Gigabyte H273-Z81-AAW1 2U Rackmount Barebone Server - Dual Socket SP5 LGA-6096256 GB DDR5 - 24 Slots - 3 PCIe x16 - 2 x 3 kW PSU
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This server platform supports dual Socket SP5 LGA-6096 processors, compatible with AMD EPYC CPUs, enabling high-core-count configurations for virtualization, database, and HPC applications. The system accommodates up to 256 GB of DDR5 SDRAM across 24 memory slots, operating at DDR5-4800/PC5-38400 speeds for enhanced data throughput.
Expansion capabilities include three PCI Express x16 slots and two total expansion bays, providing ample room for add-in cards and storage drives. The integrated Serial ATA/600 controller supports fast storage connectivity, while the AST2600 graphics controller with DDR4 SDRAM handles basic display output for management tasks.
This section brings together practical product details such as Number of Nodes, Number of Processors Supported, Processor Socket, Chipset Manufacturer, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The H273-Z81-AAW1 delivers a balance of performance, density, and reliability for modern server deployments. Its dual-processor architecture and high memory capacity make it suitable for demanding computational tasks, while the 2U rack design ensures efficient use of data center floor space.
High-Density Compute
Supports dual AMD EPYC processors and up to 256 GB of DDR5 memory, enabling robust performance for virtualization and data-intensive applications.
- Dual Socket SP5 LGA-6096
- 24 DDR5 memory slots
- 64-bit processing support
Enterprise Reliability
Features redundant 3 kW power supplies with wide input voltage range (120/230 V AC) and a C19 connector for stable power delivery in critical environments.
- Dual 3 kW PSUs
- 120/230 V AC input
- C19 power connector
Flexible Expansion
Offers three PCIe x16 slots and two expansion bays for customizing with GPUs, network adapters, or storage controllers to meet specific workload needs.
- 3 PCIe x16 slots
- 2 expansion bays
- Serial ATA/600 controller
Deployment / Use Cases
This barebone server is ideal for organizations requiring scalable and customizable server infrastructure. Its design supports a variety of deployment scenarios, from private cloud and virtualization hosts to database servers and high-performance computing clusters.
In data center environments, the 2U form factor allows for dense rack mounting, maximizing compute power per rack unit. The system's dual-processor capability and extensive memory support make it well-suited for multi-tenant virtualization platforms, where resource isolation and performance are critical.
Virtualization Host
Deploy as a hypervisor host for VMware, Hyper-V, or KVM, leveraging dual EPYC processors and high memory capacity to run multiple virtual machines efficiently.
Database Server
Use for SQL or NoSQL databases, where fast memory and processor performance ensure low-latency query processing and high transaction throughput.
Physical Profile
The server chassis measures 3.44 inches in height, 17.32 inches in width, and 34.53 inches in depth (87.50 x 440 x 877 mm), conforming to standard 2U rack dimensions. Its rack-mountable design includes integrated mounting points for secure installation in 19-inch server racks, and the included rail kit simplifies deployment and maintenance.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 2U, 17.32" (440 mm), 34.53" (877 mm). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 17.32" (440 mm)
- Depth
- 34.53" (877 mm)
- Height
- 2U
What's in the Box
The package includes all necessary components to build a complete server system, ensuring a straightforward setup process.
Highlights
- Supports dual AMD EPYC processors with Socket SP5 LGA-6096
- Accommodates up to 256 GB of DDR5 SDRAM across 24 memory slots
- 2U rack-mountable form factor for high-density data center deployment
- Includes three PCI Express x16 slots for expansion cards
- Features dual 3 kW power supplies with 120/230 V AC input
- Integrated Gigabit Ethernet for network connectivity
- Comes with eight CPU heatsinks and a rail kit for easy installation
- Serial ATA/600 controller supports fast storage devices
- Environmentally compliant with RoHS and WEEE directives
- Backed by a 3-year limited warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | GIGABYTE Technology, Inc |
| Manufacturer Part Number | H273-Z81-AAW1 |
| Brand Name | GIGABYTE |
| Product Model | H273-Z81 |
| Product Name | H273-Z81 (rev. AAW1) Barebone System |
| Packaged Quantity | 1 |
| Product Type | Barebone System |
| Processor | |
| Number of Nodes | 4 |
| Number of Processors Supported | 2 |
| Processor Socket | Socket SP5 LGA-6096 |
| Processor Supported | EPYC |
| 64-bit Processing | Yes |
| Chipset | |
| Chipset Manufacturer | AMD |
| Memory | |
| Maximum Memory Supported | 256 GB |
| Memory Technology | DDR5 SDRAM |
| Memory Standard | DDR5-4800/PC5-38400 |
| Total Number of Memory Slots | 24 |
| Controllers | |
| Controller Type | Serial ATA/600 |
| RAID Supported | No |
| Display & Graphics | |
| Graphics Controller Model | AST2600 |
| Graphics Memory Technology | DDR4 SDRAM |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| I/O Expansions | |
| Number of Total Expansion Bays | 2 |
| Total Number of Expansion Slots | 3 |
| Number of PCI Express x16 Slots | 3 |
| Interfaces/Ports | |
| Total Number of USB Ports | 2 |
| Number of USB 3.2 Gen 1 Ports | 2 |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Plug/Connector Type | C19 |
| Number of Power Supplies Installed | 2 |
| Maximum Power Supply Wattage | 3 kW |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Rack Height | 2U |
| Height | 3.44" (87.50 mm) |
| Width | 17.32" (440 mm) |
| Depth | 34.53" (877 mm) |
| Miscellaneous | |
| Package Contents | H273-Z81 (rev. AAW1) Barebone System 8 x CPU Heatsink 1 x Rail Kit |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What processors are compatible with this barebone server?
The Gigabyte H273-Z81-AAW1 supports dual AMD EPYC processors using the Socket SP5 LGA-6096. This compatibility allows for high-core-count CPUs suitable for enterprise workloads like virtualization, databases, and high-performance computing.
How much memory can this server support and what type is used?
This server supports up to 256 GB of DDR5 SDRAM across 24 memory slots, operating at DDR5-4800/PC5-38400 speeds. The DDR5 technology provides improved data transfer rates and efficiency compared to previous generations, enhancing performance for memory-intensive applications.
What expansion options are available on this barebone system?
The system includes three PCI Express x16 slots for adding expansion cards such as GPUs, network adapters, or storage controllers. It also has two total expansion bays for storage drives, offering flexibility to customize storage capacity and performance based on your needs.
What power supplies are included and what are their specifications?
The server comes with two 3 kW power supplies installed. These support input voltages of 120 V AC and 230 V AC, using a C19 connector. The dual power supply configuration provides redundancy for critical deployments, ensuring continuous operation in case of a PSU failure.
What are the physical dimensions and rack compatibility of this server?
The chassis measures 3.44 inches in height, 17.32 inches in width, and 34.53 inches in depth (87.50 x 440 x 877 mm), making it a standard 2U rack-mountable unit. It is designed for installation in 19-inch server racks, and a rail kit is included for easy mounting and maintenance.
What is included in the package with this barebone server?
The package contains the H273-Z81 (rev. AAW1) Barebone System, eight CPU heatsinks for thermal management of dual processors, and one rail kit for rack mounting. These components provide everything needed to assemble and deploy the server in a data center environment.
What processor or platform detail is listed?
This product uses the 2 processor for everyday performance and multitasking.
