Gyration CYBERVIEW 412D 4MP Indoor/Outdoor Wedge Dome Network Camera - Color - 98. 43 ft IR Night Vision - 2688 x 1520 - IP67 IK10
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This camera utilizes a 4-megapixel CMOS image sensor that balances cost-efficiency with power consumption, delivering superior HD video quality. It supports modern video compression formats including H.264, H.265, and Ultra 265, optimizing bandwidth usage and storage efficiency without compromising detail. The fixed f/1.6 aperture lens ensures strong low-light performance, while shutter speeds from 1/100,000 second to 1 second adapt to varying light conditions.
Network connectivity is provided through a standard RJ-45 port for wired Ethernet installation, supporting remote management and configuration. Local storage is facilitated via a memory card slot, offering flexibility for standalone operation or backup recording. The camera's 12 V DC power input aligns with common surveillance power supplies, simplifying deployment in both new and retrofit installations.
Key Product Advantages
The CYBERVIEW 412D integrates multiple advanced features that enhance surveillance effectiveness and reduce total cost of ownership. Wide Dynamic Range compensates for backlight and high-contrast scenes, preserving detail in both bright and shadowed areas. Privacy masking and region-of-interest (ROI) encoding allow operators to block sensitive areas or prioritize bandwidth for critical zones.
Superior Low-Light Performance
Infrared illuminators provide clear monochrome video up to 98.43 feet in total darkness, while features like digital defog and 2D/3D noise reduction ensure usable footage in fog, smoke, or low-contrast conditions.
Intelligent Video Analytics
Built-in analytics include motion detection, audio detection, face detection, cross-line detection, and tampering alarm, reducing false alerts and focusing operator attention on genuine security events.
Environmental Hardening
The IP67 rating guarantees protection against dust ingress and temporary immersion, while the IK10 impact resistance withstands deliberate strikes up to 20 joules, making it suitable for high-risk locations.
Deployment / Use Cases
This camera is designed for versatile deployment across commercial, industrial, and institutional settings where reliable 24/7 monitoring is required. Its indoor/outdoor rating and rugged construction make it ideal for perimeter security, entrance monitoring, warehouse oversight, and retail loss prevention.
Common installation scenarios include mounting under eaves, on walls, or on ceilings in parking garages, loading docks, school campuses, and office building lobbies. The wedge dome form factor provides a discreet profile that blends with architectural elements while deterring tampering. The camera's support for SD card storage enables standalone operation in locations without continuous network recorder access, serving as a primary or backup recording solution.
Physical Profile
The CYBERVIEW 412D features a compact wedge dome enclosure measuring 2.40 inches in height and 4.33 inches in diameter, with a weight of approximately 13.05 ounces. This streamlined design facilitates installation on various surfaces without obtrusive protrusion. The housing's 3-axis adjustable mount allows precise aiming during setup, ensuring optimal coverage alignment. The finish is designed for durability against UV exposure and chemical corrosion, maintaining appearance and function in outdoor environments over extended periods.
- Height
- 2.40" (61 mm)
- Weight
- 13.05 oz (370 g)
- Length
- 2.8 mm (0.11")
Highlights
- 4-megapixel resolution delivers detailed 2688 x 1520 HD video
- Infrared night vision effective up to 98.43 feet (30 meters)
- IP67 weatherproof and IK10 vandal-resistant construction
- Wide 111.1° diagonal field of view for broad coverage
- Supports H.265, H.264, and Ultra 265 video compression
- Built-in analytics: motion detection, face detection, audio detection
- Local storage via memory card slot for flexible recording
- Operates in temperatures from -22°F to 140°F (-30°C to 60°C)
- 12 V DC power input compatible with standard surveillance supplies
- RoHS compliant and backed by a 1-year limited warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | Adesso, Inc |
| Manufacturer Part Number | CYBERVIEW 412D |
| Brand Name | Gyration |
| Product Model | CYBERVIEW 412D |
| Product Name | 4 MP Outdoor Intelligent Fixed Dome Wedge Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Recording Formats | HD |
| Night Vision | Yes |
| Night Vision Distance | 98.43 ft (30 m) |
| Night Vision Type | Infrared |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Color Supported | Color |
| Field of View | Angle of View (H) 101.1°, Angle of View (V) 55.3°, Angle of View (O) 111.1° |
| Effective Camera Resolution | 4 Megapixel |
| Video | |
| Video Formats | H.264,H.265,Ultra 265,MJPEG |
| Maximum Video Resolution | 2688 x 1520 |
| Maximum Frame Rate | 30 fps |
| Lens | |
| Lens Type | Fixed |
| Maximum Focal Length | 2.8 mm (0.11") |
| Lens Included | Yes |
| Maximum Aperture | f/1.6 |
| Exposure | |
| Shortest Shutter Speed | 1/100000 Second |
| Longest Shutter Speed | 1 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Storage | |
| Storage Type | Memory Card |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Input Voltage | 12 V DC |
| Physical Characteristics | |
| Form Factor | Wedge Dome |
| Durability | Weather Resistant,Vandal Resistant,Water Proof |
| Height | 2.40" (61 mm) |
| Diameter | 4.33" (110 mm) |
| Weight (Approximate) | 13.05 oz (370 g) |
| Environmental Conditions | |
| Minimum Operating Temperature | -22°F (-30°C) |
| Maximum Operating Temperature | 140°F (60°C) |
| Maximum Operating Humidity | 95% |
| Miscellaneous | |
| Features | Cross Line Detection,Wide Dynamic Range,Built-in Microphone,SD Card Local Storage,3-Axis Adjustable,Day/Night,2D Digital Noise Reduction (2DNR),3D Digital Noise Reduction,Digital Noise Reduction,Digital Defog,Built-in OSD Function,Privacy Masking,Region of Interest,Motion Detection,Highlight Compensation (HLC),Back Light Compensation (BLC),Tampering Alarm,Audio Detection,Surge Protection,Face Detection |
| Indoor/Outdoor | Indoor/Outdoor |
| Impact Protection Rating | IK10 |
| Ingress Protection Rating | IP67 |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 1 Year |
User Manual
FAQ
What is the maximum video resolution of the Gyration CYBERVIEW 412D camera?
The camera captures video at up to 4-megapixel resolution, specifically 2688 x 1520 pixels. This high-definition format provides clear, detailed imagery suitable for identifying faces, license plates, and other critical details in surveillance footage, supporting both live monitoring and forensic review.
How far does the night vision work on this camera?
The built-in infrared illuminators provide effective night vision up to 98.43 feet (30 meters) in total darkness. This allows the camera to deliver usable monochrome video in low-light or no-light conditions, ensuring continuous monitoring capability around the clock for perimeter security and outdoor areas.
Is this camera suitable for outdoor installation?
Yes, the CYBERVIEW 412D is rated IP67 for ingress protection, meaning it is dust-tight and can withstand temporary immersion in water. Combined with its IK10 impact resistance and operating temperature range of -22°F to 140°F, it is fully engineered for reliable outdoor use in various weather conditions and environments.
What type of lens does this camera have?
It features a fixed 2.8 mm lens with a maximum aperture of f/1.6. This fixed focal length provides a consistent field of view, ideal for covering specific areas like entrances or corridors, while the wide aperture enhances low-light performance by allowing more light to reach the sensor.
Does the camera support local storage without a network video recorder?
Yes, it includes a memory card slot for local storage, enabling standalone recording directly to an SD card. This feature provides flexibility for installations where continuous NVR connectivity is unavailable or as a backup recording solution, ensuring video retention even during network interruptions.
What video compression formats are supported?
The camera supports H.264, H.265, Ultra 265, and MJPEG formats. H.265 and Ultra 265 offer advanced compression efficiency, reducing bandwidth and storage requirements by up to 50% compared to H.264 while maintaining high video quality, which is beneficial for network performance and cost-effective storage management.
What storage is included?
The system includes Memory Card of storage for applications, files, and everyday business data.
