HP AW7B6UA#ABA Elite Mini 800 G9 Desktop Computer - Intel Core i5-14500 14th Gen vPro - 16GB DDR5 RAM - 256GB NVMe SSD - Windows 11 Pro - Mini PC
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The Elite Mini 800 G9 features Intel's Core i5-14500 processor, a 14-core, 20-thread CPU with a base frequency of 2.6GHz and maximum turbo frequency of 5GHz. This processor includes Intel vPro Technology for enhanced remote management, security, and stability in business environments.
Memory performance benefits from DDR5 technology operating at 4800MHz, providing higher bandwidth and improved power efficiency compared to previous generations. The single 16GB module configuration allows for straightforward memory expansion when needed.
Storage performance is accelerated by the PCI Express NVMe interface, which delivers significantly faster data transfer rates than traditional SATA connections. The M.2 form factor SSD saves internal space while providing reliable, high-speed storage for the operating system and applications.
Relevant factors for this section include Processor Manufacturer, Processor Type, Processor Generation, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The Elite Mini 800 G9 balances performance with practicality. Its comprehensive connectivity suite includes five USB 3.2 Gen 2 ports and one USB 3.2 Gen 2x2 Type-C port for high-speed peripheral connections, along with Gigabit Ethernet and Wi-Fi 6 for flexible networking options.
Environmental certifications including TCO Certified 9.0 and EPEAT Climate+ demonstrate HP's commitment to sustainable manufacturing practices, while Energy Star compliance and the China Energy Conservation Program certification confirm energy-efficient operation.
Compact Business Computing
The mini PC form factor enables deployment in environments where space is at a premium, including behind monitors, under desks, or in wall-mounted configurations, without sacrificing desktop-class performance.
- 1.34" thin profile
- Tool-less access for maintenance
- Dust filter for improved reliability
Enterprise Management Features
Intel vPro Technology provides hardware-based security features and remote management capabilities that IT departments require for maintaining business systems efficiently.
- Remote management support
- Hardware-enhanced security
- Stable platform for business deployment
Deployment / Use Cases
The Elite Mini 800 G9 serves effectively as a primary workstation for knowledge workers, providing sufficient processing power for office productivity applications, web browsing, and video conferencing. Its small footprint makes it particularly valuable in shared workspaces, reception areas, or educational environments where desk space is limited.
For specialized deployments, the system's security slot enables physical security attachment, while the tool-less access design simplifies maintenance and upgrades. The dual-voltage power supply (120V/230V) supports international deployment scenarios, and the comprehensive wireless connectivity options facilitate installation in locations where wired networking is impractical.
Office Productivity Workstation
Ideal for general office applications, the Elite Mini 800 G9 handles productivity suites, web applications, and communication tools efficiently while occupying minimal desk space.
Digital Signage & Kiosk Platform
The compact size and reliable performance make this system suitable for digital signage deployments, information kiosks, or point-of-sale systems where space constraints exist.
Localization and Operating System
This configuration ships with Windows 11 Pro pre-installed, providing a complete, licensed operating system ready for immediate deployment. Windows 11 Pro includes enhanced security features, BitLocker encryption support, and remote desktop capabilities that are essential for business environments.
The operating system is configured for general use with standard regional settings. Organizations can apply their preferred localization, domain joining, and security policies during deployment. The included keyboard and mouse support standard input methods for productive workflow establishment from first boot.
Relevant factors for this section include Processor Manufacturer, Processor Type, Processor Generation, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
Measuring just 6.97 inches wide, 6.89 inches deep, and 1.34 inches tall, the Elite Mini 800 G9 occupies approximately the same footprint as a small hardcover book. This compact design enables versatile placement options, including vertical or horizontal orientation, VESA mount compatibility (with appropriate bracket), or discreet placement in crowded workspaces.
The 3.13-pound weight facilitates easy transport between locations, making this system suitable for mobile workers or temporary deployment scenarios. The chassis design includes ventilation for effective thermal management while maintaining quiet operation appropriate for office environments.
- Width
- 6.97" (177 mm)
- Depth
- 6.89" (175 mm)
- Height
- 1.34" (34 mm)
- Weight
- 3.13 lb (1420 g)
What's in the Box
The Elite Mini 800 G9 Desktop Computer ships as a complete system package ready for setup and immediate use.
Highlights
- Intel Core i5-14500 14th Gen processor with vPro Technology for business management
- 16GB DDR5 memory operating at 4800MHz for responsive multitasking
- 256GB PCI Express NVMe M.2 SSD for fast system responsiveness
- Windows 11 Pro operating system pre-installed and licensed
- Compact mini PC form factor (6.97" × 6.89" × 1.34") for space-constrained deployments
- Comprehensive connectivity with Wi-Fi 6, Bluetooth, and 6 USB ports
- Intel UHD Graphics 770 for display output and basic visual tasks
- Tool-less access design for simplified maintenance and upgrades
- Energy Star certified and TCO Certified 9.0 for environmental compliance
- Includes keyboard and mouse for complete out-of-box usability
Specifications
| Specifications | |
|---|---|
| Manufacturer | HP Inc. |
| Manufacturer Part Number | AW7B6UA#ABA |
| Brand Name | HP |
| Product Line | Elite Mini |
| Product Series | 800 G9 |
| Product Name | Elite Mini 800 G9 Desktop PC |
| Product Type | Desktop Computer |
| Processor | |
| Processor Manufacturer | Intel |
| Processor Type | Core i5 |
| Processor Generation | 14th Gen |
| Processor Model | i5-14500 |
| Processor Core | Tetradeca-core (14 Core) |
| Processor Threads | 20 |
| Processor Speed | 2.60 GHz |
| Maximum Turbo Speed | 5 GHz |
| vPro Technology | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | Q670 |
| Memory | |
| Standard Memory | 16 GB |
| Memory Technology | DDR5 SDRAM |
| Memory Speed | 4800 MHz |
| Memory Configuration | 1 x 16GB |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 256 GB |
| Solid State Drive Interface | PCI Express NVMe |
| SSD Form Factor | M.2 |
| Display & Graphics | |
| Graphics Controller Manufacturer | Intel |
| Graphics Controller Model | UHD Graphics 770 |
| Graphics Memory Technology | DDR5 SDRAM |
| Graphics Memory Accessibility | Shared |
| Network & Communication | |
| LAN Model | I219-LM |
| Ethernet Technology | Gigabit Ethernet |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11ax |
| Bluetooth | Yes |
| Interfaces/Ports | |
| Total Number of USB Ports | 6 |
| Number of USB 3.2 Gen 2 Ports | 5 |
| Number of USB 3.2 Gen 2x2 Type-C Ports | 1 |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Maximum Power Supply Wattage | 120 W |
| Physical Characteristics | |
| Form Factor | Mini PC |
| Height | 1.34" (34 mm) |
| Width | 6.97" (177 mm) |
| Depth | 6.89" (175 mm) |
| Weight (Approximate) | 3.13 lb (1420 g) |
| Miscellaneous | |
| Package Contents | Elite Mini 800 G9 Desktop PC Power Adapter Keyboard Mouse |
| Features | Security Slot,Tool-less Access,Low Halogen,Dust Filter |
| Energy Star | Yes |
| TCO Certified | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | TCO Certified 9.0,Electronic Product Environmental Assessment Tool Climate+ (EPEAT Climate+) |
| Energy Efficiency Certification | China Energy Conservation Program (CECP) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE),Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 1 Year |
| Additional Warranty Information | Support Service Included: HP 3 year Next Business Day Onsite Desktop excl. External Monitor Hardware Support. For terms and conditions, please visit & Manufacturer Warranty: 1 year (1/1/0) limited warranty includes 1 year of parts and labor. No on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply. |
User Manual
FAQ
What processor does the HP Elite Mini 800 G9 use?
The Elite Mini 800 G9 features an Intel Core i5-14500 processor from the 14th generation. This CPU has 14 physical cores and 20 threads, with a base clock speed of 2.6GHz and maximum turbo frequency of 5GHz. It includes Intel vPro Technology, which provides hardware-based security features and remote management capabilities for business environments.
How much memory is installed and what type is it?
This configuration includes 16GB of DDR5 SDRAM operating at 4800MHz. The memory is installed as a single 16GB module, which leaves one memory slot available for expansion if needed. DDR5 technology provides higher bandwidth and improved power efficiency compared to previous DDR4 memory.
What storage does this desktop computer include?
The system comes with a 256GB solid-state drive using the PCI Express NVMe interface in the M.2 form factor. This storage solution delivers significantly faster data transfer rates than traditional SATA SSDs or hard drives, resulting in quicker boot times, faster application loading, and responsive system performance for business applications.
What operating system is pre-installed?
Windows 11 Pro comes pre-installed and fully licensed on the Elite Mini 800 G9. This professional edition includes enhanced security features like BitLocker encryption, remote desktop functionality for IT management, and compatibility with business domain environments. The system is ready for immediate use upon setup.
What connectivity options are available on this mini PC?
The Elite Mini 800 G9 provides comprehensive connectivity including Gigabit Ethernet via an Intel I219-LM controller, Wi-Fi 6 (802.11ax) for wireless networking, and Bluetooth for peripheral connections. For wired peripherals, there are six USB ports total: five USB 3.2 Gen 2 ports and one USB 3.2 Gen 2x2 Type-C port for high-speed data transfer.
What are the physical dimensions and weight of this desktop?
The Elite Mini 800 G9 measures 6.97 inches wide, 6.89 inches deep, and 1.34 inches tall (177 × 175 × 34 mm), making it significantly smaller than traditional desktop towers. It weighs approximately 3.13 pounds (1420 grams). This compact form factor enables deployment in space-constrained environments while maintaining full desktop functionality.
