Honeywell HC70WZ5I30 5MP Network Dome Camera - Color - White/Pantone Black - 2592 x 1944 - 28. 5x Optical Zoom - Varifocal Lens - PoE+ - IK10/IP52
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
Built around a 1/2.8" CMOS sensor, the HC70WZ5I30 supports H.265 (HEVC), H.264, and MJPEG video compression formats for efficient bandwidth utilization and storage management. The camera features a comprehensive suite of imaging enhancements including Wide Dynamic Range (WDR), 3D Digital Noise Reduction, Day/Night operation with automatic switching, Defog, Privacy Masking, and Back Light Compensation (BLC).
Network connectivity is handled through Fast Ethernet with support for IPv4, IPv6, TCP/IP, HTTP, HTTPS, RTSP, ONVIF, and numerous other protocols for seamless integration into existing security infrastructures. Remote management capabilities allow administrators to configure and monitor the camera from centralized software platforms.
This section brings together practical product details such as HD Recording, Image Sensor Type, Image Sensor Size, Color Supported, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
This camera stands out with its combination of high-resolution imaging, mechanical durability, and flexible deployment options. The IK10 impact resistance rating and IP52 ingress protection ensure reliable operation in environments where physical abuse or dust/water exposure may occur.
Advanced Imaging Features
Wide Dynamic Range balances bright and dark areas in challenging lighting, while 3D Digital Noise Reduction maintains clarity in low-light conditions without motion artifacts.
- Auto Gain Control
- Automatic White Balance
- Auto Flip Function
Network & Protocol Support
Comprehensive protocol compatibility including ONVIF ensures interoperability with most video management systems and network video recorders.
- IPv4/IPv6 Dual Stack
- RTSP/RTCP Streaming
- 802.1X Authentication
Deployment / Use Cases
The HC70WZ5I30 is particularly suited for commercial and institutional surveillance applications where both wide-area monitoring and detailed identification capabilities are required. Its in-ceiling dome form factor provides discreet installation while offering vandal resistance.
Typical deployments include retail environments for loss prevention, educational facilities for campus security, corporate offices for access control monitoring, and industrial settings where environmental durability is essential. The camera's PoE+ support simplifies installation by delivering both power and data over a single Ethernet cable.
Retail Surveillance
Monitor sales floors, entrances, and high-value merchandise areas with the camera's 28.5x zoom capability for identifying individuals and activities at various distances.
Institutional Security
Deploy in schools, hospitals, or government buildings where the IK10 impact rating provides protection against intentional damage while maintaining continuous surveillance coverage.
Physical Profile
The dome enclosure measures 10.53" (267.50 mm) in height with an 8.74" (222 mm) diameter, presenting a low-profile appearance when ceiling-mounted. The dual-color finish in White and Pantone Black allows for aesthetic blending with various interior designs. At 8.38 lb (3800 g), the camera has substantial construction that contributes to its impact resistance.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 10.53" (267.50 mm), 8.38 lb (3800 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Height
- 10.53" (267.50 mm)
- Weight
- 8.38 lb (3800 g)
- Length
- 5.2 mm (0.20")
Highlights
- 5-megapixel resolution (2592 x 1944) for detailed surveillance imaging
- 28.5x optical zoom varifocal lens with adjustable field of view
- H.265 (HEVC) compression for efficient bandwidth and storage utilization
- PoE+ support for simplified single-cable power and data deployment
- IK10 impact resistance and IP52 ingress protection ratings
- Wide Dynamic Range and 3D Digital Noise Reduction for challenging lighting
- Fast Ethernet connectivity with comprehensive protocol support including ONVIF
- Operating temperature range from 14°F to 122°F (-10°C to 50°C)
- 5-year limited warranty for long-term reliability assurance
- RoHS compliant environmentally friendly construction
Specifications
| Specifications | |
|---|---|
| Manufacturer | Honeywell International, Inc |
| Manufacturer Part Number | HC70WZ5I30 |
| Brand Name | Honeywell |
| Product Series | 70 |
| Product Model | HC70WZ5I30 |
| Product Name | 5MP Network TDN WDR In-Ceiling Speed Dome Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Image Sensor Size | 1/2.8" |
| Color Supported | Color |
| Field of View | H: 55° ~ 2.64° V: 42° ~ 1.98° / H: 96° ~ 46°, V: 53° ~ 26° |
| Effective Camera Resolution | 5 Megapixel |
| Video | |
| Video Formats | H.265 (HEVC),H.264,MJPEG |
| Maximum Video Resolution | 2592 x 1944 |
| Maximum Frame Rate | 60 fps |
| Video Signal Format | PAL,NTSC |
| Lens | |
| Lens Type | Varifocal |
| Minimum Focal Length | 5.2 mm (0.20") |
| Maximum Focal Length | 148.4 mm (5.84") |
| Lens Included | Yes |
| Minimum Aperture | f/4.8 |
| Maximum Aperture | f/1.3 |
| Optical Zoom | 28.5x |
| Exposure | |
| Shortest Shutter Speed | 1/32000 Second |
| Longest Shutter Speed | 1/1 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Ethernet Technology | Fast Ethernet |
| Protocols | IPv4,IPv6,TCP/IP,HTTP,HTTPS,UPnP,RTCP,RTP/RTSP/RTCP,IGMP,Multicast,SMTP,DHCP,NTP,DNS,DDNS,COS,QoS,SNMP,802.1X,UDP,ICMP,ARP,TLS,ONVIF |
| Storage | |
| Storage Type | Memory Card |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Input Voltage | 48 V DC,24 V AC |
| Power Source Type | AC,DC,PoE+ |
| Physical Characteristics | |
| Color Family | Dual Color |
| Product Color | White,Pantone Black |
| Mount Type | In-ceiling |
| Form Factor | Dome |
| Durability | Impact Resistant |
| Height | 10.53" (267.50 mm) |
| Diameter | 8.74" (222 mm) |
| Weight (Approximate) | 8.38 lb (3800 g) |
| Environmental Conditions | |
| Minimum Operating Temperature | 14°F (-10°C) |
| Maximum Operating Temperature | 122°F (50°C) |
| Maximum Operating Humidity | 90% |
| Miscellaneous | |
| Features | Wide Dynamic Range,3D Digital Noise Reduction,Noise Detection,Noise Reduction,Day/Night,Defog,Privacy Masking,Auto Gain Control,Back Light Compensation (BLC),Automatic White Balance,White Balance,Auto Flip |
| Impact Protection Rating | IK10 |
| Ingress Protection Rating | IP52 |
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 5 Year |
User Manual
FAQ
What is the maximum video resolution of this Honeywell camera?
The HC70WZ5I30 captures video at up to 2592 x 1944 resolution, which is 5 megapixels. This high resolution provides detailed imagery suitable for identification purposes in surveillance applications, with support for 60 frames per second for smooth motion capture.
Does this camera support Power over Ethernet (PoE)?
Yes, this camera supports PoE+ (802.3at) for both power and data delivery over a single Ethernet cable. It also accepts 48V DC or 24V AC power inputs, providing flexible installation options depending on your infrastructure.
What type of lens does this network camera have?
The camera features a varifocal lens with 28.5x optical zoom capability. The focal length ranges from 5.2 mm (0.20") for wide-angle views to 148.4 mm (5.84") for telephoto shots, allowing operators to adjust the field of view without physically moving the camera.
How durable is this dome camera for outdoor or harsh environments?
With an IK10 impact resistance rating and IP52 ingress protection, this camera withstands significant physical abuse and is protected against limited dust ingress and water dripping. It operates reliably in temperatures from 14°F to 122°F (-10°C to 50°C) with up to 90% humidity.
What video compression formats does this camera support?
The camera supports H.265 (HEVC), H.264, and MJPEG compression formats. H.265 provides approximately 50% better compression efficiency than H.264, reducing bandwidth and storage requirements while maintaining video quality.
Can this camera be integrated with existing video management systems?
Yes, the HC70WZ5I30 supports ONVIF protocol along with comprehensive network standards including RTSP/RTCP streaming, IPv4/IPv6, and HTTP/HTTPS. This ensures compatibility with most professional video management systems and network video recorders on the market.
What storage is included?
The system includes Memory Card of storage for applications, files, and everyday business data.
