HP B29Y5UT#ABC Z2 Mini G9 Workstation - Intel Core i7-14700 14th Gen - 32GB DDR5 RAM - 1TB NVMe SSD - Windows 11 Pro French - Mini PC
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the Z2 Mini G9 is the Intel W680 chipset, supporting the LGA-1700 socket Intel Core i7-14700 processor. This 14th Gen CPU operates at a base frequency of 2.10 GHz and features 20 cores (Icosa-core) and 28 threads, providing substantial parallel processing power for technical and creative applications. Memory is configured as a single 32 GB DDR5 SDRAM module in one of two available slots, allowing an upgrade path to 64 GB total capacity. The DDR5 technology offers improved bandwidth and efficiency over previous generations.
Storage is handled by a 1 TB PCI Express NVMe 4.0 x4 solid-state drive, which leverages the NVMe controller for low-latency, high-throughput data access. The storage subsystem supports RAID 0 and RAID 1 configurations, enabling performance optimization or data redundancy based on user needs. Graphics are handled by shared system memory, suitable for professional applications that rely on CPU power rather than dedicated GPU acceleration.
Key Product Advantages
The Z2 Mini G9 combines workstation-class components with a space-saving design, offering a compelling solution for offices, labs, and studios where desk real estate is at a premium. Its Mini PC form factor does not sacrifice key features, maintaining robust connectivity, upgradeable memory, and efficient cooling.
Compact Powerhouse
Despite its small size, this workstation includes a high-core-count Intel Core i7 processor, fast DDR5 memory, and NVMe storage, delivering performance comparable to larger towers.
- Mini PC footprint saves space
- Full workstation performance
- Upgradeable memory and storage
Professional Connectivity
With 10 Gigabit Ethernet, dual USB-C 20Gbps ports, and wireless options, the system supports high-speed data transfers and modern peripherals.
- 10GbE for network-intensive tasks
- USB-C for fast external storage
- WiFi and Bluetooth for flexibility
Deployment / Use Cases
The HP Z2 Mini G9 Workstation is ideal for environments where space efficiency and computing power are both critical. In engineering and design firms, it can serve as a primary workstation for CAD, BIM, or finite element analysis software, handling complex models and simulations while occupying minimal desk space. Its quiet air cooling and professional aesthetics make it suitable for open-plan offices or shared workspaces.
For financial analysts, data scientists, and researchers, the combination of a multi-core processor, large memory capacity, and fast NVMe storage accelerates data processing, statistical analysis, and machine learning workflows. The system's 10GbE connectivity enables rapid access to network-attached storage or data servers, reducing bottlenecks in data-intensive tasks. In educational or training labs, the compact size allows for higher density deployments, and the French OS/keyboard configuration makes it ready for use in French-language institutions.
Localization and Operating System
This workstation is configured for French-speaking users, featuring Windows 11 Pro with the French language pack pre-installed. The operating system includes all the professional features of Windows 11 Pro, such as BitLocker encryption, Remote Desktop, and enhanced security controls, optimized for business and technical use. The included keyboard has a French layout, with appropriate key placements and accents, ensuring a seamless typing experience for local users.
This localization reduces setup time and training overhead for organizations in France, Canada (Quebec), Belgium, Switzerland, and other French-speaking regions. The system is ready for immediate deployment in offices, government agencies, or educational settings where French is the primary language.
Physical Profile
The Z2 Mini G9 measures 2.72 inches (69 mm) in height, 8.31 inches (211 mm) in width, and 8.58 inches (218 mm) in depth, with a weight of approximately 5.29 pounds (2400 grams). This compact form factor allows it to fit easily on desks, mounted behind monitors, or in constrained spaces where traditional towers would not be practical. The chassis is designed for efficient airflow with an air cooler, maintaining optimal temperatures under load while operating quietly.
The small footprint makes it an excellent choice for multi-display setups, kiosks, or point-of-sale environments, and it can be easily transported between locations if needed. Despite its size, the build quality and component layout support reliable long-term operation in professional settings.
- Width
- 8.31" (211 mm)
- Depth
- 8.58" (218 mm)
- Height
- 2.72" (69 mm)
- Weight
- 5.29 lb (2400 g)
What's in the Box
The package includes all essential components for immediate setup and use.
Package contents include Z2 Mini G9 Workstation Keyboard Mouse Power Adapter, Z2 Mini G9 Workstation. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Intel Core i7-14700 14th Gen processor with 20 cores and 28 threads for high-performance computing
- 32 GB of DDR5 SDRAM memory, upgradeable to 64 GB via two available slots
- 1 TB PCI Express NVMe 4.0 x4 SSD for fast boot times and rapid data access
- Windows 11 Pro operating system with French language, pre-installed and ready for use
- 10 Gigabit Ethernet, Wireless LAN, and Bluetooth for versatile connectivity options
- Mini PC form factor with compact dimensions, saving valuable desk space
- French keyboard included, optimized for French-speaking users
- RAID 0 and RAID 1 support for storage performance or redundancy configurations
- 280 W power supply with wide voltage input (120-230 V AC) for global compatibility
- Energy Star, TCO Certified, and other environmental compliances for eco-friendly operation
Specifications
| Specifications | |
|---|---|
| Manufacturer | HP Inc. |
| Manufacturer Part Number | B29Y5UT#ABC |
| Brand Name | HP |
| Product Series | Z2 Mini G9 |
| Product Name | Z2 Mini G9 Workstation |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Core i7 |
| Processor Generation | 14th Gen |
| Processor Model | i7-14700 |
| Processor Core | Icosa-core (20 Core) |
| Processor Threads | 28 |
| Processor Speed | 2.10 GHz |
| Processor Socket | Socket LGA-1700 |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | W680 |
| Memory | |
| Standard Memory | 32 GB |
| Maximum Memory Supported | 64 GB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 2 |
| Memory Configuration | 1 x 32GB |
| Error Checking | Non-ECC |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 1 TB |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Controllers | |
| Controller Type | NVMe |
| RAID Supported | Yes |
| RAID Levels | 0, 1 |
| Display & Graphics | |
| Graphics Memory Accessibility | Shared |
| Network & Communication | |
| Ethernet Technology | 10 Gigabit Ethernet |
| Wireless LAN | Yes |
| Bluetooth | Yes |
| Input Devices | |
| Keyboard Localization | French |
| Interfaces/Ports | |
| Total Number of USB Ports | 6 |
| USB Type-C | Yes |
| USB Type-C Detail | 2 x SuperSpeed USB Type-C 20Gbps signaling rate |
| DisplayPort | Yes |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Operating System Language | French |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Maximum Power Supply Wattage | 280 W |
| Physical Characteristics | |
| Cooler Type | Air Cooler |
| Form Factor | Mini PC |
| Height | 2.72" (69 mm) |
| Width | 8.31" (211 mm) |
| Depth | 8.58" (218 mm) |
| Weight (Approximate) | 5.29 lb (2400 g) |
| Miscellaneous | |
| Package Contents | Z2 Mini G9 Workstation Keyboard Mouse Power Adapter |
| Energy Star | Yes |
| Energy Efficiency Certification | China Energy Conservation Program (CECP) |
| Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| TCO Certified | Yes |
User Manual
FAQ
What processor does the HP Z2 Mini G9 Workstation use?
This workstation is equipped with an Intel Core i7-14700 14th Gen processor. It features 20 cores (Icosa-core) and 28 threads, with a base clock speed of 2.10 GHz. This CPU provides substantial multi-threaded performance for demanding applications like 3D rendering, simulation, and data analysis, making it suitable for professional workloads in a compact form factor.
How much memory is installed, and can it be upgraded?
The system comes with 32 GB of DDR5 SDRAM memory installed as a single 32 GB module. It has two total memory slots, allowing for expansion up to 64 GB by adding another module. The DDR5 technology offers higher bandwidth and improved power efficiency compared to DDR4, supporting faster data transfer for memory-intensive tasks.
What type of storage does this workstation include?
Storage is provided by a 1 TB PCI Express NVMe 4.0 x4 solid-state drive. This NVMe SSD uses the PCIe 4.0 interface for high sequential read and write speeds, reducing load times for applications and large files. The storage controller supports RAID 0 (striping for performance) and RAID 1 (mirroring for redundancy), giving flexibility for data management.
What operating system and localization are pre-installed?
The workstation ships with Windows 11 Pro in French language. This includes the full feature set of Windows 11 Pro, such as enhanced security, BitLocker, and Remote Desktop. A French keyboard is also included in the package, making it ready for deployment in French-speaking regions without additional localization steps.
What networking and connectivity options are available?
Connectivity includes 10 Gigabit Ethernet for high-speed wired networking, integrated Wireless LAN for WiFi connectivity, and Bluetooth for wireless peripherals. The system has six USB ports total, with two being SuperSpeed USB Type-C 20Gbps ports for fast data transfer. A DisplayPort is also included for monitor connections.
What are the dimensions and form factor of this workstation?
The HP Z2 Mini G9 is a Mini PC with dimensions of 2.72" (69 mm) height, 8.31" (211 mm) width, and 8.58" (218 mm) depth. It weighs approximately 5.29 lb (2400 g). This compact form factor saves desk space and allows for flexible placement, such as behind a monitor or in tight workspaces, while still delivering workstation-level performance.
