HP 86Y57UT#ABC Elite Mini 800 G9 Desktop PC - Intel Core i5-13500T vPro - 16GB DDR5256GB NVMe SSD - Windows 11 Pro French
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the Elite Mini 800 G9 sits the Intel Core i5-13500T processor, a 12th Gen chip with 14 cores and Intel vPro technology for enhanced manageability and security. The processor's maximum turbo frequency reaches 4.60 GHz, providing burst performance when needed while the 35W TDP design maintains thermal efficiency.
Memory performance benefits from DDR5 technology, with a single 16 GB module delivering higher bandwidth than previous generations. Storage utilizes the PCI Express NVMe interface through an M.2 form factor SSD, offering significantly faster read/write speeds compared to SATA-based storage. Graphics are handled by Intel UHD Graphics 770 with shared DDR5 memory, capable of driving multiple displays and handling mainstream visual workloads.
Relevant factors for this section include Processor Manufacturer, Processor Type, Processor Generation, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
Beyond core specifications, the Elite Mini 800 G9 incorporates features that enhance its business utility. The system includes environmental certifications like TCO Certified 9.0 and Energy Star compliance, reflecting HP's commitment to sustainable computing. The 90-watt power supply supports dual voltage input (120V/230V), making it adaptable to different regional power standards.
Compact Enterprise Desktop
The Mini PC form factor occupies minimal desk or mounting space while delivering full desktop capabilities. The 1.34-inch height and 3.13-pound weight make it ideal for space-constrained environments.
- Tool-less access for easy maintenance
- Dust filter for improved reliability
- Security slot for physical protection
Modern Connectivity Suite
Comprehensive networking includes Gigabit Ethernet, WiFi 6 with 802.11ax support, and Bluetooth for peripheral connections. The USB port selection provides both traditional and modern Type-C connectivity.
- 5 × USB 3.2 Gen 2 ports
- 1 × USB 3.2 Gen 2x2 Type-C port
- Dual-band wireless with improved range
Deployment / Use Cases
The HP Elite Mini 800 G9 serves well in environments where physical footprint matters without compromising on computing capability. Its Mini PC design allows placement in areas where traditional desktops wouldn't fit, such as behind monitors, under desks, or in mounted configurations.
For businesses with French-speaking users, the pre-installed Windows 11 Pro with French language and French keyboard localization reduces setup time and ensures immediate usability. The system's manageability features, including vPro technology, simplify IT administration in larger deployments.
Office Productivity Hub
Ideal for general office applications, the combination of Core i5 processing, 16 GB RAM, and fast NVMe storage ensures smooth performance across productivity suites, web applications, and communication tools.
Digital Signage & Kiosk Platform
The compact size and low power consumption make this system suitable for digital signage deployments, information kiosks, or point-of-sale terminals where space is limited but reliable performance is required.
Localization and Operating System
This configuration ships with Windows 11 Pro pre-installed in the French language version, providing a localized experience from first boot. The operating system includes all standard Windows 11 Pro features with French interface elements, documentation, and regional settings.
Complementing the OS localization, the included keyboard features French key legends and layout. This complete French-language solution eliminates the need for post-purchase language packs or keyboard replacements, streamlining deployment in French-speaking work environments.
Relevant factors for this section include Processor Manufacturer, Processor Type, Processor Generation, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
Measuring just 1.34 inches in height, 6.97 inches in width, and 6.89 inches in depth, the Elite Mini 800 G9 occupies minimal space while delivering full desktop functionality. The 3.13-pound weight facilitates easy transport between locations or mounting in various orientations.
The compact chassis incorporates thoughtful design elements including tool-less access for maintenance, a dust filter to protect internal components, and a security slot for physical theft prevention. The small footprint makes this system suitable for desktop, wall-mounted, or behind-monitor installations where space optimization is critical.
- Width
- 6.97" (177 mm)
- Depth
- 6.89" (175 mm)
- Height
- 1.34" (34 mm)
- Weight
- 3.13 lb (1420 g)
What's in the Box
The package includes all essential components for immediate setup and operation.
Package contents include Elite Mini 800 G9 Desktop PC Mouse Keyboard Power Adapter, Elite Mini 800 G9 Desktop PC. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Intel Core i5-13500T processor with 14 cores and vPro technology for enterprise manageability
- 16 GB DDR5 memory provides high-bandwidth performance for multitasking and demanding applications
- 256 GB PCIe NVMe SSD delivers fast boot times, quick application launches, and responsive file access
- Windows 11 Pro French edition pre-installed with French keyboard for immediate deployment
- Mini PC form factor saves space while maintaining full desktop capabilities
- WiFi 6 (802.11ax) and Gigabit Ethernet provide flexible, high-speed connectivity options
- Multiple USB 3.2 ports including Type-C with 20 Gbps transfer speeds
- Tool-less chassis design simplifies maintenance and upgrades
- Energy Star certified and TCO Certified 9.0 for environmental compliance
- Compact dimensions: 1.34" H × 6.97" W × 6.89" D (34 × 177 × 175 mm)
Specifications
| Specifications | |
|---|---|
| Manufacturer | HP Inc. |
| Manufacturer Part Number | 86Y57UT#ABC |
| Brand Name | HP |
| Product Line | Elite Mini |
| Product Series | 800 G9 |
| Product Name | Elite Mini 800 G9 Desktop PC |
| Product Type | Desktop Computer |
| Processor | |
| Processor Manufacturer | Intel |
| Processor Type | Core i5 |
| Processor Generation | 12th Gen |
| Processor Model | i5-13500T |
| Processor Core | Tetradeca-core (14 Core) |
| Maximum Turbo Speed | 4.60 GHz |
| vPro Technology | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | Q670 |
| Memory | |
| Standard Memory | 16 GB |
| Memory Technology | DDR5 SDRAM |
| Memory Configuration | 1 x 16GB |
| Storage | |
| Total Solid State Drive Capacity | 256 GB |
| Solid State Drive Interface | PCI Express NVMe |
| SSD Form Factor | M.2 |
| Display & Graphics | |
| Graphics Controller Manufacturer | Intel |
| Graphics Controller Model | UHD Graphics 770 |
| Graphics Memory Technology | DDR5 SDRAM |
| Graphics Memory Accessibility | Shared |
| Network & Communication | |
| LAN Model | I219-LM |
| Ethernet Technology | Gigabit Ethernet |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11ax |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | French |
| Interfaces/Ports | |
| Total Number of USB Ports | 6 |
| Number of USB 3.2 Gen 2 Ports | 5 |
| Number of USB 3.2 Gen 2x2 Type-C Ports | 1 |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Language | French |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Maximum Power Supply Wattage | 90 W |
| Physical Characteristics | |
| Form Factor | Mini PC |
| Height | 1.34" (34 mm) |
| Width | 6.97" (177 mm) |
| Depth | 6.89" (175 mm) |
| Weight (Approximate) | 3.13 lb (1420 g) |
| Miscellaneous | |
| Package Contents | Elite Mini 800 G9 Desktop PC Mouse Keyboard Power Adapter |
| Features | Tool-less Access,Dust Filter,Security Slot |
| Energy Star | Yes |
| TCO Certified | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | TCO Certified 9.0 |
| Energy Efficiency Certification | China Energy Conservation Program (CECP) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
User Manual
FAQ
What processor does the HP Elite Mini 800 G9 use?
This desktop features the Intel Core i5-13500T processor from the 12th Generation. It's a 14-core processor with a maximum turbo frequency of 4.60 GHz and includes Intel vPro technology for enhanced security and remote management capabilities in business environments.
How much memory is installed and what type is it?
The system comes with 16 GB of DDR5 SDRAM installed as a single 16 GB module. DDR5 memory provides higher bandwidth and improved power efficiency compared to previous DDR4 technology, supporting better performance in memory-intensive applications.
What storage configuration does this desktop have?
Storage consists of a 256 GB PCI Express NVMe solid-state drive in the M.2 form factor. NVMe technology delivers significantly faster data transfer speeds compared to SATA SSDs, resulting in quicker boot times, faster application loading, and responsive file operations.
What operating system is pre-installed?
Windows 11 Pro comes pre-installed in the French language version. This includes the complete Windows 11 Pro feature set with French interface elements, system messages, and regional settings optimized for French-speaking users.
What networking capabilities does this Mini PC offer?
The system includes both wired and wireless networking options. Wired connectivity features Gigabit Ethernet through an Intel I219-LM controller. Wireless capabilities include WiFi 6 (802.11ax) for faster wireless speeds and improved network efficiency, plus Bluetooth for connecting peripherals.
How compact is the Elite Mini 800 G9 form factor?
This Mini PC measures 1.34 inches in height, 6.97 inches in width, and 6.89 inches in depth (34 × 177 × 175 mm), with a weight of approximately 3.13 pounds (1420 grams). The compact design saves significant desk space while maintaining full desktop functionality.
