HP AY4K1UA#ABA Z2 Mini G9 Workstation - Intel Core i5-13500 13th Gen - 16GB DDR5256GB NVMe SSD - Windows 11 Pro - Mini PC
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the Z2 Mini G9 is the Intel Core i5-13500 processor, a 13th Gen chip with 14 cores and 20 threads operating at a base frequency of 2.50 GHz. This CPU is paired with the Intel W680 chipset, providing a stable platform for workstation tasks. The system includes 16GB of DDR5 SDRAM running at 5.60 GHz, with two memory slots allowing expansion up to 64GB to accommodate growing workloads.
Storage is handled by a 256GB PCI Express NVMe 4.0 x4 solid-state drive, offering rapid data access and boot times. The NVMe controller supports RAID 0 and 1 configurations for data redundancy or performance enhancement. Graphics are powered by a dedicated 4GB solution with 80 GB/s of memory bandwidth, suitable for CAD, visualization, and multimedia applications.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The Z2 Mini G9 Workstation stands out through its combination of compact design and uncompromised workstation performance. Its Mini PC form factor occupies minimal desk space while delivering the processing power needed for professional applications.
Enterprise-Grade Security
Intel vPro technology provides hardware-based security features, including threat detection and remote management capabilities, essential for business environments.
- Hardware-enhanced security
- Remote manageability
- IT deployment efficiency
High-Speed Connectivity
Dual 10 Gigabit Ethernet ports enable fast network transfers, while multiple USB Type-C and DisplayPort outputs support modern peripherals and multi-monitor setups.
- 10GbE for large file transfers
- USB-C 20Gbps support
- Multiple display outputs
Efficient Thermal Design
The air cooling system maintains optimal operating temperatures within the compact chassis, ensuring consistent performance during extended workloads.
- Reliable thermal management
- Quiet operation
- Sustained performance
Deployment / Use Cases
This workstation is engineered for professional environments where space efficiency and computational power are equally important. Its compact size makes it suitable for crowded office desks, medical carts, financial trading floors, or embedded installations where traditional towers would be impractical.
The Z2 Mini G9 excels in CAD and engineering applications, financial modeling, software development, and multimedia production. Its dedicated graphics and fast storage accelerate rendering and simulation tasks, while the robust connectivity supports multiple high-resolution displays and peripheral arrays.
Design and Engineering Workstations
Ideal for CAD, BIM, and 3D modeling applications where desk space is limited but processing demands are high.
Financial and Trading Environments
The compact form factor fits easily into multi-screen trading desks while providing the performance needed for real-time analytics.
Localization and Operating System
This workstation ships with Windows 11 Pro pre-installed, providing a professional operating system with enhanced security features, BitLocker encryption, and enterprise management tools. Windows 11 Pro offers a modern interface optimized for productivity and creative workflows.
The system supports global power standards with input voltages of 120V AC and 230V AC, making it suitable for deployment in North American, European, and international markets without requiring power adapters.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
Measuring just 2.72 inches in height, 8.31 inches in width, and 8.58 inches in depth, the Z2 Mini G9 occupies less than 0.4 cubic feet of space. Despite its compact dimensions, the chassis is engineered for durability and efficient heat dissipation.
Weighing 5.29 pounds, the workstation can be easily mounted behind monitors or under desks using VESA-compatible brackets. The minimalist design features clean lines and professional aesthetics suitable for corporate, educational, and healthcare environments.
- Width
- 80 GB/s
- Depth
- 8.58" (218 mm)
- Height
- 2.72" (69 mm)
- Weight
- 5.29 lb (2400 g)
What's in the Box
The workstation arrives ready for deployment with all essential components included for immediate setup and use.
Highlights
- Intel Core i5-13500 13th Gen processor with 14 cores and 20 threads
- 16GB DDR5 SDRAM running at 5.60 GHz, expandable to 64GB
- 256GB PCI Express NVMe 4.0 x4 SSD for fast storage performance
- Dedicated 4GB graphics memory with 80 GB/s bandwidth
- Windows 11 Pro operating system with enterprise features
- Intel vPro technology for enhanced security and manageability
- Mini PC form factor measuring just 2.72" × 8.31" × 8.58"
- Dual 10 Gigabit Ethernet ports for high-speed networking
- Multiple USB Type-C and DisplayPort connectivity options
- Energy Star certified with TCO and environmental compliance
Specifications
| Specifications | |
|---|---|
| Manufacturer | HP Inc. |
| Manufacturer Part Number | AY4K1UA#ABA |
| Brand Name | HP |
| Product Series | Z2 Mini G9 |
| Product Name | Z2 Mini G9 Workstation |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Core i5 |
| Processor Generation | 13th Gen |
| Processor Model | i5-13500 |
| Processor Core | Tetradeca-core (14 Core) |
| Processor Threads | 20 |
| Processor Speed | 2.50 GHz |
| Processor Socket | Socket LGA-1700 |
| vPro Technology | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | W680 |
| Memory | |
| Standard Memory | 16 GB |
| Maximum Memory Supported | 64 GB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 2 |
| Memory Clock Speed | 5.60 GHz |
| Memory Configuration | 1 x 16GB |
| Error Checking | Non-ECC |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 256 GB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | NVMe |
| RAID Supported | Yes |
| RAID Levels | 0, 1 |
| Display & Graphics | |
| Graphics Memory Capacity | 4 GB |
| Graphics Memory Accessibility | Dedicated |
| Maximum Memory Bandwidth | 80 GB/s |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet,10 Gigabit Ethernet |
| Interfaces/Ports | |
| Total Number of USB Ports | 6 |
| USB Type-C | Yes |
| USB Type-C Detail | 2 SuperSpeed USB Type-C® 20Gbps signaling rate |
| DisplayPort | Yes |
| Mini DisplayPort | Yes |
| Number of Mini DisplayPort | 3 |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Maximum Power Supply Wattage | 280 W |
| Physical Characteristics | |
| Cooler Type | Air Cooler |
| Form Factor | Mini PC |
| Height | 2.72" (69 mm) |
| Width | 8.31" (211 mm) |
| Depth | 8.58" (218 mm) |
| Weight (Approximate) | 5.29 lb (2400 g) |
| Miscellaneous | |
| Package Contents | Z2 Mini G9 Workstation Keyboard Mouse Power Adapter |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | China Environmental United Certification Center (CEC) |
| Energy Efficiency Certification | China Energy Conservation Program (CECP) |
| Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 1 Year |
User Manual
FAQ
What processor does the HP Z2 Mini G9 Workstation use?
The workstation features an Intel Core i5-13500 processor from the 13th Generation. This CPU has 14 cores and 20 threads with a base clock speed of 2.50 GHz, providing balanced performance for professional applications while maintaining power efficiency in the compact form factor.
How much memory is installed and what is the maximum supported?
The system comes with 16GB of DDR5 SDRAM installed, operating at 5.60 GHz. There are two memory slots available, allowing expansion up to a maximum of 64GB total system memory to accommodate more demanding workloads or future upgrades.
What type of storage does this workstation include?
Storage is provided by a 256GB PCI Express NVMe 4.0 x4 solid-state drive. This NVMe SSD offers significantly faster data transfer speeds compared to traditional SATA drives, resulting in quicker boot times, faster application loading, and improved overall system responsiveness.
Does this workstation include dedicated graphics?
Yes, the Z2 Mini G9 features dedicated graphics with 4GB of dedicated memory and 80 GB/s of memory bandwidth. This dedicated graphics solution provides better performance for visualization, CAD, and multimedia applications compared to integrated graphics options.
What networking capabilities does the workstation offer?
The workstation includes both Gigabit Ethernet and 10 Gigabit Ethernet ports. The 10GbE capability enables extremely fast network transfers for large files, making it ideal for environments that frequently move substantial data sets between workstations and servers.
What are the physical dimensions and weight of this Mini PC?
The Z2 Mini G9 measures 2.72 inches in height, 8.31 inches in width, and 8.58 inches in depth (69 × 211 × 218 mm). It weighs approximately 5.29 pounds (2400 grams), making it exceptionally compact and portable for a workstation-class system.
