HP B41KGUA#ABA Z2 Mini G9 Workstation - Intel Core i5-14600 14th Gen - 16GB DDR5256GB NVMe SSD - Windows 11 Pro - Mini PC
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the Z2 Mini G9 is the Intel Core i5-14600 processor, operating at a base frequency of 2.70 GHz with support for Socket LGA-1700. The 14-core design provides substantial parallel processing capability for applications that benefit from multi-threaded performance.
Memory architecture utilizes two DDR5 SDRAM slots populated with 2 x 8 GB modules running in dual-channel mode, offering bandwidth advantages over previous generations. Storage is handled by a PCI Express NVMe solid-state drive with NVMe controller technology, delivering significantly faster read/write speeds compared to SATA-based storage solutions.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The Z2 Mini G9 combines workstation-class components with a space-saving design that fits virtually anywhere. Despite its compact dimensions, it includes professional features like 10 Gigabit Ethernet for high-speed network connectivity and multiple USB-C ports with 20 Gbps signaling rates.
Compact Professional Workstation
Delivers full workstation performance in a Mini PC form factor measuring just 2.72" high, making it ideal for space-constrained environments.
- Small footprint desktop
- Professional component quality
- Enterprise connectivity options
Modern Connectivity Suite
Includes 10 Gigabit Ethernet for high-bandwidth network applications and two SuperSpeed USB Type-C ports with 20 Gbps transfer rates.
- 10GbE networking
- USB-C 20Gbps ports
- DisplayPort output
Enterprise-Ready Platform
Windows 11 Pro provides advanced management features, while the Intel W680 chipset offers platform stability and RAID support for data protection.
- Windows 11 Pro OS
- RAID 0/1 capability
- Professional chipset
Deployment / Use Cases
The HP Z2 Mini G9 Workstation is designed for professional environments where space is at a premium but performance cannot be compromised. Its compact form factor makes it suitable for financial trading desks, engineering workstations in crowded labs, or creative workstations in studio environments.
With 10 Gigabit Ethernet and high-speed USB-C connectivity, this system excels in data-intensive applications such as financial analysis, engineering simulation, and media production workflows. The Mini PC design allows for flexible mounting options including VESA mount compatibility for behind-display installations.
Space-Constrained Professional Environments
Ideal for trading floors, medical imaging stations, or engineering labs where desktop real estate is limited but computational demands are high.
Digital Content Creation
Supports video editing, 3D modeling, and graphic design applications with its multi-core processor and fast NVMe storage.
Localization and Operating System
The HP Z2 Mini G9 Workstation ships with Windows 11 Pro pre-installed, providing a fully localized English operating system environment optimized for professional use. This edition includes advanced management tools, enhanced security features, and enterprise-grade functionality that streamline deployment in business settings.
Windows 11 Pro supports multiple language packs and regional settings, allowing users to customize the interface for their workflow. The operating system efficiently manages hardware resources, ensuring smooth performance for essential applications and professional software suites commonly used in engineering, design, and financial analysis.
This configuration is ready for immediate use in North American markets, with keyboard and input methods aligned to standard English layouts. The pre-loaded OS eliminates setup delays, enabling rapid deployment in environments where time-to-productivity is critical.
Windows 11 Pro for Business
Delivers enterprise-level security, BitLocker encryption, and remote management capabilities, making it suitable for corporate networks and regulated industries.
- Advanced threat protection
- Group Policy management
- Windows Update for Business
Localization and Deployment
Pre-configured with English language settings and regional formats, reducing initial setup time and ensuring compatibility with standard business software in English-speaking markets.
Physical Profile
The Z2 Mini G9 measures 2.72" (69 mm) in height, 8.31" (211 mm) in width, and 8.58" (218 mm) in depth, with a weight of approximately 5.29 lb (2400 g). This compact footprint allows placement in environments where traditional tower workstations would be impractical. The air cooling system maintains optimal operating temperatures while keeping noise levels manageable for office environments.
- Width
- 8.31" (211 mm)
- Depth
- 8.58" (218 mm)
- Height
- 2.72" (69 mm)
- Weight
- 5.29 lb (2400 g)
What's in the Box
The workstation ships complete with all necessary components for immediate setup and operation.
Highlights
- Intel Core i5-14600 14th Gen processor with 14 cores and 20 threads
- 16 GB DDR5 SDRAM memory in dual-channel configuration
- 256 GB NVMe SSD with PCI Express interface for fast storage
- Windows 11 Pro operating system with enterprise features
- Compact Mini PC form factor saves valuable desk space
- 10 Gigabit Ethernet for high-speed network connectivity
- Two SuperSpeed USB Type-C ports with 20 Gbps signaling rates
- Intel W680 chipset with support for RAID 0 and RAID 1
- 280 W power supply ensures stable operation under load
- Includes wireless keyboard and mouse combo for complete setup
Specifications
| Specifications | |
|---|---|
| Manufacturer | HP Inc. |
| Manufacturer Part Number | B41KGUA#ABA |
| Brand Name | HP |
| Product Series | Z2 Mini G9 |
| Product Name | Z2 Mini G9 Workstation |
| Product Type | Workstation |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Core i5 |
| Processor Generation | 14th Gen |
| Processor Model | i5-14600 |
| Processor Core | Tetradeca-core (14 Core) |
| Processor Threads | 20 |
| Processor Speed | 2.70 GHz |
| Processor Socket | Socket LGA-1700 |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | W680 |
| Memory | |
| Standard Memory | 16 GB |
| Maximum Memory Supported | 64 GB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 2 |
| Memory Configuration | 2 x 8GB |
| Error Checking | Non-ECC |
| Storage | |
| Drive Type | SSD |
| Total Solid State Drive Capacity | 256 GB |
| Solid State Drive Interface | PCI Express NVMe |
| Controllers | |
| Controller Type | NVMe |
| RAID Supported | Yes |
| RAID Levels | 0, 1 |
| Display & Graphics | |
| Graphics Memory Accessibility | Shared |
| Network & Communication | |
| Ethernet Technology | 10 Gigabit Ethernet |
| Interfaces/Ports | |
| Total Number of USB Ports | 6 |
| USB Type-C | Yes |
| USB Type-C Detail | 2 x SuperSpeed USB Type-C 20Gbps signaling rate |
| DisplayPort | Yes |
| Operating System | |
| Operating System Platform | Windows |
| Operating System | Windows 11 Pro |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Maximum Power Supply Wattage | 280 W |
| Physical Characteristics | |
| Cooler Type | Air Cooler |
| Form Factor | Mini PC |
| Height | 2.72" (69 mm) |
| Width | 8.31" (211 mm) |
| Depth | 8.58" (218 mm) |
| Weight (Approximate) | 5.29 lb (2400 g) |
| Miscellaneous | |
| Package Contents | Z2 Mini G9 Workstation Wireless Keyboard and mouse combo USB Receiver Power Adapter |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold),Electronic Product Environmental Assessment Tool Climate+ (EPEAT Climate+) |
| Energy Efficiency Certification | China Energy Conservation Program (CECP) |
| Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| TCO Certified | Yes |
| Warranty | |
| Limited Warranty | 1 Year |
| Additional Warranty Information | Support Service Included: HP 4 year Next Business Day Response Onsite Workstation Hardware Support. For terms and conditions, please visit & Manufacturer Warranty: 1 year (1/1/0) limited warranty includes 1 year of parts and labor. No on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply. |
User Manual
FAQ
What processor does this product use?
This product uses the 1 processor for everyday performance and multitasking.
How much memory is installed?
It includes 16 GB of memory to support responsive multitasking and daily workloads.
What storage is included?
The system includes 256 GB of storage for applications, files, and everyday business data.
What graphics or display support is listed?
It features a display specification of Shared, giving you clear visuals for work and media use.
What connectivity options are available?
Connectivity options include 10 Gigabit Ethernet, helping the product integrate into common office or home setups.
What operating system or platform is included?
The included operating environment is Windows, which helps position the product for software compatibility, deployment planning, and day-to-day business use.
