HP B29Y5UT#ABA Z2 Mini G9 Workstation - Intel Core i7-14700 14th Gen - 32GB DDR5 - 1TB NVMe SSD - Windows 11 Pro - Mini PC
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the heart of the Z2 Mini G9 is Intel's W680 chipset paired with a Core i7-14700 processor featuring 20 cores (8 performance cores and 12 efficiency cores) operating at a base frequency of 2.10 GHz. This processor supports Intel's Thread Director technology for intelligent workload distribution across performance and efficiency cores.
The memory subsystem utilizes DDR5 SDRAM technology with one 32GB module installed in the first of two available slots, supporting future expansion to 64GB total. Storage is handled by a high-performance PCIe NVMe 4.0 x4 solid-state drive with an NVMe controller, delivering sequential read speeds up to 7,000 MB/s for rapid data access and application loading.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The Z2 Mini G9 combines workstation-class performance with a remarkably small footprint, making it ideal for environments where space is at a premium but computational requirements remain high. The system's thermal design incorporates an efficient air cooling solution that maintains optimal operating temperatures even under sustained heavy loads.
Professional-Grade Connectivity
Six USB ports including two SuperSpeed USB Type-C 20Gbps ports provide high-speed peripheral connectivity, while Gigabit Ethernet, Wi-Fi, and Bluetooth ensure comprehensive networking options for any workspace configuration.
- 2x USB Type-C 20Gbps
- Gigabit Ethernet
- Wi-Fi & Bluetooth
- DisplayPort output
Enterprise-Ready Platform
With Windows 11 Pro, hardware RAID support, and extensive certification including Energy Star, TCO Certified, and environmental compliance standards, this workstation meets the requirements of professional and enterprise deployment scenarios.
- Windows 11 Pro
- RAID 0/1 Support
- TCO Certified
- Energy Star Compliant
Deployment / Use Cases
The compact dimensions of the Z2 Mini G9 make it exceptionally versatile for professional environments. The system can be mounted behind monitors using VESA mounts, placed on desks with minimal footprint, or integrated into specialized workstations where space optimization is critical.
Primary use cases include engineering workstations for CAD and CAM applications, financial analysis stations requiring simultaneous data processing, architectural design environments, scientific research stations, and media production setups where both performance and space efficiency are valued. The system's 280W power supply ensures stable operation across varying power conditions while supporting the processor and components at full load.
Engineering & Design
With 20-core processing power and 32GB of DDR5 memory, this workstation handles complex 3D modeling, simulation, and rendering tasks efficiently while occupying minimal desk space.
Financial & Data Analysis
The combination of high-core-count processor and fast NVMe storage enables rapid processing of large datasets, complex calculations, and multiple simultaneous analytical applications.
Localization and Operating System
This workstation ships with Windows 11 Pro pre-installed in English language version, providing a familiar interface for professional users while offering enterprise management capabilities, enhanced security features, and productivity tools. The keyboard localization is English, matching the operating system language for consistent user experience.
Windows 11 Pro includes BitLocker device encryption for data protection, Windows Information Protection for separating personal and corporate data, and support for joining Azure Active Directory or Group Policy management. The operating system takes full advantage of the hardware's performance capabilities while maintaining compatibility with professional software suites.
Physical Profile
Measuring just 2.72 inches in height, 8.31 inches in width, and 8.58 inches in depth, the Z2 Mini G9 achieves a remarkably compact footprint while housing full workstation components. The system weighs approximately 5.29 pounds, making it easily portable between work locations when needed.
The mini PC form factor enables flexible placement options including vertical or horizontal orientation, VESA mounting behind displays, or integration into specialized workstation furniture. The chassis design incorporates efficient airflow patterns and an air cooling system that maintains thermal performance within the compact enclosure.
- Width
- 8.31" (211 mm)
- Depth
- 8.58" (218 mm)
- Height
- 2.72" (69 mm)
- Weight
- 5.29 lb (2400 g)
What's in the Box
The workstation ships complete with all necessary components for immediate setup and operation.
Package contents include Z2 Mini G9 Workstation Keyboard Mouse Power Adapter, Z2 Mini G9 Workstation. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Intel Core i7-14700 14th Gen processor with 20 cores and 28 threads
- 32GB DDR5 SDRAM memory with expansion capability to 64GB
- 1TB PCIe NVMe 4.0 x4 SSD for high-speed storage performance
- Windows 11 Pro operating system with English language
- Compact mini PC form factor (2.72" H x 8.31" W x 8.58" D)
- Intel W680 chipset with hardware RAID 0/1 support
- Six USB ports including two SuperSpeed USB Type-C 20Gbps
- Gigabit Ethernet, Wi-Fi, and Bluetooth connectivity
- 280W power supply with 120-230V AC input range
- Energy Star, TCO Certified, and environmental compliance certifications
Specifications
| Specifications | |
|---|---|
| Manufacturer | HP Inc. |
| Manufacturer Part Number | B29Y5UT#ABA |
| Brand Name | HP |
| Product Series | Z2 Mini G9 |
| Product Name | Z2 Mini G9 Workstation |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Core i7 |
| Processor Generation | 14th Gen |
| Processor Model | i7-14700 |
| Processor Core | Icosa-core (20 Core) |
| Processor Threads | 28 |
| Processor Speed | 2.10 GHz |
| Processor Socket | Socket LGA-1700 |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | W680 |
| Memory | |
| Standard Memory | 32 GB |
| Maximum Memory Supported | 64 GB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 2 |
| Memory Configuration | 1 x 32GB |
| Error Checking | Non-ECC |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 1 TB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | NVMe |
| RAID Supported | Yes |
| RAID Levels | 0, 1 |
| Display & Graphics | |
| Graphics Memory Accessibility | Shared |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | English |
| Interfaces/Ports | |
| Total Number of USB Ports | 6 |
| USB Type-C | Yes |
| USB Type-C Detail | 2 x SuperSpeed USB Type-C 20Gbps signaling rate |
| DisplayPort | Yes |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Language | English |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Maximum Power Supply Wattage | 280 W |
| Physical Characteristics | |
| Cooler Type | Air Cooler |
| Form Factor | Mini PC |
| Height | 2.72" (69 mm) |
| Width | 8.31" (211 mm) |
| Depth | 8.58" (218 mm) |
| Weight (Approximate) | 5.29 lb (2400 g) |
| Miscellaneous | |
| Package Contents | Z2 Mini G9 Workstation Keyboard Mouse Power Adapter |
| Energy Star | Yes |
| Energy Efficiency Certification | China Energy Conservation Program (CECP) |
| Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 1 Year |
User Manual
FAQ
What processor does the HP Z2 Mini G9 Workstation use?
The workstation features an Intel Core i7-14700 14th Generation processor with 20 cores (8 performance cores and 12 efficiency cores) and 28 threads. This processor operates at a base frequency of 2.10 GHz and utilizes Intel's hybrid architecture with Thread Director technology for intelligent workload distribution between performance and efficiency cores.
How much memory is installed and what type is it?
The system comes with 32GB of DDR5 SDRAM installed as a single 32GB module. DDR5 memory provides higher bandwidth and improved power efficiency compared to previous generations. There are two memory slots total, allowing expansion up to 64GB by adding a second 32GB module. The memory operates in non-ECC configuration suitable for professional workstation applications.
What storage configuration does this workstation include?
Storage is provided by a 1TB PCI Express NVMe 4.0 x4 solid-state drive with an NVMe controller. This high-speed storage interface delivers sequential read speeds up to 7,000 MB/s for rapid application loading and data access. The system supports hardware RAID configurations (RAID 0 and RAID 1) for data protection or performance enhancement when additional drives are installed.
What operating system is pre-installed?
Windows 11 Pro is pre-installed in English language version. This professional edition includes enterprise-grade features such as BitLocker device encryption, Windows Information Protection, remote desktop hosting, and support for joining Azure Active Directory or Group Policy management. The operating system is optimized to take full advantage of the hardware's performance capabilities.
What connectivity options are available on this mini PC?
The workstation provides comprehensive connectivity with six USB ports total, including two SuperSpeed USB Type-C ports supporting 20Gbps signaling rates. Networking includes Gigabit Ethernet, Wi-Fi wireless networking, and Bluetooth for peripheral connections. A DisplayPort output supports external monitor connections. The system also features an English-localized keyboard interface.
What are the physical dimensions and form factor?
The Z2 Mini G9 utilizes a compact mini PC form factor measuring 2.72 inches in height, 8.31 inches in width, and 8.58 inches in depth (69 x 211 x 218 mm). Weighing approximately 5.29 pounds, this small footprint allows flexible placement including VESA mounting behind displays, desktop placement with minimal space requirements, or integration into specialized workstation configurations.
