Gigabyte Workstation Motherboard AMD B650E Chipset Socket Micro ATX Compatible With EPYC And Ryzen Processors 128 GB Support MC13-LE0
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- 4 unbuffered DIMMs memory socket with 2-Channel
- ECC/Non-ECC; DDR5 support
- Up to 5200MHz for 1DPC; up to 3600MHz for 2DPC
Marketing Information:
Architecture for Modern Data Centers
Supporting AMD EPYC™ 4004 Series Processors for SMB and Hosted IT Services
AMD EPYC™ 4004 for 24x7 Business Growth and Manageability
AMD EPYC™ 4004 Series Processors are a welcome addition to the 4th Gen AMD EPYC™ processor family, lowering the threshold for businesses and hosting services that have been wanting to move to a platform with a server OS and other enterprise features, yet at an optimal price point in GIGABYTE solutions. SMB and hosting services rely on server-grade reliability so they can continue running 24x7. At the same time, they need to have a higher degree of manageability. On top of validating, GIGABYTE provides GIGABYTE Management Console (GMC) for system management and GIGABYTE Server Management (GSM) software for monitoring multiple servers.
The Rising AM5 Platform
AMD AM5 Socket is versatile as it can support the consumer platform yet is able to step into the field of enterprise-level applications, and GIGABYTE has motherboards, workstations, and servers to support it. Taking advantage of its low cost per core and high core count options, the first processor on this platform, the AMD Ryzen™ 7000 Series, has proven its value in the enterprise server market. Its successor, the AMD EPYC™ 4004 Series, now further expands capabilities by including even more enterprise features. These "Zen 4" architecture processors can easily handle compute-heavy workloads yet are versatile enough for users to find an optimal choice for applications where performance, productivity, and efficiency matter.
Select GIGABYTE for the AMD EPYC™ 4004 Platform | Support for Server OS
GIGABYTE has validated platforms for compatibility with Windows Server, Ubuntu, and RHEL for greater manageability and security.
Ease of Management
GIGABYTE servers come with GIGABYTE Management Console for IPMI management. And with a server OS, greater management and control is possible.
Continuous Operation
Systems have RAS features for continuous uptime and availability as users require and expect stable performance around the clock.
Energy Efficient
Our engineers have created a highly eco-friendly entry level server platform for EPYC 4004 with fan profiles and a PSU with efficiency ≥ 89%.
Performance
Up to 16 cores and 32 threads, AMD EPYC 4004 can reach its potential in GIGABYTE platforms for mission-critical and general-purpose server workloads.
Memory Support
PCIe 5.0 Ready Design
MC13-LE0 and MC13-LE1 equip several new components to ensure the best PCIe 5.0 signal quality, including PCB, PCIe Slots, M.2 Connectors, Re-drivers, Switches that are specifically designed for PCIe 5.0.
There will be no compromised on PCIe 5.0 performance on PCIe and M.2 interface.
Hardware Security
Optional TPM 2.0 Module
For hardware-based authentication, the passwords, encryption keys, and digital certificates are stored in a TPM module to prevent unwanted users from gaining access to your data. GIGABYTE TPM modules come in either a Serial Peripheral Interface or Low Pin Count bus.
Chipset Manufacturer: AMD
Chipset Model: B650E
Total Processor Supported: 1
Processor Socket: Socket AM5
Processor Supported: EPYC,Ryzen 7
Number of Memory Slots: 4
Memory Form Factor: DIMM,UDIMM
Maximum Memory Supported: 128 GB
Memory Speed Supported: 5200 MHz,3600 MHz
Memory Technology: DDR5 SDRAM
Controller Type: Serial ATA/600
RAID Supported: Yes
RAID Levels: 0,1,10
Onboard Video: CPU Dependent Video
Graphics Controller Model: AST2600
Gigabit Ethernet: Yes
Total Number of Expansion Slots: 2
Total Number of PCI Express Slots: 2
Number of PCI Express x4 Slots: 1
Number of PCI Express x16 Slots: 1
PCI Express Standard: PCI Express 5.0,PCI Express 4.0
Total Number of USB Ports: 2
Number of USB 3.2 Gen 1 Type-A Ports: 2
VGA: Yes
Number of Network (RJ-45) Ports: 2
Number of SATA Interfaces: 4
Number of M.2 Interfaces: 1
Total Number of Onboard USB Ports: 5
Number of Onboard USB 2.0 Ports: 2
Form Factor: Micro ATX
Width: 9.61" (244 mm)
Depth: 9.61" (244 mm)
Environmental Compliance: China Restriction of Hazardous Substances (China RoHS),Waste Electrical and Electronic Equipment Directive (WEEE)
- Compatible EPYC processor lets you perform all your computational tasks at a swift pace
- DDR5 SDRAM slot for convenient installation of memory
- RAID supported levels provide data reliability and fault tolerance
- Retrieve a significant number of PCI slots, expansion slots, and peripheral ports that have an enhanced heat dissipation capability with the Micro ATX workstation motherboard
[custom-specifications]
| Specifications | |
| Manufacturer | GIGABYTE Technology, Inc |
| Manufacturer Part Number | MC13-LE0 |
| Manufacturer Website Address | http://www.gigabyte.com |
| Brand Name | Gigabyte |
| Product Model | MC13-LE0 |
| Product Name | MC13-LE0 Workstation Motherboard |
| Product Type | Workstation Motherboard |
| Processor & Chipset | |
| Chipset Manufacturer | AMD |
| Chipset Model | B650E |
| Total Processor Supported | 1 |
| Processor Socket | Socket AM5 |
| Processor Supported | EPYC,Ryzen 7 |
| Memory | |
| Number of Memory Slots | 4 |
| Memory Form Factor | DIMM,UDIMM |
| Maximum Memory Supported | 128 GB |
| Memory Speed Supported | 5200 MHz,3600 MHz |
| Memory Technology | DDR5 SDRAM |
| I/O Controller | |
| Controller Type | Serial ATA/600 |
| RAID Supported | Yes |
| RAID Levels | 0,1,10 |
| Video | |
| Onboard Video | CPU Dependent Video |
| Graphics Controller Model | AST2600 |
| Network & Communication | |
| Gigabit Ethernet | Yes |
| I/O Expansions | |
| Total Number of Expansion Slots | 2 |
| Total Number of PCI Express Slots | 2 |
| Number of PCI Express x4 Slots | 1 |
| Number of PCI Express x16 Slots | 1 |
| PCI Express Standard | PCI Express 5.0,PCI Express 4.0 |
| Interfaces/Ports | |
| Total Number of USB Ports | 2 |
| Number of USB 3.2 Gen 1 Type-A Ports | 2 |
| VGA | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Onboard Interfaces | |
| Number of SATA Interfaces | 4 |
| Number of M.2 Interfaces | 1 |
| Total Number of Onboard USB Ports | 5 |
| Number of Onboard USB 2.0 Ports | 2 |
| Physical Characteristics | |
| Form Factor | Micro ATX |
| Width | 9.61" (244 mm) |
| Depth | 9.61" (244 mm) |
| Miscellaneous | |
| Environmental Compliance | China Restriction of Hazardous Substances (China RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
