FLIR 427-0097-74-00 FC-608 O Elara 307. 2 Kilopixel Thermal Network Camera - Bullet - MPEG-4 - H. 264 - MJPEG - Wall/Corner/Pole Mount - Outdoor
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This thermal network camera operates with a thermal video resolution of 720 x 576 in PAL signal format, ensuring compatibility with regional broadcast standards. The 2.95-inch (75 mm) maximum thermal focal length allows for detailed imaging at medium ranges, suitable for perimeter and area surveillance. The camera does not support HD recording, focusing instead on thermal detection performance optimized for security and monitoring tasks.
Network communication is handled via a wired RJ-45 connection, enabling stable data transmission and integration into IP-based surveillance networks. Remote management features allow administrators to configure settings, monitor status, and perform maintenance without physical access to the unit. The technical design emphasizes reliability and interoperability in professional security deployments.
Relevant factors for this section include HD Recording, Thermal Image Sensor Type, Color Supported, Effective Camera Resolution. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The FLIR Elara FC-608 O stands out with its specialized thermal imaging capabilities, providing a critical layer of security beyond conventional visible-light cameras. Its rugged outdoor construction and versatile mounting options make it adaptable to various installation environments, from industrial sites to commercial perimeters.
Environmental Durability
Rated IP66 and IP67, the camera is dust-tight and protected against powerful water jets, ensuring reliable operation in rain, snow, and dusty conditions. The extended temperature tolerance from -50°C to 70°C supports deployment in extreme climates.
- IP66/IP67 Ingress Protection
- Wide Temperature Range
- 95% Humidity Tolerance
Mounting Flexibility
Designed for easy integration, the bullet form factor supports wall, corner, and pole mounting, allowing installers to optimize camera placement for maximum coverage and minimal blind spots in outdoor settings.
- Wall Mount Compatible
- Corner Mount Option
- Pole Mount Ready
Deployment / Use Cases
The FC-608 O is ideal for perimeter security, critical infrastructure protection, and industrial monitoring where thermal detection enhances safety and surveillance effectiveness. Its outdoor rating and thermal imaging make it suitable for applications requiring 24/7 operation in low-light or adverse weather conditions.
Common use cases include monitoring fence lines, securing warehouses and storage yards, overseeing transportation hubs, and safeguarding utilities and manufacturing plants. The camera's thermal sensor provides an advantage in detecting intruders, overheating equipment, or unauthorized activity that might be missed by standard cameras, especially at night or in foggy environments.
Perimeter Security
Deploy along property boundaries to detect intrusions with thermal imaging, reducing false alarms from wildlife or environmental movement while maintaining vigilance in complete darkness.
- Thermal Intrusion Detection
- Low-Light Operation
- Reduced False Alarms
Industrial Safety
Monitor industrial sites for overheating machinery, fire risks, or unauthorized access in areas with poor lighting or high dust levels, leveraging the camera's environmental resilience.
- Equipment Monitoring
- Fire Risk Detection
- Dust-Prone Area Suitability
Physical Profile
The bullet form factor measures 4.53 inches in height, 5.08 inches in width, and 11.10 inches in length (115 mm x 129 mm x 282 mm), with an approximate weight of 2.50 kg. This compact yet sturdy design facilitates installation on various surfaces without requiring excessive space. The housing is built to endure outdoor exposure, with finishes that resist corrosion and UV degradation over time.
- Width
- 5.08" (129 mm)
- Height
- 4.53" (115 mm)
- Weight
- 2.50 kg
- Length
- 2.95" (75 mm)
Highlights
- 307.2 Kilopixel thermal camera resolution for detailed imaging
- Uncooled VOx microbolometer sensor with color thermal output
- Supports MPEG-4, H.264, and MJPEG video formats
- Bullet form factor with wall, corner, and pole mounting options
- IP66 and IP67 ingress protection for outdoor durability
- Wired connectivity with RJ-45 network port and remote management
- Operating temperature range from -58°F to 158°F (-50°C to 70°C)
- PAL video signal format for regional compatibility
- 2.95-inch (75 mm) maximum thermal focal length
- Designed for 24/7 outdoor surveillance applications
Specifications
| Specifications | |
|---|---|
| Manufacturer | FLIR Systems GmbH |
| Manufacturer Part Number | 427-0097-74-00 |
| Brand Name | FLIR |
| Product Line | Elara |
| Product Series | FC |
| Product Model | FC-608 O |
| Product Name | Thermal Security Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | No |
| Display & Graphics | |
| Thermal Image Sensor Type | Uncooled VOx Microbolometer |
| Color Supported | Color |
| Effective Camera Resolution | 307.2 Kilopixel |
| Video | |
| Video Formats | MPEG-4,H.264,MJPEG |
| Thermal Video Resolution | 720 x 576 |
| Video Signal Format | PAL |
| Lens | |
| Maximum Thermal Focal Length | 2.95" (75 mm) |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Physical Characteristics | |
| Mount Type | Wall Mount,Corner Mount,Pole Mount |
| Form Factor | Bullet |
| Height | 4.53" (115 mm) |
| Width | 5.08" (129 mm) |
| Length | 11.10" (282 mm) |
| Weight (Approximate) | 2.50 kg |
| Environmental Conditions | |
| Minimum Operating Temperature | -58°F (-50°C) |
| Maximum Operating Temperature | 158°F (70°C) |
| Maximum Operating Humidity | 95% |
| Miscellaneous | |
| Indoor/Outdoor | Outdoor |
| Ingress Protection Rating | IP66,IP67 |
User Manual
FAQ
What is the resolution of the FLIR FC-608 O thermal camera?
The FLIR FC-608 O features an effective camera resolution of 307.2 kilopixels, with a thermal video resolution of 720 x 576 in PAL format. This resolution provides clear thermal imagery suitable for security monitoring and detection tasks in various outdoor environments.
Can this camera be used outdoors in harsh weather?
Yes, the camera is rated IP66 and IP67, making it dust-tight and protected against powerful water jets. It operates in temperatures from -58°F to 158°F (-50°C to 70°C) and up to 95% humidity, ensuring reliable performance in rain, snow, dust, and extreme climates for outdoor surveillance.
What mounting options are available for the FC-608 O?
The bullet-style camera supports wall mount, corner mount, and pole mount installations. This flexibility allows security integrators to position the camera optimally for perimeter coverage, corner placement, or elevated pole mounting to reduce blind spots and enhance monitoring effectiveness.
Does the camera support remote management?
Yes, the FC-608 O includes remote management capabilities, enabling administrators to configure settings, monitor status, and perform maintenance via the network connection without needing physical access to the camera. This feature simplifies oversight in distributed security systems.
What video formats does the camera output?
The camera outputs video in MPEG-4, H.264, and MJPEG formats. This multi-format support ensures compatibility with a wide range of network video recorders (NVRs), video management software (VMS), and monitoring systems, facilitating integration into existing security infrastructures.
Is the FLIR FC-608 O suitable for low-light or nighttime surveillance?
Absolutely. As a thermal camera, it detects heat signatures rather than relying on visible light, making it highly effective for 24/7 surveillance in complete darkness, fog, or other low-visibility conditions. This capability is ideal for perimeter security and critical infrastructure monitoring where traditional cameras may fail.
