Gyration CYBERVIEW 410D-TAA 4MP Outdoor Dome Network Camera - 2688 x 1520 HD - 131. 23 ft IR Night Vision - IP67 - TAA Compliant
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The CYBERVIEW 410D-TAA leverages a 4-megapixel CMOS sensor to produce high-quality HD video, balancing power efficiency with superior image clarity compared to traditional CCD sensors. Video output reaches up to 2688 x 1520 resolution at 30 frames per second, providing smooth and detailed surveillance footage. The camera supports multiple compression formats, including H.265 and Ultra 265 for efficient bandwidth and storage utilization.
Advanced imaging features enhance performance in challenging lighting. Wide Dynamic Range (WDR) compensates for backlight and high-contrast scenes, while 2D and 3D Digital Noise Reduction (DNR) minimize grain in low-light conditions. The fixed lens offers a 2.8 mm focal length with a maximum aperture of f/1.6, ensuring ample light intake. Exposure control ranges from 1/100,000 second to 1 second, allowing precise adjustment for fast-moving objects or prolonged low-light capture.
Key Product Advantages
This camera combines high-resolution imaging with robust construction for versatile security applications. The dome form factor offers a discreet profile and vandal resistance, while the 3-axis adjustable mount simplifies precise positioning during installation. Integrated intelligence features like cross-line detection, privacy masking, and tampering alarm reduce false alerts and enhance monitoring efficiency.
Extended Night Vision Coverage
Infrared illumination provides clear monochrome video up to 131.23 feet (40 meters) in total darkness, ensuring reliable 24/7 surveillance without additional lighting.
Rugged Environmental Design
IP67 rating guarantees protection against dust ingress and temporary immersion in water, while the operating range of -22°F to 140°F (-30°C to 60°C) ensures functionality in extreme weather.
Deployment / Use Cases
The CYBERVIEW 410D-TAA is designed for scenarios requiring dependable, high-definition surveillance with minimal maintenance. Its wired connectivity and 12V DC power input make it suitable for integration into existing network video recorder (NVR) systems or standalone setups with local SD card storage.
Common applications include retail store monitoring, school campus security, transportation hubs, and critical infrastructure protection. The camera's audio detection and built-in microphone enable audio monitoring, while features like region of interest (ROI) and digital defog optimize video quality in specific zones or adverse weather conditions.
Perimeter and Entryway Surveillance
Install at building entrances, gates, or parking lots to monitor activity with high-resolution video and long-range night vision, leveraging motion detection and tampering alarms for security alerts.
Industrial and Outdoor Facilities
Deploy in warehouses, construction sites, or remote outdoor areas where IP67 protection and wide temperature tolerance ensure continuous operation despite dust, rain, or temperature extremes.
Physical Profile
The dome camera measures 2.47" (62.70 mm) in height, 2.48" (63.10 mm) in width, and 6.14" (155.90 mm) in length, with an approximate weight of 14.82 oz (420 g). Its compact and low-profile design facilitates discreet mounting on ceilings or walls, while the 3-axis adjustable mechanism allows for precise alignment of the viewing angle. The durable housing resists environmental wear, supporting long-term installation in exposed locations.
- Width
- 2.48" (63.10 mm)
- Height
- 2.47" (62.70 mm)
- Weight
- 14.82 oz (420 g)
- Length
- 2.8 mm (0.11")
Highlights
- 4-megapixel resolution for detailed 2688 x 1520 HD video
- Infrared night vision effective up to 131.23 feet (40 meters)
- IP67-rated weatherproof and waterproof dome housing
- Wide dynamic range and digital noise reduction for clear imaging
- Supports H.264, H.265, Ultra 265, and MJPEG video formats
- Fixed 2.8 mm lens with f/1.6 aperture for low-light performance
- 3-axis adjustable mount for flexible installation angles
- TAA compliant for government and institutional procurement
- Operating temperature range of -22°F to 140°F (-30°C to 60°C)
- Built-in microphone and audio detection capabilities
Specifications
| Specifications | |
|---|---|
| Manufacturer | Adesso, Inc |
| Manufacturer Part Number | CYBERVIEW 410D-TAA |
| Brand Name | Gyration |
| Product Model | CYBERVIEW 410D-TAA |
| Product Name | 4 MP Outdoor Intelligent Fixed Dome Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Recording Formats | HD |
| Night Vision | Yes |
| Night Vision Distance | 131.23 ft (40 m) |
| Night Vision Type | Infrared |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Color Supported | Color |
| Field of View | Angle of View (H) 101.1°, Angle of View (V) 55.3°, Angle of View (O) 111.1° |
| Effective Camera Resolution | 4 Megapixel |
| Video | |
| Video Formats | H.264,H.265,Ultra 265,MJPEG |
| Maximum Video Resolution | 2688 x 1520 |
| Maximum Frame Rate | 30 fps |
| Lens | |
| Lens Type | Fixed |
| Maximum Focal Length | 2.8 mm (0.11") |
| Lens Included | Yes |
| Maximum Aperture | f/1.6 |
| Exposure | |
| Shortest Shutter Speed | 1/100000 Second |
| Longest Shutter Speed | 1 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Storage | |
| Storage Type | Memory Card |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Input Voltage | 12 V DC |
| Physical Characteristics | |
| Form Factor | Dome |
| Durability | Weather Resistant,Water Proof |
| Height | 2.47" (62.70 mm) |
| Width | 2.48" (63.10 mm) |
| Length | 6.14" (155.90 mm) |
| Weight (Approximate) | 14.82 oz (420 g) |
| Environmental Conditions | |
| Minimum Operating Temperature | -22°F (-30°C) |
| Maximum Operating Temperature | 140°F (60°C) |
| Maximum Operating Humidity | 95% |
| Miscellaneous | |
| Features | Cross Line Detection,Wide Dynamic Range,Built-in Microphone,SD Card Local Storage,3-Axis Adjustable,Day/Night,2D Digital Noise Reduction (2DNR),3D Digital Noise Reduction,Digital Noise Reduction,Digital Defog,Built-in OSD Function,Privacy Masking,Region of Interest,Motion Detection,Highlight Compensation (HLC),Back Light Compensation (BLC),Tampering Alarm,Audio Detection,Surge Protection,Face Detection |
| Indoor/Outdoor | Indoor/Outdoor |
| Ingress Protection Rating | IP67 |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 1 Year |
User Manual
FAQ
What is the maximum video resolution of the Gyration CYBERVIEW 410D-TAA camera?
The camera delivers high-definition video at a maximum resolution of 2688 x 1520 pixels. This 4-megapixel capability provides detailed imagery suitable for identifying faces, license plates, and other critical details in surveillance footage, ensuring clear monitoring for security applications.
How far does the night vision reach on this network camera?
Infrared night vision covers distances up to 131.23 feet (40 meters) in complete darkness. This extended range allows for reliable 24/7 surveillance in outdoor areas like parking lots, perimeters, or dimly lit interiors without requiring additional external lighting.
Is the Gyration CYBERVIEW 410D-TAA suitable for outdoor installation?
Yes, this camera is designed for both indoor and outdoor use. It features an IP67 ingress protection rating, making it dust-tight and waterproof against temporary immersion. The dome housing is weather resistant, and it operates in temperatures from -22°F to 140°F (-30°C to 60°C), ensuring durability in harsh environments.
What video compression formats does this camera support?
It supports multiple video formats including H.264, H.265, Ultra 265, and MJPEG. H.265 and Ultra 265 offer efficient compression, reducing bandwidth and storage requirements while maintaining high video quality, which is beneficial for network-based surveillance systems with limited resources.
Does this camera include remote management capabilities?
Yes, the CYBERVIEW 410D-TAA supports remote management over a wired network connection. This allows administrators to configure settings, view live feeds, and manage recordings from a central location using compatible network video recorder (NVR) software or web interfaces, enhancing operational flexibility.
What is the significance of TAA compliance for this camera?
TAA compliance indicates that the camera meets the Trade Agreements Act requirements, meaning it is manufactured in a designated country like Taiwan. This makes it eligible for procurement by U.S. federal government agencies and many institutional buyers who mandate TAA-compliant products for contracts and projects.
What storage is included?
The system includes Memory Card of storage for applications, files, and everyday business data.
