Honeywell Xenon Ultra 1962G Cordless Bluetooth Handheld Scanner - Wireless Connectivity - 43.90" (1115.06 mm) Scan Distance - LED - - (1962GSR-2)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- Engineered to withstand 50 drops at 1.8 m (6 ft) to concrete across operating temp range
- Lithium-ion Battery Pack: 1 year
Connectivity Technology: Wireless
Light Source: LED
Image Sensor Type: Imager
Scan Pattern: Area
Scanner Range: Standard Range
Scanning Distance: 43.90" (1115.06 mm)
Field of View (Horizontal): 42°
Field of View (Vertical): 36°
Reading Angle (Skew): 65°
Reading Angle (Pitch): 65°
Reading Angle (Roll): 360°
Motion Tolerance: 157.48 in/s (4000 mm/s)
Maximum Ambient Light: 100000 lux
Drop Specification:
Minimum Print Contrast: 15%
Minimum Element Resolution (Code 39): 3 mil (0.08 mm)
Maximum Element Resolution (Code 39): 20 mil (0.51 mm)
Minimum Element Resolution (DataMatrix): 5 mil (0.13 mm)
Maximum Element Resolution (DataMatrix): 10 mil (0.25 mm)
Minimum Element Resolution (PDF417): 5 mil (0.13 mm)
Maximum Element Resolution (PDF417): 6.70 mil (0.17 mm)
Image Sensor Resolution: 1280 x 1080
Illumination Type: LED
Illumination Color: White
Air Electrostatic Discharge (+/-): 15kV
Features: Beep,Notification LED
Bluetooth: Yes
Radio Frequency: Yes
Maximum Operating Power Consumption: 10 W
Battery Chemistry: Lithium Ion (Li-Ion)
Battery Capacity: 3300 mAh
Maximum Battery Run Time: 22 Hour
Maximum Battery Recharge Time: 4.50 Hour
Operating Temperature: 32°F (0°C) to 122°F (50°C)
Storage Temperature: -40°F (-40°C) to 158°F (70°C)
Humidity (Non-condensing): 0% to 95%
Form Factor: Handheld
Color Family: Black
Product Color: Black
Height: 6.30" (160.02 mm)
Width: 2.80" (71.12 mm)
Length: 4.30" (109.22 mm)
Weight (Approximate): 8.71 oz (247 g)
Ingress Protection (IP) Rating: IP52,IP41
Application/Usage: Inventory,Component Tracking,Assembly Line,Retail,Self-checkout,Manufacturing
Limited Warranty: 3 Year
Additional Warranty Information:
- Laser-free design provides high-performance scanning without the risk of eye injury
- Increases productivity by giving the opportunity to wander, without the tangle of cables
- With Bluetooth technology, you can scan barcodes and then transmit data from the base
[custom-specifications]
| Specifications | |
| Manufacturer | Honeywell International, Inc |
| Manufacturer Part Number | 1962GSR-2 |
| Manufacturer Website Address | http://www.honeywell.com |
| Brand Name | Honeywell |
| Product Line | Xenon Ultra |
| Product Model | 1962G |
| Product Name | Xenon Ultra 1962G Cordless Bluetooth Handheld Scanner |
| Product Type | Barcode Scanner |
| Technical Information | |
| Connectivity Technology | Wireless |
| Light Source | LED |
| Image Sensor Type | Imager |
| Scan Pattern | Area |
| Scanner Range | Standard Range |
| Scanning Distance | 43.90" (1115.06 mm) |
| Field of View (Horizontal) | 42° |
| Field of View (Vertical) | 36° |
| Reading Angle (Skew) | 65° |
| Reading Angle (Pitch) | 65° |
| Reading Angle (Roll) | 360° |
| Motion Tolerance | 157.48 in/s (4000 mm/s) |
| Maximum Ambient Light | 100000 lux |
| Drop Specification |
|
| Minimum Print Contrast | 15% |
| Minimum Element Resolution (Code 39) | 3 mil (0.08 mm) |
| Maximum Element Resolution (Code 39) | 20 mil (0.51 mm) |
| Minimum Element Resolution (DataMatrix) | 5 mil (0.13 mm) |
| Maximum Element Resolution (DataMatrix) | 10 mil (0.25 mm) |
| Minimum Element Resolution (PDF417) | 5 mil (0.13 mm) |
| Maximum Element Resolution (PDF417) | 6.70 mil (0.17 mm) |
| Image Sensor Resolution | 1280 x 1080 |
| Illumination Type | LED |
| Illumination Color | White |
| Air Electrostatic Discharge (+/-) | 15kV |
| Features | Beep,Notification LED |
| Network & Communication | |
| Bluetooth | Yes |
| Radio Frequency | Yes |
| Power Description | |
| Maximum Operating Power Consumption | 10 W |
| Battery Information | |
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Battery Capacity | 3300 mAh |
| Maximum Battery Run Time | 22 Hour |
| Maximum Battery Recharge Time | 4.50 Hour |
| Environmental Conditions | |
| Operating Temperature | 32°F (0°C) to 122°F (50°C) |
| Storage Temperature | -40°F (-40°C) to 158°F (70°C) |
| Humidity (Non-condensing) | 0% to 95% |
| Physical Characteristics | |
| Form Factor | Handheld |
| Color Family | Black |
| Product Color | Black |
| Height | 6.30" (160.02 mm) |
| Width | 2.80" (71.12 mm) |
| Length | 4.30" (109.22 mm) |
| Weight (Approximate) | 8.71 oz (247 g) |
| Miscellaneous | |
| Ingress Protection (IP) Rating | IP52,IP41 |
| Application/Usage | Inventory,Component Tracking,Assembly Line,Retail,Self-checkout,Manufacturing |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information |
|
