HP AZ1J8UA#ABA Z2 Mini G9 Workstation - Intel Core i5-14400 14th Gen - 16GB DDR5 - 1TB NVMe SSD - Windows 11 Pro - Mini PC
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This workstation is engineered for stability and expansion. The Intel Core i5-14400 processor features a 10-core, 16-thread architecture with a base clock of 2.50 GHz, providing balanced performance for multi-threaded applications. The platform is supported by the Intel W680 chipset, which enables professional features and reliable I/O management.
Memory performance is driven by DDR5 SDRAM technology operating at 5.60 GHz, installed in a single 16 GB module. The system provides two memory slots, allowing an upgrade path to 64 GB for future workload growth. Storage is handled by a PCI Express NVMe 4.0 x4 SSD, offering sequential read/write speeds that significantly reduce load times for large project files.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The Z2 Mini G9 combines workstation-class capabilities with a minimal desktop footprint, eliminating the trade-off between power and space. Its specialized thermal design and component selection ensure sustained performance under heavy computational loads, a hallmark of the Z series.
Compact Professional Power
Delivers the performance profile of a traditional tower workstation in a chassis less than 9 inches deep, ideal for crowded desks, kiosks, or wall-mounted deployments.
- Mini PC form factor
- 280 W efficient PSU
- Air cooling system
Modern Connectivity Suite
Equipped with high-speed USB-C ports supporting 20 Gbps data transfer and device charging, alongside Gigabit Ethernet and wireless connectivity for flexible network integration.
- 2x USB-C 20Gbps
- Gigabit Ethernet
- Wi-Fi & Bluetooth
Enterprise-Ready Platform
Includes Windows 11 Pro for advanced management features, supports hardware RAID for data redundancy, and carries key environmental certifications for responsible deployment.
- Windows 11 Pro
- RAID 0/1 Support
- TCO Certified
Deployment / Use Cases
This workstation is designed for professionals who require reliable performance in environments where space is at a premium. Its balanced specifications make it suitable for a range of compute-intensive tasks without the bulk of a full-sized tower.
In engineering and architectural firms, it can run CAD and simulation software. For digital content creators, it handles video editing and 3D rendering applications. In financial or research settings, it manages data analysis and visualization workloads. The small size also makes it an excellent choice for digital signage controllers, thin client hosts, or as a compact server for specific applications.
Technical & Creative Workstations
A primary desktop for engineers, architects, and designers using software like AutoCAD, SolidWorks, Adobe Creative Suite, or similar professional tools.
Space-Optimized Office Deployments
Ideal for trading floors, call centers, university labs, or healthcare settings where desk space is limited but full PC functionality is required.
Localization and Operating System
This system ships with a full license for Windows 11 Pro installed. Windows 11 Pro provides enhanced security with features like BitLocker encryption, robust remote management capabilities for IT departments, and support for joining Azure Active Directory domains.
The operating system is configured for a standard North American English environment. The pre-installed OS ensures immediate productivity out of the box, with all necessary drivers for the workstation's hardware components.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The Mini PC form factor measures just 2.72 inches in height, 8.31 inches in width, and 8.58 inches in depth, with a weight of approximately 5.29 pounds. This compact design allows for placement behind monitors, under desks, or mounted vertically or horizontally using optional VESA brackets.
The chassis is designed for efficient airflow with an integrated air cooler, maintaining optimal temperatures for the Core i5 processor and other components during sustained operation. The small footprint and clean aesthetic integrate seamlessly into professional and minimalist workspaces.
- Width
- 8.31" (211 mm)
- Depth
- 8.58" (218 mm)
- Height
- 2.72" (69 mm)
- Weight
- 5.29 lb (2400 g)
What's in the Box
The package includes all essential components to set up and begin using the workstation immediately.
Highlights
- Intel Core i5-14400 14th Gen processor with 10 cores and 16 threads for multitasking
- 16 GB of DDR5 SDRAM running at 5.60 GHz for fast data handling
- 1 TB PCIe NVMe 4.0 SSD offers high-speed storage and quick boot times
- Compact Mini PC form factor saves valuable desk space
- Windows 11 Pro operating system for professional features and security
- Includes 2 x USB-C 20Gbps ports with charging support
- Gigabit Ethernet, Wi-Fi, and Bluetooth for comprehensive connectivity
- Supports hardware RAID 0 and 1 for data performance or redundancy
- 280 W power supply supports stable operation under load
- Backed by a 1-year limited warranty
Specifications
| Specifications | |
|---|---|
| Manufacturer | HP Inc. |
| Manufacturer Part Number | AZ1J8UA#ABA |
| Brand Name | HP |
| Product Series | Z2 Mini G9 |
| Product Name | Z2 Mini G9 Workstation |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Core i5 |
| Processor Generation | 14th Gen |
| Processor Model | i5-14400 |
| Processor Core | Deca-core (10 Core) |
| Processor Threads | 16 |
| Processor Speed | 2.50 GHz |
| Processor Socket | Socket LGA-1700 |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | W680 |
| Memory | |
| Standard Memory | 16 GB |
| Maximum Memory Supported | 64 GB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 2 |
| Memory Clock Speed | 5.60 GHz |
| Memory Configuration | 1 x 16GB |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 1 TB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | NVMe,Serial ATA/600 |
| RAID Supported | Yes |
| RAID Levels | 0, 1 |
| Display & Graphics | |
| Graphics Memory Accessibility | Shared |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Interfaces/Ports | |
| Total Number of USB Ports | 6 |
| USB Type-C | Yes |
| USB Type-C Detail | 2 x Type-C SuperSpeed USB 20Gbps port (charging supported) |
| DisplayPort | Yes |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Maximum Power Supply Wattage | 280 W |
| Physical Characteristics | |
| Cooler Type | Air Cooler |
| Form Factor | Mini PC |
| Height | 2.72" (69 mm) |
| Width | 8.31" (211 mm) |
| Depth | 8.58" (218 mm) |
| Weight (Approximate) | 5.29 lb (2400 g) |
| Miscellaneous | |
| Package Contents | Z2 Mini G9 Workstation Keyboard Mouse Power Adapter |
| Energy Star | Yes |
| Energy Efficiency Certification | China Energy Conservation Program (CECP) |
| Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 1 Year |
User Manual
FAQ
What processor is in the HP Z2 Mini G9 Workstation?
This workstation is equipped with an Intel Core i5-14400 processor from the 14th Generation. It is a deca-core (10-core) CPU with 16 threads and a base clock speed of 2.50 GHz, built on the LGA-1700 socket. This processor provides strong multi-threaded performance suitable for professional applications like CAD, data analysis, and content creation.
How much memory does it have, and can I upgrade it?
The system comes standard with 16 GB of DDR5 SDRAM installed as a single module. It has two total memory slots, leaving one slot available for expansion. The motherboard supports a maximum of 64 GB of DDR5 memory, allowing you to add another 16 GB module for 32 GB total, or upgrade both slots with higher-capacity modules as needed for more demanding workloads.
What type of storage is included?
It includes a 1 Terabyte (TB) Solid State Drive (SSD) that uses the PCI Express NVMe 4.0 x4 interface. This is a high-speed storage technology that offers significantly faster data transfer rates compared to traditional SATA SSDs or hard drives, resulting in quicker system boot, application launches, and file loading times for large project files.
What operating system does it come with?
This workstation ships with Microsoft Windows 11 Pro pre-installed and licensed. Windows 11 Pro includes advanced features beneficial for business and professional use, such as BitLocker device encryption, remote desktop hosting, and enhanced tools for IT management and deployment, providing a secure and manageable platform.
What are the physical dimensions of this Mini PC?
The HP Z2 Mini G9 has a compact form factor measuring 2.72 inches in height, 8.31 inches in width, and 8.58 inches in depth (approximately 69 mm x 211 mm x 218 mm). It weighs about 5.29 pounds (2400 grams). This small size allows for flexible placement in space-constrained environments like crowded desktops, media consoles, or mounted behind a monitor.
What connectivity ports are available?
The workstation offers comprehensive connectivity, including a total of six USB ports. This includes two high-speed USB Type-C ports (SuperSpeed USB 20Gbps) that support data transfer and device charging. It also features a DisplayPort for monitor connection, Gigabit Ethernet for wired networking, and integrated Wireless LAN and Bluetooth for wireless peripherals and network access.
