Grandstream GSC3620 2MP Indoor/Outdoor Full HD Network Dome Camera - Varifocal Lens - 82 ft IR Night Vision - IP67 - PoE/DC
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This camera utilizes a 2-megapixel CMOS sensor that balances power efficiency with high-definition video capture. It supports H.264 and H.265 compression formats alongside JPEG and MJPEG, enabling efficient bandwidth usage and storage management. The varifocal lens offers a focal length range from 2.8 mm to 12 mm, allowing precise adjustment of the viewing angle and zoom level during installation.
Network connectivity is handled through a wired RJ-45 interface with support for Power over Ethernet (PoE) and traditional 12 V DC power inputs. Remote management capabilities facilitate configuration and monitoring from centralized video management systems. The camera's dual-stream functionality enables simultaneous recording at different resolutions for live viewing and archival purposes.
This section brings together practical product details such as HD Recording, Recording Formats, Night Vision, Image Sensor Type, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The dome form factor provides discreet surveillance while offering vandal resistance. Advanced video analytics including motion detection and privacy masking enhance security monitoring without requiring additional hardware. HTTPS encryption ensures secure data transmission, protecting footage from unauthorized access.
Superior Low-Light Performance
Equipped with two infrared LEDs and a removable IR cut-off filter, the GSC3620 automatically transitions between day and night modes to maintain image clarity. The 82-foot night vision range ensures reliable monitoring in darkness, supported by features like white balance and wide dynamic range to handle challenging lighting conditions.
Robust Environmental Durability
With an IP67 ingress protection rating, this camera is fully dust-tight and protected against temporary immersion in water. It operates reliably in temperatures from -4°F to 140°F and up to 95% humidity, making it suitable for outdoor installations in varying climates without additional housing.
Deployment / Use Cases
This camera integrates with Grandstream's video management systems and compatible third-party NVRs for scalable surveillance solutions. The ceiling mount design facilitates installation in standard indoor locations or under eaves for outdoor coverage. Its compact 4.25-inch height and 720-gram weight make it manageable for various mounting scenarios without requiring heavy support structures.
Business Perimeter Security
Deploy the GSC3620 at entry points, parking lots, or building exteriors where weather resistance and night vision are critical. The varifocal lens allows customization of the field of view to cover specific areas, while PoE support simplifies installation by combining power and data over a single cable.
Retail & Commercial Monitoring
Install in retail stores, warehouses, or office environments to monitor customer activity, inventory areas, or employee access points. The dome design blends with ceiling architecture, and features like dual streaming enable both live monitoring and high-quality recording for incident review.
Physical Profile
The GSC3620 features a compact dome enclosure measuring 4.25 inches (108 mm) in height with a weight of approximately 720 grams. The weatherproof construction includes a durable housing that protects internal components from dust, moisture, and physical impacts. The ceiling mount design allows for secure installation on standard surfaces, with the varifocal lens accessible for field adjustment during setup.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 4.25" (108 mm), 720 g. This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Height
- 4.25" (108 mm)
- Weight
- 720 g
- Length
- 2.8 mm
Highlights
- 2-megapixel CMOS sensor delivers Full HD 1080p video quality
- Infrared night vision with 82-foot (25 m) range for 24/7 monitoring
- Varifocal lens (2.8-12 mm) provides adjustable field of view
- IP67 weatherproof rating for reliable indoor/outdoor operation
- Supports Power over Ethernet (PoE) and 12 V DC power inputs
- Advanced features include motion detection, privacy masking, and wide dynamic range
- Dual streaming enables simultaneous live viewing and recording
- Operating temperature range from -4°F to 140°F (-20°C to 60°C)
- HTTPS encryption ensures secure video transmission
- Compact dome design with ceiling mount for discreet installation
Specifications
| Specifications | |
|---|---|
| Manufacturer | Grandstream Networks, Inc |
| Manufacturer Part Number | GSC3620 |
| Brand Name | Grandstream |
| Product Model | GSC3620 |
| Product Name | Infrared Weatherproof Varifocal and Auto-Focus Dome Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Recording Formats | Full HD |
| Night Vision | Yes |
| Night Vision Distance | 82.02 ft (25 m) |
| Night Vision Type | Infrared |
| Number of IR LEDs | 2 |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Color Supported | Color |
| Effective Camera Resolution | 2 Megapixel |
| Video | |
| Video Formats | H.264,H.265,JPEG,MJPEG |
| Maximum Video Resolution | 1920 x 1080 |
| Lens | |
| Lens Type | Varifocal |
| Minimum Focal Length | 2.8 mm |
| Maximum Focal Length | 12 mm |
| Lens Included | Yes |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Input Voltage | 12 V DC |
| Power Source Type | PoE,DC |
| Physical Characteristics | |
| Mount Type | Ceiling Mount |
| Form Factor | Dome |
| Durability | Weather Proof |
| Height | 4.25" (108 mm) |
| Weight (Approximate) | 720 g |
| Environmental Conditions | |
| Minimum Operating Temperature | -4°F (-20°C) |
| Maximum Operating Temperature | 140°F (60°C) |
| Maximum Operating Humidity | 95% |
| Miscellaneous | |
| Features | Wide Dynamic Range,Motion Detection,Video Management System,White Balance,Dual Stream,HTTPS Encryption,Day/Night,Removable IR Cut-off Filter,Privacy Masking |
| Indoor/Outdoor | Indoor/Outdoor |
| Ingress Protection Rating | IP67 |
User Manual
FAQ
What is the maximum video resolution of the Grandstream GSC3620 camera?
The GSC3620 captures video at a maximum resolution of 1920 x 1080 pixels, which is Full HD quality. This 2-megapixel resolution provides clear, detailed imagery suitable for identifying faces, license plates, and other important details in surveillance applications.
How far does the night vision reach on this camera?
The infrared night vision system illuminates objects up to 82.02 feet (25 meters) in complete darkness. It utilizes two IR LEDs and automatically switches between day and night modes using a removable IR cut-off filter to maintain optimal image quality in low-light conditions.
Can this camera be used outdoors in harsh weather conditions?
Yes, the GSC3620 is rated IP67 for dust and water resistance, making it suitable for outdoor installation. It operates reliably in temperatures from -4°F to 140°F (-20°C to 60°C) and up to 95% humidity, ensuring consistent performance in various weather conditions without requiring additional protective housing.
What power options are available for this network camera?
The camera supports both Power over Ethernet (PoE) and traditional 12 V DC power inputs. PoE allows installation with a single network cable that carries both data and power, simplifying deployment in locations without convenient power outlets. The dual power options provide flexibility for different installation scenarios.
What type of lens does this camera have and is it adjustable?
The GSC3620 features a varifocal lens with an adjustable focal length range from 2.8 mm to 12 mm. This allows installers to customize the field of view during setup, providing flexibility to cover wide areas or zoom in on specific points of interest without changing hardware.
What video management features does this camera support?
The camera includes motion detection, privacy masking, dual streaming, and wide dynamic range capabilities. It supports H.264 and H.265 compression formats for efficient bandwidth usage and integrates with Grandstream's video management systems and compatible third-party NVRs for comprehensive surveillance solutions.
What connectivity or interface options are available?
Connectivity options include Wired, helping the product integrate into common office or home setups.
