Gigabyte H273-Z82-AAN1 2U Rackmount Barebone System - Dual Socket SP5 LGA-6096256GB DDR4 - 24 Slots - 12Gb/s SAS - 2 x 2. 6kW PSUs
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
Relevant factors for this section include Number of Nodes, Number of Processors Supported, Processor Socket, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Processor Architecture
Supports dual AMD EPYC processors via Socket SP5 LGA-6096 interfaces, enabling 64-bit processing for demanding server applications. The platform accommodates up to four nodes within the system architecture.
- Dual processor support
- Socket SP5 LGA-6096
- 64-bit processing
- Four-node architecture
Memory Configuration
Features 24 DDR4 SDRAM slots supporting up to 256GB total memory capacity with DDR5-4800/PC5-38400 memory standards. This extensive memory expansion capability supports memory-intensive applications and virtualization workloads.
- 256GB maximum capacity
- 24 DDR4 slots
- DDR5-4800/PC5-38400 standard
- Low-power operation
Key Product Advantages
This barebone system delivers enterprise-ready infrastructure with dual-redundant power supplies, extensive memory expansion, and high-speed storage connectivity in a space-efficient 2U form factor.
Enterprise Storage Connectivity
Integrated 12Gb/s SAS and Serial ATA/600 controllers provide high-speed storage interfaces suitable for enterprise storage arrays and high-performance storage solutions.
- 12Gb/s SAS interface
- Serial ATA/600 support
- Enterprise-grade reliability
Redundant Power Design
Dual 2.6kW power supplies with C19 connectors ensure power redundancy and high availability for critical server deployments, supporting both 120V and 230V input voltages.
- Dual power supplies
- 2.6kW each
- C19 connectors
- Dual voltage support
Deployment / Use Cases
The H273-Z82-AAN1 barebone system serves as an ideal foundation for virtualization hosts, database servers, and compute nodes in enterprise data centers and cloud infrastructure deployments.
With its dual-processor support and extensive memory capacity, this platform excels in virtualized environments running multiple virtual machines, containerized applications, and memory-intensive databases. The 12Gb/s SAS connectivity makes it suitable for storage servers and backup targets requiring high-throughput storage interfaces.
Virtualization Host
Supports hypervisor platforms with dual EPYC processors and up to 256GB memory for running multiple virtual machines and virtualized applications.
- Dual processor scalability
- High memory capacity
- Virtualization optimized
Enterprise Storage Server
12Gb/s SAS controllers enable high-performance storage arrays for file servers, backup targets, and storage area network deployments.
- 12Gb/s SAS speed
- Multiple expansion bays
- Storage-optimized design
Physical Profile
The 2U rack-mountable chassis measures 3.44 inches in height, 17.32 inches in width, and 34.53 inches in depth, providing standard rack compatibility while accommodating server components and cooling systems. The design includes tool-less access features for maintenance and component upgrades in data center environments.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 2U, 17.32" (440 mm), 34.53" (877 mm). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 17.32" (440 mm)
- Depth
- 34.53" (877 mm)
- Height
- 2U
What's in the Box
This barebone system ships complete with essential components for server assembly and rack installation.
Highlights
- Dual Socket SP5 LGA-6096 supports AMD EPYC processors for enterprise compute
- 256GB maximum DDR4 memory capacity across 24 slots for memory-intensive workloads
- 12Gb/s SAS and Serial ATA/600 controllers for high-speed storage connectivity
- 2U rack-mountable form factor optimizes data center space utilization
- Dual 2.6kW power supplies with C19 connectors ensure power redundancy
- Gigabit Ethernet provides reliable network connectivity for server deployments
- Two USB 3.2 Gen 1 ports for peripheral connectivity without system shutdown
- Includes eight CPU heatsinks and rail kit for complete server assembly
- RoHS and WEEE compliant for environmental responsibility
- 3-year limited warranty for long-term deployment confidence
Specifications
| Specifications | |
|---|---|
| Manufacturer | GIGABYTE Technology, Inc |
| Manufacturer Part Number | H273-Z82-AAN1 |
| Brand Name | GIGABYTE |
| Product Model | H273-Z81 |
| Product Name | H273-Z82 (rev. AAN1) Barebone System |
| Packaged Quantity | 1 |
| Product Type | Barebone System |
| Processor | |
| Number of Nodes | 4 |
| Number of Processors Supported | 2 |
| Processor Socket | Socket SP5 LGA-6096 |
| Processor Supported | EPYC |
| 64-bit Processing | Yes |
| Chipset | |
| Chipset Manufacturer | AMD |
| Memory | |
| Maximum Memory Supported | 256 GB |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR5-4800/PC5-38400 |
| Total Number of Memory Slots | 24 |
| Controllers | |
| Controller Type | 12Gb/s SAS,Serial ATA/600 |
| RAID Supported | No |
| Display & Graphics | |
| Graphics Controller Model | AST2600 |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| I/O Expansions | |
| Number of Total Expansion Bays | 2 |
| Total Number of Expansion Slots | 2 |
| Number of PCI Express x16 Slots | 1 |
| Interfaces/Ports | |
| Total Number of USB Ports | 2 |
| Number of USB 3.2 Gen 1 Ports | 2 |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Plug/Connector Type | C19 |
| Number of Power Supplies Installed | 2 |
| Maximum Power Supply Wattage | 2.60 kW |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Rack Height | 2U |
| Height | 3.44" (87.50 mm) |
| Width | 17.32" (440 mm) |
| Depth | 34.53" (877 mm) |
| Miscellaneous | |
| Package Contents | H273-Z82 (rev. AAN1) Barebone System 8 x CPU Heatsink 1 x Rail Kit |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What processors does this barebone system support?
This system supports dual AMD EPYC processors using Socket SP5 LGA-6096 interfaces. The platform accommodates 64-bit processing and is designed for enterprise server workloads requiring high core counts and performance scalability.
How much memory can I install in this server chassis?
The H273-Z82-AAN1 supports up to 256GB of DDR4 SDRAM across 24 memory slots. This extensive memory capacity enables memory-intensive applications, virtualization environments, and database workloads that benefit from large memory configurations.
What storage interfaces are available on this barebone system?
This system includes 12Gb/s SAS and Serial ATA/600 controllers for storage connectivity. These interfaces support high-speed storage devices suitable for enterprise storage arrays, backup solutions, and performance-sensitive storage applications.
What power supplies are included with this server chassis?
The system includes dual 2.6kW power supplies with C19 connectors, providing power redundancy for high-availability deployments. These power supplies support both 120V and 230V input voltages for flexible data center power infrastructure compatibility.
What expansion capabilities does this 2U chassis provide?
This barebone system offers two total expansion bays and two expansion slots, including one PCI Express x16 slot. This expansion capability supports additional storage controllers, network adapters, or specialized accelerator cards for server customization.
What is included in the package for server assembly?
The package includes the H273-Z82 (rev. AAN1) barebone system chassis, eight CPU heatsinks for processor cooling, and a rail kit for standard rack mounting. These components provide everything needed for server assembly and rack installation in data center environments.
