Hikvision DS-2CD2545FWD-I 4MM EasyIP 3. 0 4MP Mini Dome Network Camera - 2688 x 1520 Resolution - 32. 8ft Night Vision - Fixed 4mm Lens
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This camera captures 4-megapixel video at a maximum resolution of 2688 x 1520, supporting both NTSC and PAL signal formats. It uses advanced video compression with H.264+, H.265+, and standard H.264/H.265 codecs, along with MJPEG, to balance quality and bandwidth efficiency. The CMOS sensor enhances HD video performance while reducing power consumption, making it a cost-effective choice for continuous surveillance.
Network connectivity is wired via RJ-45, ensuring stable data transmission and PoE compatibility for simplified installation. Remote management capabilities allow administrators to configure and monitor the camera from a central location, supporting integration into larger security systems.
This section brings together practical product details such as HD Recording, Recording Formats, Night Vision Distance, Image Sensor Type, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The DS-2CD2545FWD-I 4MM combines high-resolution imaging with practical surveillance features, offering clear advantages for security deployments. Its 4-megapixel sensor and advanced compression deliver detailed footage without excessive storage demands, while the fixed lens minimizes maintenance and ensures consistent field of view.
Enhanced Low-Light Performance
Infrared night vision extends monitoring capability to 32.8 feet, providing reliable coverage in darkness or low-light environments.
- CMOS sensor efficiency
- Integrated IR LEDs
- 10-meter range
Streamlined Installation
The mini dome design and junction box mount facilitate quick, discreet mounting on ceilings or walls, reducing installation time and visual intrusion.
- Compact form factor
- Standard mount compatibility
- PoE-ready wiring
Deployment / Use Cases
This camera is ideal for small to medium-sized surveillance setups where high-definition video and discreet installation are priorities. Its 4MP resolution and wide dynamic range make it suitable for monitoring entrances, corridors, or retail spaces where detail capture is critical for identification or incident review.
Common applications include office security, retail loss prevention, residential property monitoring, and educational facility surveillance. The wired connectivity and remote management support integration with NVRs or VMS platforms, enabling scalable security solutions for businesses or institutional environments.
Retail & Commercial Monitoring
Deploy in stores or offices to deter theft and monitor customer or employee activity with clear color video during day and night.
Residential Security
Install in homes or apartments for perimeter surveillance, leveraging the compact dome design to blend with interior decor while providing reliable coverage.
Physical Profile
The camera measures 2.20 inches (55.88 mm) in height and 4.30 inches (109.22 mm) in diameter, with an approximate weight of 400 grams. Its mini dome form factor and white housing offer a low-profile appearance suitable for indoor ceilings or walls. The junction box mount ensures secure attachment and easy alignment for optimal viewing angles.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 2.20" (55.88 mm), 400 g. This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Height
- 2.20" (55.88 mm)
- Weight
- 400 g
- Length
- 4 mm
Highlights
- 4-megapixel resolution for detailed 2688 x 1520 video capture
- Night vision up to 32.8 feet (10 meters) with infrared LEDs
- Fixed 4mm lens provides consistent wide-angle coverage
- Supports H.264, H.265, H.265+, and MJPEG compression formats
- CMOS sensor for efficient power use and enhanced HD video
- Wired connectivity via RJ-45 with PoE compatibility
- Remote management capability for centralized control
- Mini dome form factor with junction box mount for discreet installation
Specifications
| Specifications | |
|---|---|
| Manufacturer | Hikvision |
| Manufacturer Part Number | DS-2CD2545FWD-I 4MM |
| Brand Name | Hikvision |
| Product Line | EasyIP 3.0 |
| Product Model | DS-2CD2545FWD-I |
| Product Name | 4 MP IR Fixed Mini Dome Network Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Recording Formats | HD |
| Night Vision Distance | 32.81 ft (10 m) |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Color Supported | Color |
| Effective Camera Resolution | 4 Megapixel |
| Video | |
| Video Formats | MJPEG,H.264+,H.264,H.265,H.265+ |
| Maximum Video Resolution | 2688 x 1520 |
| Video Signal Format | NTSC,PAL |
| Lens | |
| Lens Type | Fixed |
| Maximum Focal Length | 4 mm |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Physical Characteristics | |
| Mount Type | Junction Box Mount |
| Form Factor | Mini Dome |
| Height | 2.20" (55.88 mm) |
| Diameter | 4.30" (109.22 mm) |
| Weight (Approximate) | 400 g |
User Manual
FAQ
What is the maximum video resolution of this camera?
The Hikvision DS-2CD2545FWD-I 4MM captures video at up to 2688 x 1520 resolution, which is 4 megapixels. This high definition provides clear, detailed imagery suitable for identifying faces, license plates, or other critical details in surveillance footage.
How far does the night vision reach?
The camera's infrared night vision effectively covers distances up to 32.81 feet (10 meters). This allows for reliable monitoring in low-light or complete darkness, making it ideal for 24/7 security applications in indoor environments like warehouses, offices, or hallways.
What type of lens does this camera have?
It features a fixed 4mm lens, which offers a consistent field of view without the need for adjustment. Fixed lenses are low-maintenance and provide reliable coverage for general surveillance areas, reducing complexity in installation and operation.
What video compression formats are supported?
This camera supports multiple compression formats including MJPEG, H.264, H.264+, H.265, and H.265+. These options allow for flexible bandwidth and storage management, with H.265+ offering advanced efficiency for reducing file sizes while maintaining video quality.
How is the camera connected and powered?
It uses wired connectivity via an RJ-45 Ethernet port, which supports Power over Ethernet (PoE) for simplified installation. This single-cable solution provides both data transmission and power, reducing wiring clutter and enabling integration with standard network infrastructure.
What mounting options are available?
The camera is designed for junction box mounting, making it easy to install on ceilings or walls. Its mini dome form factor is compact and discreet, suitable for indoor environments where a low-profile appearance is desired to blend with surroundings.
What connectivity or interface options are available?
Connectivity options include Wired, helping the product integrate into common office or home setups.
