and fasteners support mounting on wood stud or concrete surfaces. The arm itself weighs 5.9 lb, adding minimal load to the wall structure.
- Height
- Yes
- Weight
- 5.90 lb (2676.19 g)
What's in the Box
The package includes the arm assembly, monitor pivot, wall mount base, and all necessary fasteners for wood stud or concrete installation. Hardware for VESA mounting is also provided.
Highlights
- Smooth gas-lift height adjustment for ergonomic monitor positioning
- Supports a single display up to 34" and 22 lb
- 360° pan and rotation with tilt from -15° to +70°
- Stows within 4" of the wall to maximize workspace
- Integrated cable management keeps wires organized
- Built-in rotation stop prevents arm from hitting the wall
- Mounts to wood stud or concrete walls
- Polished aluminum construction with 10-year warranty
- VESA compatible: 75x75 mm and 100x100 mm
Specifications
| Specifications | |
|---|---|
| Manufacturer | Ergotron, Inc |
| Manufacturer Part Number | 45-683-026 |
| Brand Name | Ergotron |
| Product Series | LX Pro |
| Product Name | LX Pro Wall Monitor Arm (Polished Aluminum) |
| Product Type | Mounting Arm |
| Product Information | |
| Device Supported | Monitor,LCD Display |
| Number of Displays Supported | 1 |
| Minimum Load Capacity | 4 lb (1814.37 g) |
| Maximum Load Capacity | 22 lb (9979.03 g) |
| Maximum Screen Size Supported | 34" |
| Height Adjustable | Yes |
| Features | Ergonomic,Expandable,Tilt,Rotation Stop,Easy to Install,Pan,Rotate,Adjustable,Lift Mechanism,Durable,Compact |
| Minimum Tilt Angle | -15° |
| Maximum Tilt Angle | 70° |
| Maximum Rotate Angle | 360° |
| Minimum Pan Angle | 180° |
| Maximum Pan Angle | 360° |
| Mount Function | Wall Mount,Cable Management,Tilt,Extendable,Pan,Rotate,Adjustable |
| Mount Surface | Wall,Wood Stud,Concrete |
| Physical Characteristics | |
| Color Family | Gray |
| Product Color | Polished Aluminum |
| Product Material | Aluminum |
| VESA Mount Compatible | Yes |
| Mounting Pattern | 100 x 100,75 x 75 |
| Form Factor | Wall Mountable |
| Weight (Approximate) | 5.90 lb (2676.19 g) |
| Miscellaneous | |
| Package Contents | Arm Extension Monitor Pivot Wall Mount Base Fasteners For Wood Stud Or Concrete Wall Attachment Hardware |
| Application/Usage | Wall,Workstation,Workspace,Wood Stud,Concrete,Commercial |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Warranty | |
| Limited Warranty | 10 Year |
FAQ
What is the maximum screen size and weight this arm can support?
The Ergotron LX Pro Wall Monitor Arm supports a single display up to 34 inches with a maximum load capacity of 22 lb (10 kg) and a minimum of 4 lb (1.8 kg). Always verify your monitor's weight and VESA pattern before installation.
What VESA patterns are compatible with this arm?
The arm is compatible with both 75x75 mm and 100x100 mm VESA mounting patterns. The necessary mounting hardware is included in the box for both standards.
Can the arm be adjusted after installation?
Yes, the LX Pro arm offers full motion adjustability even after wall mounting. You can adjust height using the gas-lift mechanism, tilt from -15° to +70°, pan 360°, and rotate 360°. The rotation stop prevents the arm from hitting the wall.
What type of wall surfaces is this arm designed for?
The arm is designed for mounting on wood stud walls and concrete surfaces. Fasteners for both wood stud and concrete attachment are included in the package. It is not intended for drywall without proper anchoring.
Does the arm include cable management?
Yes, the arm features integrated cable management routing along its length. This helps keep cables organized and out of sight, contributing to a cleaner workspace.
How much space does the arm take up when not in use?
When fully retracted, the arm stows the monitor within 4 inches (10 cm) of the wall, freeing up desk surface. This is ideal for space-constrained environments or when you need to push the monitor aside.
What screen size is listed?
It features a display specification of 34", giving you clear visuals for work and media use.
What refresh rate or brightness details are available?
Display-oriented products are best judged through screen, connectivity, and installation specifications. Those facts help buyers confirm visual fit, mounting flexibility, and deployment suitability more clearly than generic summary text.
