Honeywell HF811-01RT00004K-R HF811 Fixed Mount Scanner - 1D/2D Imager - Serial/Ethernet Cable - IP65 Industrial - Black
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The HF811 scanner features a 20° horizontal and 11° vertical field of view, optimized for capturing barcodes within its scanning zone. It supports decoding of direct part marking (DPM) codes, making it suitable for applications where barcodes are etched or engraved directly onto components.
This scanner operates effectively in ambient light conditions up to 100,000 lux, ensuring reliable performance in brightly lit industrial settings. The combination of serial and Ethernet host interfaces provides flexible integration with existing point-of-sale, inventory management, and manufacturing systems.
This section brings together practical product details such as Connectivity Technology, Scanning Capability, Barcode Symbology Supported, Host Interface, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The HF811 delivers several distinct advantages for industrial scanning applications. Its rugged IP65-rated enclosure protects against dust ingress and low-pressure water jets, making it suitable for washdown environments and areas with airborne particulates.
Versatile Barcode Support
Handles both 1D and 2D barcodes including QR codes, Data Matrix, PDF417, and direct part marked codes for comprehensive scanning capability across different labeling methods.
- QR Code Support
- Data Matrix
- PDF417
- 1D DPM
Dual Interface Connectivity
Provides both serial RS-232 and Ethernet connectivity options, allowing integration with legacy systems and modern networked environments without requiring additional adapters.
- Serial RS-232
- Ethernet 10/100
- Cable Connectivity
Industrial Durability
Built to withstand harsh industrial conditions with IP65 protection, robust construction, and reliable performance in high-ambient-light environments up to 100,000 lux.
- IP65 Rated
- High Light Tolerance
- Fixed Mount Stability
Deployment / Use Cases
The Honeywell HF811 fixed mount scanner is designed for installation at stationary points within material handling and production workflows. Its compact dimensions and versatile mounting options make it suitable for integration into conveyor systems, assembly lines, and sorting stations.
In warehouse environments, the HF811 excels at package sorting, inventory verification, and shipping label validation. Manufacturing applications include component tracking, work-in-process monitoring, and quality control checkpoints where durable, hands-free scanning improves throughput and accuracy.
Conveyor System Integration
Mounts alongside conveyor belts to automatically scan packages and cartons as they move through distribution centers, eliminating manual handling and increasing sorting speed.
Assembly Line Tracking
Installs at production stations to scan components and subassemblies, providing real-time visibility into manufacturing progress and component traceability.
Physical Profile
The HF811 features a compact black enclosure measuring 2.17" wide × 2.76" high × 1.77" deep (55 × 70 × 45 mm) with an approximate weight of 6.35 ounces (180 grams). This streamlined form factor enables installation in space-constrained locations while maintaining a low profile that minimizes interference with workflow areas.
- Width
- 2.17" (55 mm)
- Depth
- 1.77" (45 mm)
- Height
- 2.76" (70 mm)
- Weight
- 6.35 oz (180 g)
Highlights
- Fixed mount barcode scanner for industrial and warehouse applications
- 1D and 2D scanning capability including QR codes and Data Matrix
- Direct part marking (DPM) decoding support
- Serial and Ethernet host interface connectivity
- IP65 rating for dust and water protection
- Operates in ambient light up to 100,000 lux
- 20° horizontal × 11° vertical field of view
- Compact dimensions: 2.17" W × 2.76" H × 1.77" D
- 3-year limited warranty
- Black color for professional appearance
Specifications
| Specifications | |
|---|---|
| Manufacturer | Honeywell International, Inc |
| Manufacturer Part Number | HF811-01RT00004K-R |
| Brand Name | Honeywell |
| Product Series | HF81X |
| Product Model | HF811 |
| Product Name | HF811 Fixed Mount Scanner |
| Product Type | Barcode Scanner |
| Technical Information | |
| Connectivity Technology | Cable |
| Scanning Capability | 1D,2D |
| Barcode Symbology Supported | 2D (QR, Datamatrix, Maxicode, Aztec) PDF417 1D DPM |
| Image Sensor Type | Imager |
| Field of View (Horizontal) | 20° |
| Field of View (Vertical) | 11° |
| Maximum Ambient Light | 100000 lux |
| Direct Part Marking (DPM) Decoding | Yes |
| Interfaces/Ports | |
| Host Interface | Serial,Ethernet |
| Physical Characteristics | |
| Form Factor | Fixed Mount |
| Product Color | Black |
| Height | 2.76" (70 mm) |
| Width | 2.17" (55 mm) |
| Depth | 1.77" (45 mm) |
| Weight (Approximate) | 6.35 oz (180 g) |
| Miscellaneous | |
| Ingress Protection (IP) Rating | IP65 |
| Application/Usage | Industrial,Manufacturing,Warehouse |
| Warranty | |
| Limited Warranty | 3 Year |
User Manual
FAQ
What types of barcodes can the Honeywell HF811 scanner read?
The HF811 reads both 1D and 2D barcodes, including 2D codes like QR, Data Matrix, Maxicode, and Aztec, plus PDF417 and 1D direct part marked (DPM) codes. This comprehensive symbology support makes it suitable for various industrial labeling methods from printed labels to etched components.
What does the IP65 rating mean for this scanner?
The IP65 rating indicates complete protection against dust ingress and protection against low-pressure water jets from any direction. This makes the HF811 suitable for industrial environments where dust, debris, or occasional water exposure might occur, such as manufacturing floors or warehouse areas that require occasional cleaning.
What connectivity options does the HF811 offer?
The HF811 provides both serial RS-232 and Ethernet 10/100 connectivity through cable connections. This dual-interface approach allows integration with legacy systems using serial connections while also supporting modern networked environments, providing flexibility for different IT infrastructures.
Can this scanner read direct part marked (DPM) codes?
Yes, the HF811 includes DPM decoding capability, allowing it to read barcodes that are etched, engraved, or otherwise permanently marked directly onto components and products. This is particularly valuable in manufacturing and automotive applications where printed labels may not withstand the production environment.
What is the field of view for the HF811 scanner?
The HF811 has a 20° horizontal field of view and an 11° vertical field of view. This optimized viewing angle helps ensure barcodes within the scanning zone are captured reliably while minimizing the chance of reading unintended codes outside the target area.
What type of warranty comes with the Honeywell HF811?
The HF811 comes with a 3-year limited warranty from Honeywell. This warranty period reflects the product's industrial-grade construction and reliability expectations for continuous operation in demanding environments.
What duplex or duty-cycle detail is listed?
the specifications are intended to help buyers confirm fit, compatibility, and expected day-to-day operation. In practical terms, the best reading of this product comes from how its hardware, connectivity, and deployment details work together.
What connectivity options are listed?
Connectivity details help confirm how the product integrates with your network, accessories, and surrounding peripherals before rollout or replacement planning. They are often the difference between a technically compatible device and one that is genuinely easy to deploy.
