Honeywell 1991IXLR-3-N Granit XP 1991iXR Wireless Ultra-Rugged Area-Imaging Scanner - 32. 81 ft (10000 mm) Long Range - 2D/1D - IP67/IP65
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The Granit XP 1991iXR scanner incorporates advanced optical specifications that ensure reliable scanning performance. With a 40° horizontal and 30° vertical field of view, combined with reading angles of 65° skew, 45° pitch, and 360° roll, this scanner maintains accurate reading capabilities even when barcodes are positioned at challenging angles or orientations.
The scanner handles motion tolerance up to 177 in/s (4495.80 mm/s) and operates effectively in maximum ambient light conditions of 100,000 lux. It supports barcode resolutions from 3 mil (0.08 mm) minimum to 100 mil (2.54 mm) maximum for Code 39, with specific capabilities for DataMatrix (6-10 mil) and PDF417 (6.70 mil maximum) formats. The 20% minimum print contrast requirement ensures reliable scanning across various print qualities.
This section brings together practical product details such as Connectivity Technology, Scanning Capability, Scanner Range, Bluetooth, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The Honeywell Granit XP 1991iXR scanner provides distinct advantages for operations requiring mobility, durability, and extended scanning range. Its combination of wireless freedom, rugged construction, and long-distance capability makes it a versatile solution for various scanning-intensive environments.
Extended Mobility
Wireless Bluetooth connectivity eliminates cable restrictions, allowing operators to move freely throughout scanning areas while maintaining reliable data transmission to base stations or mobile devices.
- No cable tangles
- Freedom to wander
- Bluetooth data transmission
Industrial Durability
Built to withstand demanding conditions with IP67/IP65 ingress protection, MIL-STD-810G drop compliance, and operation across extreme temperature ranges from -4°F (-20°C) to 122°F (50°C).
- IP67/IP65 rated
- MIL-STD-810G compliant
- Wide temperature range
Long-Range Precision
32.81 ft (10000 mm) scanning distance enables accurate barcode reading from significant distances, reducing the need for close proximity to scanning targets in warehouse or inventory settings.
- 32.81 ft range
- Precision at distance
- Reduced proximity requirements
Deployment / Use Cases
The Honeywell Granit XP 1991iXR scanner is designed for deployment in environments where scanning flexibility, durability, and extended range provide operational advantages. Its wireless nature and rugged construction make it suitable for applications where traditional wired scanners would be impractical or limiting.
In warehouse and distribution center environments, this scanner enables efficient inventory management from elevated positions or across wide aisles without requiring physical proximity to barcodes. Retail operations benefit from the mobility for price verification, inventory counts, and customer service applications where staff need to move freely throughout the store. Manufacturing and industrial settings utilize the scanner's durability for quality control, parts tracking, and shipping verification in environments with dust, moisture, or temperature variations.
Warehouse Inventory Management
Scan high-shelf inventory from ground level, manage warehouse receiving and shipping operations, and conduct cycle counts without ladder access or close proximity requirements.
Retail Mobility Solutions
Enable price verification, inventory management, and customer service applications with wireless freedom throughout store floors, backrooms, and receiving areas.
Physical Profile
The Granit XP 1991iXR scanner features a compact yet durable physical design measuring 7.56" (192 mm) in length, 2.99" (76 mm) in width, and 3.94" (100 mm) in height. With an approximate weight of 14.29 oz (405 g), it balances substantial rugged construction with manageable handheld operation. The ergonomic design supports extended use in scanning-intensive applications while the rugged exterior provides protection against drops, dust, and moisture ingress.
- Width
- 2.99" (76 mm)
- Height
- 3.94" (100 mm)
- Weight
- 14.29 oz (405 g)
- Length
- 7.56" (192 mm)
Highlights
- 32.81 ft (10000 mm) extended long-range scanning capability
- Wireless Bluetooth connectivity for cable-free operation
- 2D and 1D barcode scanning with area-imaging technology
- IP67/IP65 ingress protection against dust and water
- MIL-STD-810G compliant drop specification for rugged durability
- 2450 mAh Lithium Ion battery for extended operation
- Wide operating temperature range: -4°F to 122°F (-20°C to 50°C)
- 3-year limited warranty for long-term reliability
- 40° horizontal and 30° vertical field of view
- 177 in/s (4495.80 mm/s) motion tolerance for fast-moving items
Specifications
| Specifications | |
|---|---|
| Manufacturer | Honeywell International, Inc |
| Manufacturer Part Number | 1991IXLR-3-N |
| Brand Name | Honeywell |
| Product Line | Granit XP |
| Product Series | 1991iXR |
| Product Name | Granit XP 1991iXR Wireless Ultra-Rugged Area-Imaging Scanner |
| Product Type | Barcode Scanner |
| Technical Information | |
| Connectivity Technology | Wireless |
| Scanning Capability | 2D,1D |
| Scanner Range | Extended Long Range |
| Scanning Distance | 32.81 ft (10000 mm) |
| Field of View (Horizontal) | 40° |
| Field of View (Vertical) | 30° |
| Reading Angle (Skew) | 65° |
| Reading Angle (Pitch) | 45° |
| Reading Angle (Roll) | 360° |
| Motion Tolerance | 177 in/s (4495.80 mm/s) |
| Maximum Ambient Light | 100000 lux |
| Drop Specification | 2 m (6.5 ft): 50 drops from -30°C to 50°C (-22°F to 122°F), uncontrolled RH 2.4 m (8 ft): 20 drops at 25°C (77°F), 55% RH 3 m (10 ft): MIL-STD-810G, 25°C (77°F), 55% RH |
| Minimum Print Contrast | 20% |
| Minimum Element Resolution (Code 39) | 3 mil (0.08 mm) |
| Maximum Element Resolution (Code 39) | 100 mil (2.54 mm) |
| Minimum Element Resolution (DataMatrix) | 6 mil (0.15 mm) |
| Maximum Element Resolution (DataMatrix) | 10 mil (0.25 mm) |
| Maximum Element Resolution (PDF417) | 6.70 mil (0.17 mm) |
| Features | Vibration,Beep |
| Network & Communication | |
| Bluetooth | Yes |
| Battery Information | |
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Battery Capacity | 2450 mAh |
| Environmental Conditions | |
| Operating Temperature | -4°F (-20°C) to 122°F (50°C) |
| Storage Temperature | -40°F (-40°C) to 158°F (70°C) |
| Humidity (Non-condensing) | 0% to 95% |
| Physical Characteristics | |
| Rugged | Yes |
| Height | 3.94" (100 mm) |
| Width | 2.99" (76 mm) |
| Length | 7.56" (192 mm) |
| Weight (Approximate) | 14.29 oz (405 g) |
| Miscellaneous | |
| Ingress Protection (IP) Rating | IP67,IP65 |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What is the maximum scanning distance of the Honeywell Granit XP 1991iXR scanner?
The Honeywell Granit XP 1991iXR scanner provides an extended long-range scanning distance of 32.81 ft (10000 mm). This substantial range allows operators to scan barcodes from significant distances, making it particularly useful in warehouse environments, retail settings, and industrial applications where scanning high shelves or distant items is necessary without requiring physical proximity.
Does this scanner support both 2D and 1D barcode scanning?
Yes, the Honeywell Granit XP 1991iXR scanner supports both 2D and 1D barcode scanning using area-imaging technology. This dual capability enables it to read traditional linear barcodes as well as two-dimensional codes like QR codes, DataMatrix, and PDF417 formats, providing versatility across various labeling systems and industry standards.
What type of wireless connectivity does this scanner use?
This scanner utilizes Bluetooth wireless technology for connectivity. The Bluetooth capability enables cable-free operation, allowing users to move freely while scanning and transmitting data to compatible base stations, mobile devices, or computer systems. This wireless design eliminates cable tangles and provides greater mobility in scanning-intensive environments.
How durable is the Granit XP 1991iXR scanner for industrial use?
The Granit XP 1991iXR scanner is designed for industrial durability with IP67/IP65 ingress protection ratings, making it dust-tight and protected against water immersion. It complies with MIL-STD-810G drop specifications and can withstand multiple drops from various heights. The scanner operates across a wide temperature range from -4°F (-20°C) to 122°F (50°C) and handles 0% to 95% non-condensing humidity.
What is the battery capacity and chemistry of this scanner?
The Honeywell Granit XP 1991iXR scanner features a 2450 mAh Lithium Ion (Li-Ion) battery. This battery chemistry provides reliable power for extended scanning sessions with good cycle life. The capacity supports substantial operational time between charges, making it suitable for full-shift use in warehouse, retail, or industrial scanning applications.
What warranty coverage comes with this scanner?
The Honeywell Granit XP 1991iXR scanner includes a 3-year limited warranty. This warranty period provides substantial coverage for normal use in commercial and industrial environments, offering protection against manufacturing defects and ensuring long-term reliability for business operations that depend on consistent scanning performance.
What duplex or duty-cycle detail is listed?
the specifications are intended to help buyers confirm fit, compatibility, and expected day-to-day operation. In practical terms, the best reading of this product comes from how its hardware, connectivity, and deployment details work together.
What connectivity options are listed?
Connectivity support is listed in the product specifications, including the relevant wireless or port options when available.
