HP B27K8UA#ABA Elite Mini 800 G9 Desktop PC - Intel Core i7-14700T vPro - 16GB DDR5 - 512GB NVMe SSD - Windows 11 Pro - Mini PC
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the Elite Mini 800 G9 is the Intel Core i7-14700T processor, featuring 20 cores and 28 threads with Intel vPro technology for enhanced security and remote management capabilities. The processor operates at a 1.30 GHz base frequency with turbo boost up to 5.0 GHz, supported by the Intel Q670 chipset that provides enterprise-level stability and management features.
System memory utilizes a single 16 GB DDR5 SDRAM module, offering high-bandwidth performance for memory-intensive applications while leaving an expansion slot available for future upgrades. Storage is handled by a 512 GB PCI Express NVMe 4.0 x4 solid-state drive in the M.2 form factor, delivering rapid boot times and fast application loading.
Relevant factors for this section include Processor Manufacturer, Processor Type, Processor Generation, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The Elite Mini 800 G9 combines enterprise management features with a space-saving design that doesn't compromise on performance. Intel vPro technology provides hardware-based security and remote management capabilities that IT administrators require for maintaining distributed workforces, while the tool-less chassis design simplifies maintenance and upgrades without specialized tools.
Compact Professional Workstation
Despite its small 1.34-inch height, this mini PC delivers desktop-level performance with professional features including Intel vPro, Windows 11 Pro, and enterprise-grade connectivity options.
- Ultra-compact footprint saves desk space
- Full desktop performance in mini form factor
- Professional-grade components throughout
Enterprise Management Ready
Built with IT deployment and management in mind, featuring Intel vPro for remote management, tool-less access for easy maintenance, and comprehensive environmental certifications.
- Intel vPro for security and manageability
- Tool-less chassis design
- TCO Certified 9.0 and EPEAT Climate+
Deployment / Use Cases
The HP Elite Mini 800 G9 is ideally suited for corporate environments where space constraints meet performance requirements. Its compact dimensions make it perfect for reception areas, call centers, financial trading desks, and shared workspaces where multiple systems must fit in limited areas without sacrificing computing capability.
The system's combination of Intel vPro technology and Windows 11 Pro makes it particularly valuable for IT-managed environments requiring remote administration, security compliance, and standardized deployment. Educational institutions, healthcare facilities, and government offices benefit from both the physical footprint and the enterprise management features.
Corporate Workspace Solution
Deploy in space-constrained office environments where traditional desktops would be impractical but full computing power is still required for business applications.
Digital Signage & Kiosk Platform
The compact size and reliable performance make this system suitable for digital signage, interactive kiosks, and point-of-sale systems in retail and hospitality settings.
Localization and Operating System
This HP Elite Mini 800 G9 comes pre-installed with Windows 11 Pro, providing a professional operating system environment with enhanced security features, BitLocker encryption support, and enterprise management capabilities. Windows 11 Pro offers improved multitasking features, a redesigned interface optimized for productivity, and compatibility with business applications.
The system is configured for North American power standards with 120/230 V AC input compatibility, making it suitable for deployment in both residential and commercial environments across multiple regions.
Relevant factors for this section include Processor Manufacturer, Processor Type, Processor Generation, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
Measuring just 1.34 inches in height, 6.97 inches in width, and 6.89 inches in depth, the Elite Mini 800 G9 occupies minimal desk space while providing full desktop functionality. The 3.13-pound weight makes it easily portable between workspaces or mounting locations. The compact form factor includes multiple mounting options for vertical or horizontal placement, and the small footprint allows installation in areas where traditional desktop towers would be impractical.
- Width
- 6.97" (177 mm)
- Depth
- 6.89" (175 mm)
- Height
- 1.34" (34 mm)
- Weight
- 3.13 lb (1420 g)
What's in the Box
The HP Elite Mini 800 G9 Desktop PC ships complete with all necessary components for immediate deployment in business environments.
Highlights
- Intel Core i7-14700T processor with 20 cores and 28 threads for demanding multitasking
- 16 GB DDR5 memory provides high-bandwidth performance for professional applications
- 512 GB PCIe NVMe 4.0 SSD delivers fast boot times and rapid data access
- Intel vPro technology enables enhanced security and remote management capabilities
- Windows 11 Pro operating system with enterprise features and BitLocker support
- Ultra-compact mini PC form factor saves valuable desk and workspace
- Tool-less chassis design simplifies maintenance and hardware upgrades
- Comprehensive connectivity with Gigabit Ethernet, Wi-Fi 6, Bluetooth, and multiple USB ports
- Energy-efficient 90-watt power supply with 120/230 V AC compatibility
- Environmental certifications including TCO Certified 9.0 and EPEAT Climate+
Specifications
| Specifications | |
|---|---|
| Manufacturer | HP Inc. |
| Manufacturer Part Number | B27K8UA#ABA |
| Brand Name | HP |
| Product Line | Elite Mini |
| Product Series | 800 G9 |
| Product Name | Elite Mini 800 G9 Desktop PC |
| Product Type | Desktop Computer |
| Processor | |
| Processor Manufacturer | Intel |
| Processor Type | Core i7 |
| Processor Generation | 14th Gen |
| Processor Model | i7-14700T |
| Processor Core | Icosa-core (20 Core) |
| Processor Threads | 28 |
| Processor Speed | 1.30 GHz |
| Maximum Turbo Speed | 5 GHz |
| vPro Technology | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | Q670 |
| Memory | |
| Standard Memory | 16 GB |
| Memory Technology | DDR5 SDRAM |
| Memory Configuration | 1 x 16GB |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 512 GB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| SSD Form Factor | M.2 |
| Display & Graphics | |
| Graphics Controller Manufacturer | Intel |
| Graphics Controller Model | UHD Graphics 770 |
| Graphics Memory Technology | DDR5 SDRAM |
| Graphics Memory Accessibility | Shared |
| Network & Communication | |
| LAN Manufacturer | Intel |
| LAN Model | I219-LM |
| Ethernet Technology | Gigabit Ethernet |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11ax |
| Bluetooth | Yes |
| Interfaces/Ports | |
| Total Number of USB Ports | 6 |
| Number of USB 3.2 Gen 2 Ports | 5 |
| Number of USB 3.2 Gen 2x2 Type-C Ports | 1 |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Maximum Power Supply Wattage | 90 W |
| Physical Characteristics | |
| Form Factor | Mini PC |
| Height | 1.34" (34 mm) |
| Width | 6.97" (177 mm) |
| Depth | 6.89" (175 mm) |
| Weight (Approximate) | 3.13 lb (1420 g) |
| Miscellaneous | |
| Package Contents | Elite Mini 800 G9 Desktop PC Power Adapter Keyboard Mouse |
| Features | Security Slot,Tool-less Access,Low Halogen,Dust Filter |
| Energy Star | Yes |
| TCO Certified | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | TCO Certified 9.0,Electronic Product Environmental Assessment Tool Climate+ (EPEAT Climate+) |
| Energy Efficiency Certification | China Energy Conservation Program (CECP) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE),Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 1 Year |
User Manual
FAQ
What processor does the HP Elite Mini 800 G9 use and what are its key features?
The HP Elite Mini 800 G9 is powered by an Intel Core i7-14700T processor from the 14th generation. This processor features 20 cores and 28 threads, with a base clock speed of 1.30 GHz that can turbo boost up to 5.0 GHz under load. It includes Intel vPro technology, which provides hardware-enhanced security features and remote management capabilities essential for enterprise IT environments. The processor is built on Intel's latest architecture for improved performance per watt.
How much memory comes installed and what type is it?
This configuration includes 16 GB of DDR5 SDRAM memory installed as a single 16 GB module. DDR5 memory offers significantly higher bandwidth compared to previous generations, improving performance in memory-intensive applications. The system has one memory slot occupied, leaving expansion capability for future upgrades. The DDR5 technology also provides better power efficiency while maintaining compatibility with demanding professional workloads.
What storage configuration does this desktop include?
The HP Elite Mini 800 G9 comes with a 512 GB solid-state drive using the PCI Express NVMe 4.0 x4 interface in the M.2 form factor. This storage solution provides exceptionally fast read and write speeds compared to traditional hard drives or SATA SSDs, resulting in quick system boot times, rapid application loading, and fast file transfers. The NVMe 4.0 interface offers maximum performance for professional applications that require high storage throughput.
What operating system is pre-installed on this system?
This HP Elite Mini 800 G9 comes with Windows 11 Pro pre-installed and ready for use. Windows 11 Pro includes all the features of the Home edition plus additional business-oriented capabilities such as BitLocker device encryption, remote desktop functionality, Hyper-V for virtualization, and enhanced security features. The professional edition is particularly suited for business environments that require advanced management tools and enterprise-grade security protocols.
What are the physical dimensions and weight of this mini PC?
The HP Elite Mini 800 G9 measures 1.34 inches in height, 6.97 inches in width, and 6.89 inches in depth, making it one of the most compact desktop solutions available. It weighs approximately 3.13 pounds (1.42 kg), which contributes to its portability and flexibility in various deployment scenarios. The ultra-compact form factor allows installation in space-constrained environments while still providing full desktop computing capabilities.
What connectivity options are available on this desktop?
The Elite Mini 800 G9 offers comprehensive connectivity with six USB ports total, including five USB 3.2 Gen 2 ports and one USB 3.2 Gen 2x2 Type-C port for high-speed data transfer. Network connectivity includes Intel I219-LM Gigabit Ethernet for wired connections, plus IEEE 802.11ax (Wi-Fi 6) wireless networking and Bluetooth for wireless peripheral connections. This combination ensures compatibility with modern peripherals and network infrastructure in both wired and wireless environments.
