HPE S0F35A#ACJ Instant On 1960 14-Port Managed Switch - 8 x 1G PoE - 4 x 2. 5G PoE+ - 2 x 10G - 2x SFP+ - 480W PoE Budget - 1U Rack-Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This switch implements a comprehensive port architecture designed for mixed-speed environments. The eight Gigabit Ethernet ports with PoE support standard 802.3af/at devices, while the four 2.5 Gigabit Ethernet PoE+ ports deliver higher power and bandwidth for advanced endpoints. Two 10 Gigabit Ethernet copper ports and two SFP+ slots provide high-speed uplinks and backbone connectivity, supporting both twisted pair and optical fiber media.
The switch operates as a full Layer 2 managed device, supporting key networking standards including IEEE 802.1Q for VLANs, 802.3ad for link aggregation, and 802.1x for port-based authentication. Its internal power supply accepts 120V or 230V AC input, with a maximum power consumption of 790W under full load.
This section brings together practical product details such as Total Number of Network Ports, Network (RJ-45), Uplink Port, Media Type Supported, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The HPE Instant On 1960 switch stands out with its high-density PoE design and flexible uplink options, providing a future-ready platform for growing networks.
Substantial PoE Power Budget
With 480W of total PoE budget, this switch can power multiple high-demand devices simultaneously, such as IP cameras, wireless access points, and VoIP phones, without requiring additional midspan injectors.
- Supports PoE, PoE+, and PoE++ devices
- Eliminates need for separate power supplies
Multi-Speed Port Flexibility
The combination of 1G, 2.5G, and 10G ports allows for optimized bandwidth allocation across different network segments, ensuring both legacy and modern devices operate at their maximum potential.
- Backward compatible with 10/100/1000Mbps devices
- 2.5G ports ideal for newer Wi-Fi 6 access points
Professional Rack Integration
The 1U rack-mountable form factor with standard dimensions ensures seamless integration into existing server racks or network cabinets, supporting organized cable management and efficient use of space.
- Standard 19-inch rack width
- Front-to-back airflow design
Deployment / Use Cases
This switch is engineered for small to medium business environments, branch offices, and retail locations where reliable, managed connectivity with Power over Ethernet is essential. Its port mix and uplink capabilities make it suitable for both edge distribution and small network core roles.
Typical deployments include connecting and powering a suite of IP security cameras and access control systems, serving as the backbone for a high-density wireless network with Wi-Fi 6 access points, or providing managed switching for a VoIP telephone system with PoE phones. The SFP+ uplinks enable fiber connections to other switches or routers for extended distance or electrical noise immunity.
Office Network Expansion
Add managed switching capacity to an existing network, providing VLAN segmentation for different departments, QoS for voice traffic, and secure port access control.
IP Surveillance Backbone
Power and connect multiple high-resolution IP cameras directly from the switch, utilizing the PoE budget and managed features for optimized video traffic handling.
Physical Profile
The switch features a durable metal chassis designed for 1U rack mounting in standard 19-inch equipment racks. Its compact dimensions (1.73" height, 17.44" width, 13.78" depth) and 10.8-pound weight make it easy to install and integrate into most network cabinets. The front panel provides clear port status LEDs, while the rear houses the power inlet and grounding point. The design supports typical front-to-back cooling airflow for reliable operation in controlled environments.
- Width
- 17.44" (443 mm)
- Depth
- 13.78" (350 mm)
- Height
- 1.73" (44 mm)
- Weight
- 10.80 lb (4900 g)
Highlights
- 14 total network ports with versatile speed mix: 8x 1G PoE, 4x 2.5G PoE+, 2x 10G, 2x SFP+
- 480W total PoE budget to power multiple IP phones, cameras, and access points
- Full Layer 2 managed switch with VLAN, QoS, link aggregation, and security features
- 1U rack-mountable form factor for standard 19-inch cabinet installation
- Supports both twisted pair (copper) and optical fiber (SFP+) connectivity
- Stack port for easy expansion and simplified management of multiple switches
- Uplink port for cascading to other network devices and extending LAN reach
- Complies with IEEE 802.3, 802.1Q, 802.3ad, 802.1x, and other key networking standards
Specifications
| Specifications | |
|---|---|
| Manufacturer | Hewlett Packard Enterprise |
| Manufacturer Part Number | S0F35AACJ |
| Brand Name | HPE |
| Product Line | Instant On |
| Product Series | 1960 |
| Product Model | S0F35A |
| Product Name | Instant On 1960 8p 1G Class 4 4p SR1G/2.5G Class 6 PoE 2p 10GBASE-T 2p SFP+ 480W Switch |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 14 |
| Network (RJ-45) | Yes |
| Uplink Port | Yes |
| Stack Port | Yes |
| Port/Expansion Slot Details | 8 x Gigabit Ethernet PoE,4 x 2.5 Gigabit Ethernet PoE+,2 x 10 Gigabit Ethernet Network,2 x Gigabit Ethernet Expansion Slot |
| Media & Performance | |
| Media Type Supported | Twisted Pair,Optical Fiber |
| Ethernet Technology | Gigabit Ethernet,10 Gigabit Ethernet,2.5 Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T,1000Base-X,10GBase-T,2.5GBase-T |
| I/O Expansions | |
| Total Number of Expansion Slots | 2 |
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 2 |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.1x,IEEE 802.3,IEEE 802.3u,IEEE 802.1D,IEEE 802.1Q,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.1p,IEEE 802.1s,IEEE 802.1ab |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 480 W |
| Input Voltage | 120 V AC,230 V AC |
| Power Source | Power Supply,AC |
| Power Consumption | 790 W |
| Physical Characteristics | |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable |
| Height | 1.73" (44 mm) |
| Width | 17.44" (443 mm) |
| Depth | 13.78" (350 mm) |
| Weight (Approximate) | 10.80 lb (4900 g) |
User Manual
FAQ
What is the total PoE budget of this switch, and what can it power?
The HPE Instant On 1960 switch provides a 480W total PoE budget. This substantial power allocation can simultaneously support multiple Power over Ethernet devices such as IP phones, wireless access points (including Wi-Fi 6 models), IP security cameras, and access control systems without requiring additional power injectors. The budget is intelligently managed across the PoE-capable ports.
How many and what types of ports does this switch have?
This switch features 14 total network ports. The configuration includes eight Gigabit Ethernet ports with PoE, four 2.5 Gigabit Ethernet ports with PoE+, two 10 Gigabit Ethernet copper ports, and two SFP+ fiber uplink slots. This mix supports a range of devices from legacy Gigabit to modern multi-gigabit equipment.
Is this a managed switch, and what management features does it offer?
Yes, this is a fully manageable Layer 2 switch. It supports essential management protocols including VLAN (IEEE 802.1Q) for network segmentation, Link Aggregation (802.3ad) for increased bandwidth and redundancy, Quality of Service (802.1p) for traffic prioritization, and port-based access control (802.1x). These features provide control over network configuration, security, and performance.
Can this switch be mounted in a standard server rack?
Absolutely. The switch is designed for 1U rack mounting in standard 19-inch wide equipment racks. Its dimensions (1.73" H x 17.44" W x 13.78" D) and front-mount ears make it compatible with most network cabinets and server racks, facilitating organized installation and cable management.
What are the uplink options for connecting this switch to other network equipment?
The switch offers multiple uplink options. It includes two dedicated 10 Gigabit Ethernet copper ports and two SFP+ slots for fiber optic transceivers or direct-attach cables. Additionally, it features a stack port for connecting multiple Instant On switches into a single logical unit and a standard uplink port for cascading to routers or other switches.
What power input does the switch require, and what is its power consumption?
The switch has an internal power supply that accepts both 120V and 230V AC input, making it suitable for use in North America and international locations. Under maximum load with all PoE ports active, the switch consumes up to 790W. Its design includes efficient power management to minimize operational costs.
What uplink, SFP, fiber, or media support detail is listed?
The warranty or support detail listed is Yes, giving buyers a clearer picture of expected coverage after purchase.
Does the product support PoE or wireless networking?
Connectivity support is listed in the product specifications, including the relevant wireless or port options when available.
