Honeywell 1990IXLR-3-AIT-N Granit XP 1990iXR Ultra-Rugged Area-Imaging Scanner - Cable Connectivity - 32. 81 ft - 10000 mm Scan Distance - 1D - 2D
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The Granit XP 1990iXR incorporates advanced imaging technology with a 40° horizontal and 30° vertical field of view, enabling broad scanning coverage without precise alignment. The scanner maintains reading accuracy across extreme angles with 65° skew, 45° pitch, and 360° roll tolerance, ensuring reliable performance even when barcodes are tilted or positioned awkwardly.
With motion tolerance up to 177 inches per second (4495.80 mm/s), this scanner captures fast-moving items on conveyor belts or during manual scanning operations. The imager sensor achieves minimum element resolution of 5 mil (0.13 mm) for Code 39 barcodes and supports various barcode types including DataMatrix and PDF417 with specific resolution capabilities.
This section brings together practical product details such as Connectivity Technology, Scanning Capability, Image Sensor Type, Host Interface, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The Granit XP 1990iXR stands out with its combination of extended scanning range, exceptional durability, and industrial-focused features. Unlike standard handheld scanners, this model is built to withstand repeated drops, extreme temperatures, and harsh environmental conditions while maintaining scanning accuracy.
Military-Grade Durability
Tested to MIL-STD-810G standards with IP67/IP65 ratings for dust and water resistance, plus multiple drop specifications including 50 drops from 2 meters across temperature extremes.
- IP67/IP65 rated
- MIL-STD-810G compliant
- Extended temperature operation
Extended Scanning Range
Achieves scanning distances up to 32.81 feet (10,000 mm) with precise barcode capture, reducing the need for close proximity scanning in warehouse and industrial settings.
- 32.81 ft maximum distance
- Wide field of view
- High motion tolerance
Industrial Connectivity
Supports multiple host interfaces including keyboard wedge, USB, and serial connections for seamless integration with existing industrial systems and equipment.
- Keyboard wedge support
- USB connectivity
- Serial interface
Deployment / Use Cases
The Honeywell Granit XP 1990iXR is specifically designed for industrial environments where scanning equipment faces physical abuse, environmental extremes, and demanding operational requirements. Its extended scanning range and rugged construction make it suitable for applications where standard scanners would quickly fail or require frequent replacement.
In warehouse and logistics operations, the scanner handles inventory management, shipping verification, and receiving processes where barcodes may be located at height or distance. Manufacturing facilities benefit from its durability on production lines, quality control stations, and tool crib management. Outdoor applications including construction sites, transportation yards, and field service operations leverage its environmental resistance and long-range capabilities.
Physical Profile
The handheld form factor measures 7.56 inches (192 mm) in length, 2.99 inches (76 mm) in width, and 3.94 inches (100 mm) in height, providing an ergonomic design for extended use. Weighing approximately 11.29 ounces (320 g), the scanner balances durability with comfortable handling during shift-long operations. The rugged construction includes reinforced housing and impact-resistant materials that withstand the physical demands of industrial environments.
- Width
- 2.99" (76 mm)
- Height
- 3.94" (100 mm)
- Weight
- 11.29 oz (320 g)
- Length
- 7.56" (192 mm)
Highlights
- Ultra-rugged construction with IP67/IP65 rating for dust and water resistance
- Extended scanning distance up to 32.81 feet (10000 mm) for long-range applications
- 1D and 2D barcode scanning capability with area-imaging technology
- Military-grade durability tested to MIL-STD-810G standards
- Wide operating temperature range from -22°F to 122°F (-30°C to 50°C)
- Multiple host interfaces: keyboard wedge, USB, and serial connectivity
- Industrial application focus with TAA compliance for government contracts
- High motion tolerance up to 177 in/s for fast-moving items
- User feedback features including beep, notification LED, and vibration
- 3-year limited warranty for long-term reliability assurance
Specifications
| Specifications | |
|---|---|
| Manufacturer | Honeywell International, Inc |
| Manufacturer Part Number | 1990IXLR-3-AIT-N |
| Brand Name | Honeywell |
| Product Line | Granit XP |
| Product Series | 1990iXR |
| Product Name | Granit XP 1990iXR Ultra-Rugged Area-Imaging Scanner |
| Product Type | Barcode Scanner |
| Technical Information | |
| Connectivity Technology | Cable |
| Scanning Capability | 1D,2D |
| Image Sensor Type | Imager |
| Scanner Range | Long Range |
| Scanning Distance | 32.81 ft (10000 mm) |
| Field of View (Horizontal) | 40° |
| Field of View (Vertical) | 30° |
| Reading Angle (Skew) | 65° |
| Reading Angle (Pitch) | 45° |
| Reading Angle (Roll) | 360° |
| Motion Tolerance | 177 in/s (4495.80 mm/s) |
| Maximum Ambient Light | 100000 lux |
| Drop Specification | 2 m (6.5 ft): 50 drops from -30°C to 50°C (-22°F to 122°F), uncontrolled RH 2.4 m (8 ft): 20 drops at 25°C (77°F), 55% RH 3 m (10 ft): MIL-STD-810G, 25°C (77°F), 55% RH |
| Minimum Print Contrast | 20% |
| Minimum Element Resolution (Code 39) | 5 mil (0.13 mm) |
| Maximum Element Resolution (Code 39) | 100 mil (2.54 mm) |
| Maximum Element Resolution (DataMatrix) | 10 mil (0.25 mm) |
| Maximum Element Resolution (PDF417) | 6.70 mil (0.17 mm) |
| Features | Beep,Notification LED,Vibration |
| Interfaces/Ports | |
| Host Interface | Keyboard Wedge,USB,Serial |
| Environmental Conditions | |
| Operating Temperature | -22°F (-30°C) to 122°F (50°C) |
| Storage Temperature | -40°F (-40°C) to 150°F (65.6°C) |
| Humidity (Non-condensing) | 95% |
| Physical Characteristics | |
| Form Factor | Handheld |
| Rugged | Yes |
| Height | 3.94" (100 mm) |
| Width | 2.99" (76 mm) |
| Length | 7.56" (192 mm) |
| Weight (Approximate) | 11.29 oz (320 g) |
| Miscellaneous | |
| Ingress Protection (IP) Rating | IP67,IP65 |
| Application/Usage | Industrial |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What is the maximum scanning distance for this Honeywell scanner?
The Honeywell Granit XP 1990iXR achieves a maximum scanning distance of 32.81 feet (10,000 mm), making it suitable for long-range applications in warehouses, manufacturing facilities, and outdoor environments where barcodes may be positioned at height or distance from the operator.
What types of barcodes can this scanner read?
This area-imaging scanner reads both 1D and 2D barcodes, including common formats like Code 39, DataMatrix, and PDF417. It supports minimum element resolutions from 5 mil (0.13 mm) for Code 39 up to 100 mil (2.54 mm), providing flexibility for various barcode sizes and printing qualities.
How durable is this scanner for industrial environments?
The Granit XP 1990iXR features ultra-rugged construction with IP67/IP65 ingress protection against dust and water. It's tested to MIL-STD-810G standards with multiple drop specifications, including 50 drops from 2 meters across temperature extremes, ensuring reliable performance in harsh industrial conditions.
What connectivity options does this scanner support?
This cable-connected scanner supports multiple host interfaces including keyboard wedge, USB, and serial connections. This flexibility allows integration with various industrial systems, point-of-sale equipment, and legacy hardware without requiring additional adapters or interface modules.
What environmental conditions can this scanner operate in?
The scanner operates in temperatures from -22°F to 122°F (-30°C to 50°C) and withstands up to 95% non-condensing humidity. It tolerates maximum ambient light up to 100,000 lux and maintains scanning accuracy across wide reading angles, making it suitable for both indoor and outdoor industrial applications.
What warranty comes with this Honeywell scanner?
Honeywell provides a 3-year limited warranty for the Granit XP 1990iXR scanner, covering defects in materials and workmanship. This warranty period reflects the product's industrial-grade construction and reliability expectations for demanding operational environments.
