Extreme Networks 16713 Summit X460-G2 VIM-2ss Interface Module - 2-Port RJ-45 10GBase-T Stacking - 10 Gigabit Ethernet
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This interface module delivers robust technical specifications tailored for modern data center and enterprise networking environments. It utilizes 10GBase-T network technology, which operates over Category 6a or better twisted pair copper cabling, providing a cost-effective and familiar medium for 10 Gigabit Ethernet connections.
The module's two RJ-45 ports are dedicated for stacking operations, allowing multiple Summit X460-G2 switches to be logically combined into a single, managed unit. This enhances operational simplicity, improves redundancy, and increases aggregate backplane bandwidth across the stack.
Key Product Advantages
The VIM-2ss module offers distinct advantages for network administrators seeking to optimize switch performance and management. By enabling high-speed stacking links, it facilitates the creation of unified switch stacks that simplify configuration, enhance fault tolerance, and streamline network operations.
High-Speed Stacking Backbone
Provides dedicated 10 Gbit/s stacking ports, ensuring minimal latency and maximum throughput for inter-switch communication within a stack, which is critical for maintaining performance during high traffic loads.
- Dedicated 10GBase-T stacking ports
- Up to 10 Gbit/s per port
- Reduces internal stack congestion
Simplified Network Management
Allows multiple physical switches to be managed as a single logical device, reducing administrative overhead, simplifying firmware updates, and providing a unified view of the network stack.
- Single management interface
- Consolidated configuration
- Easier troubleshooting
Deployment / Use Cases
This interface module is ideally deployed in environments where switch stacking is required to scale network capacity and improve resiliency. It is commonly used in enterprise data centers, campus networks, and large office deployments where high availability and simplified management are priorities.
Typical use cases include expanding existing Summit X460-G2 switch stacks, creating new high-density access layer stacks, or building resilient core/distribution layers. The use of twisted pair cabling makes it particularly suitable for retrofits or installations where fiber optic infrastructure is not available or cost-prohibitive.
Data Center Access Layer
Deploy in data center racks to stack access switches, providing a high-bandwidth backbone for server connectivity while maintaining a small physical footprint and simplified management.
Enterprise Campus Networking
Use in campus wiring closets to create stacked switch configurations that support high user density, VoIP deployments, and bandwidth-intensive applications across multiple floors or buildings.
Physical Profile
The module features a compact design with dimensions of 1.40" (35.56 mm) in height, 3.40" (86.36 mm) in width, and 5.50" (139.70 mm) in depth, and weighs approximately 16.2 grams. This small form factor ensures it integrates seamlessly into the Summit X460-G2 switch chassis without adding significant bulk or weight, maintaining the switch's overall rack profile and thermal characteristics.
- Width
- 3.40" (86.36 mm)
- Depth
- 5.50" (139.70 mm)
- Height
- 1.40" (35.56 mm)
- Weight
- 16.2 g
Highlights
- Two dedicated RJ-45 ports for 10GBase-T stacking operations
- Supports 10 Gigabit Ethernet technology with 10 Gbit/s data transfer rate
- Compatible with Extreme Networks Summit X460-G2 series switches
- Uses standard twisted pair copper cabling (Category 6a or better)
- Hot-pluggable design for easy installation and replacement
- Compact form factor fits neatly into switch chassis
- Enables logical stacking of multiple switches for unified management
- Enhances network redundancy and fault tolerance within stacks
Specifications
| Specifications | |
|---|---|
| Manufacturer | Extreme Networks, Inc |
| Manufacturer Part Number | 16713 |
| Brand Name | Extreme Networks |
| Product Name | Summit X460-G2 VIM-2ss |
| Product Type | Interface Module |
| Technical Information | |
| Application/Usage | Stacking,Data Networking |
| Interfaces/Ports | |
| Total Number of Ports | 2 |
| Connector Type | RJ-45 |
| Interfaces/Ports Details | 2 x RJ-45 10GBase-T Stacking |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network Technology | 10GBase-T |
| Maximum Data Transfer Rate | 10 Gbit/s |
| Physical Characteristics | |
| Height | 1.40" (35.56 mm) |
| Width | 3.40" (86.36 mm) |
| Depth | 5.50" (139.70 mm) |
| Weight (Approximate) | 16.2 g |
FAQ
What is the primary function of this VIM-2ss interface module?
The Extreme Networks VIM-2ss is an interface module designed specifically for stacking Summit X460-G2 series switches. It provides two RJ-45 ports that use 10GBase-T technology to create high-speed stacking links, allowing multiple physical switches to operate as a single logical unit for simplified management and improved network resilience.
What type of cabling does this module require for stacking connections?
This module supports twisted pair copper cabling, specifically Category 6a or better, for its 10GBase-T stacking ports. It does not require fiber optic cables, making it a cost-effective solution for environments where copper infrastructure is already deployed or preferred for shorter reach connections within data centers or wiring closets.
What is the maximum data transfer rate supported by the stacking ports?
Each of the two RJ-45 stacking ports on the VIM-2ss module supports a maximum data transfer rate of 10 Gbit/s (10 Gigabit per second) using 10GBase-T Ethernet technology. This provides ample bandwidth for inter-switch communication within a stack, ensuring low latency and high throughput for network traffic.
Is this module hot-pluggable for easy installation?
Yes, the VIM-2ss interface module is designed to be hot-pluggable, meaning it can be installed or removed from a compatible Summit X460-G2 switch without powering down the switch. This feature allows for maintenance, upgrades, or replacements with minimal disruption to network operations.
