HP AN6C3UT#ABA ZBook Studio G11 16" Mobile Workstation - Intel Core Ultra 7155H - 16 GB RAM - 512 GB SSD - NVIDIA RTX 1000 - Windows 11 Pro - English
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the ZBook Studio G11 is Intel's Core Ultra 7 155H processor, featuring 16 cores and 22 threads with a maximum turbo frequency of 4.80 GHz. The integrated AI Boost NPU delivers 11 TOPS of performance, enabling efficient local AI processing without relying on cloud resources.
Memory is configured as 16 GB of DDR5 SDRAM running at 5600 MHz across two occupied SO-DIMM slots, with support for expansion up to 64 GB. Storage is handled by a 512 GB M.2 SSD, providing fast boot times and rapid file access.
Relevant factors for this section include AI-powered, Processor Manufacturer, Processor Type, Processor Model. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The ZBook Studio G11 combines workstation-grade performance with mobile convenience, making it an ideal choice for architects, engineers, content creators, and data scientists who need to work on the go.
Professional-Grade Display
The 16-inch WUXGA IPS panel offers 1920 x 1200 resolution with 400 cd/m² brightness and 100% sRGB color coverage, ensuring accurate color reproduction for design and media work.
- Anti-glare coating reduces reflections
- Low Blue Light mode for extended viewing comfort
Advanced Connectivity
With two Thunderbolt 4 ports and a high-speed USB Type-C port, the workstation supports fast data transfer, dual 4K display output, and single-cable docking solutions.
- Wi-Fi 7 provides future-proof wireless performance
- Bluetooth enables peripheral connectivity
Enhanced Security & Convenience
Built-in features like a fingerprint reader, infrared camera for Windows Hello facial recognition, and a physical camera shutter ensure secure access and privacy.
- Keyboard backlight aids low-light typing
- Miracast support for wireless display mirroring
Deployment / Use Cases
The HP ZBook Studio G11 is designed for professional environments where mobility cannot compromise performance. Its balanced specifications make it suitable for a wide range of demanding applications.
In engineering and architecture firms, the workstation handles CAD software, finite element analysis, and 3D rendering. For media production teams, it accelerates video editing, color grading, and motion graphics workflows. Data scientists and researchers benefit from the local AI capabilities for machine learning inference and data visualization tasks.
Field Engineering & Site Visits
Portable enough for site surveys and client meetings, yet powerful enough to run Autodesk Revit, SOLIDWORKS, or ArcGIS Pro directly in the field.
Content Creation Studio
The color-accurate display and RTX graphics accelerate Adobe Creative Cloud applications, DaVinci Resolve, and Blender for video editors, animators, and graphic designers.
Localization and Operating System
This ZBook Studio G11 configuration ships with Windows 11 Pro pre-installed in English, providing a professional-grade operating system with enhanced security, management features, and compatibility with business software.
The keyboard is localized for English (US) layouts and includes a backlight for visibility in dimly lit environments. This setup is ideal for North American markets and international teams where English is the primary language for software and documentation.
Relevant factors for this section include AI-powered, Processor Manufacturer, Processor Type, Processor Model. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
Measuring 14.02 inches wide, 9.53 inches deep, and just 0.75 inches thick, the ZBook Studio G11 maintains a slim profile without sacrificing cooling or expandability. Weighing 3.81 pounds, it strikes a balance between portability and durability, making it easy to carry between office, home, and client sites.
The build incorporates materials and design choices that support professional use, with a focus on thermal management to sustain performance under continuous load. The included 150 W power adapter supports fast charging and can also deliver power via USB Power Delivery for compatible devices.
- Width
- 14.02" (356 mm)
- Depth
- 9.53" (242 mm)
- Height
- 0.75" (19 mm)
- Weight
- 11.96 oz (339 g)
What's in the Box
The workstation arrives ready for setup with all essential components included.
Highlights
- Intel Core Ultra 7 155H processor with 16 cores and AI Boost NPU for on-device AI acceleration
- 16 GB DDR5 RAM (5600 MHz) in dual-channel configuration, expandable to 64 GB
- 512 GB NVMe SSD for fast storage and quick system responsiveness
- 16-inch WUXGA (1920 x 1200) IPS display with 400 cd/m² brightness and 100% sRGB color gamut
- NVIDIA RTX 1000 discrete graphics with 6 GB GDDR6 memory for professional applications
- Windows 11 Pro operating system pre-installed with English language
- English backlit keyboard for comfortable typing in any lighting
- Thunderbolt 4 and USB Type-C ports for high-speed connectivity and docking
- Wi-Fi 7 (802.11be) and Bluetooth for advanced wireless performance
- Fingerprint reader, infrared camera, and physical camera shutter for enhanced security
Specifications
| Specifications | |
|---|---|
| Manufacturer | HP Inc. |
| Manufacturer Part Number | AN6C3UT#ABA |
| Brand Name | HP |
| Product Line | ZBook Studio G11 |
| Product Name | ZBook Studio 16 inch G11 Mobile Workstation PC |
| Product Type | Mobile Workstation |
| Technical Information | |
| AI-powered | Yes |
| Processor | |
| Processor Manufacturer | Intel |
| Processor Type | Core Ultra 7 |
| Processor Model | 155H |
| Maximum Turbo Speed | 4.80 GHz |
| Processor Core | Hexadeca-core (16 Core) |
| Processor Threads | 22 |
| vPro Technology | No |
| NPU Name | AI Boost |
| NPU Performance | 11 TOPS |
| Chipset | |
| Chipset Manufacturer | Intel |
| Memory | |
| Standard Memory | 16 GB |
| Maximum Supported System Memory | 64 GB |
| System Memory Technology | DDR5 SDRAM |
| System Memory Speed | 5600 MHz |
| System Memory Form Factor | SoDIMM |
| Installed Slot Memory | 16 GB |
| Installed Slot Memory Configuration | 2 x 8GB |
| Total Number of Memory Slots | 2 |
| Number of Occupied Memory Slots | 2 |
| Number of Free Memory Slots | 0 |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 512 GB |
| SSD Form Factor | M.2 |
| Display & Graphics | |
| Screen Size | 16" |
| Screen Mode | WUXGA |
| Display Screen Type | LCD |
| Display Screen Technology | In-plane Switching (IPS) Technology |
| Screen Resolution | 1920 x 1200 |
| Brightness | 400 cd/m² |
| Color Gamut | 100% sRGB |
| Contrast Ratio | 1000:1 |
| Standard Refresh Rate | 60 Hz |
| Touchscreen | No |
| Graphics Controller Manufacturer | NVIDIA,Intel |
| Graphics Controller Model | RTX 1000,Arc Graphics |
| Graphics Memory Capacity | 6 GB |
| Graphics Memory Technology | GDDR6,DDR5 SDRAM |
| Graphics Memory Accessibility | Dedicated,Shared |
| Network & Communication | |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11be |
| Bluetooth | Yes |
| Built-in Devices | |
| Camera Privacy Shutter | Yes |
| Front Camera/Webcam | Yes |
| Infrared Camera | Yes |
| Finger Print Reader | Yes |
| Interfaces/Ports | |
| Total Number of USB Ports | 2 |
| USB Type-C | Yes |
| USB Type-C Detail | 1 SuperSpeed USB Type-C 10Gbps signaling rate (USB Power Delivery, DisplayPort™ 1.4) |
| Number of Thunderbolt 4 Ports | 2 |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Language | English |
| Input Devices | |
| Keyboard Localization | English |
| Keyboard Backlight | Yes |
| Battery Information | |
| Number of Cells | 6-cell |
| Battery Weight | 11.96 oz (339 g) |
| Power Description | |
| Maximum Power Supply Wattage | 150 W |
| AC Adapter Frequency | 47 Hz,63 Hz |
| USB Power Delivery Support | Yes |
| Physical Characteristics | |
| Height | 0.75" (19 mm) |
| Width | 14.02" (356 mm) |
| Depth | 9.53" (242 mm) |
| Weight (Approximate) | 3.81 lb (1730 g) |
| Miscellaneous | |
| Package Contents | ZBook Studio 16 inch G11 Mobile Workstation PC Power Cord AC Adapter |
| Charger Included | Yes |
| Energy Star | Yes |
| Features | Anti-glare Screen,Low Blue Light,Miracast Technology |
| Windows Hello Compatible | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),Electronic Product Environmental Assessment Tool Climate+ (EPEAT Climate+) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 1 Year |
User Manual
FAQ
What processor does the HP ZBook Studio G11 use, and what are its key features?
The HP ZBook Studio G11 is powered by an Intel Core Ultra 7 155H processor. This hexadeca-core (16-core) CPU operates at up to 4.80 GHz turbo frequency and includes Intel's AI Boost NPU, which delivers 11 TOPS of performance for accelerating on-device AI tasks like live transcription and content creation filters.
How much memory and storage does this mobile workstation have, and can they be upgraded?
This configuration comes with 16 GB of DDR5 SDRAM running at 5600 MHz, installed as two 8 GB modules in dual-channel mode. The memory is expandable up to 64 GB using the two available SO-DIMM slots. For storage, it includes a 512 GB M.2 NVMe SSD, which provides fast boot times and application loading, and can typically be upgraded or supplemented with additional drives.
What are the display specifications of the ZBook Studio G11?
The workstation features a 16-inch WUXGA display with a resolution of 1920 x 1200 pixels. It uses an IPS panel for wide viewing angles, offers 400 cd/m² brightness, covers 100% of the sRGB color gamut for accurate color reproduction, and has a 60 Hz refresh rate. The screen includes anti-glare and low blue light features to reduce eye strain during extended use.
What graphics capabilities does this model offer for professional applications?
Graphics are handled by an NVIDIA RTX 1000 discrete GPU with 6 GB of dedicated GDDR6 memory, combined with Intel Arc integrated graphics. This configuration provides the performance needed for CAD, 3D modeling, video editing, and data visualization software, ensuring smooth rendering and real-time previews in professional workflows.
What operating system and keyboard localization are included?
The workstation comes with Windows 11 Pro pre-installed in English, offering advanced security and management features for business environments. The keyboard is localized for English (US) layouts and includes a backlight, making it suitable for users in North America and other regions where English is the primary input language.
What are the physical dimensions and weight of the ZBook Studio G11, and what ports does it have?
The ZBook Studio G11 measures 14.02 inches wide, 9.53 inches deep, and 0.75 inches thick, weighing approximately 3.81 pounds. For connectivity, it includes two Thunderbolt 4 ports, one SuperSpeed USB Type-C 10Gbps port with Power Delivery and DisplayPort support, and a total of two USB ports. It also features Wi-Fi 7 and Bluetooth for wireless connections.
