HPE P72992-005 ProLiant DL360 Gen11 1U Rack Server - 1x Xeon Silver 4514Y 2 GHz Hexadeca-core - 128 GB DDR5 RAM - 1. 92 TB SSD (2 x 960GB) - SAS
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the DL360 Gen11 is a single Intel Xeon Silver 4514Y processor, a hexadeca-core (16-core) CPU operating at 2 GHz with 30 MB of cache. This 5th Gen processor, paired with the Intel C741 chipset, supports advanced memory technologies, including DDR5 SDRAM with ECC and registered buffering for data integrity.
Storage is managed by the MR408i-o Gen11 controller, which supports both Serial ATA/600 and 12Gb/s SAS interfaces with RAID capabilities. The server includes two PCIe 5.0 expansion slots for adding network, storage, or accelerator cards. Four Gigabit Ethernet ports provide high-speed network connectivity, and five USB ports (including one USB 2.0) offer peripheral flexibility.
This section brings together practical product details such as Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The ProLiant DL360 Gen11 combines enterprise-grade reliability with modern performance features, making it an ideal choice for IT environments that demand both density and expandability. Its 1U form factor maximizes rack space efficiency without sacrificing critical capabilities.
Enhanced Security & Management
HPE iLO 6 provides secure remote management with features like UEFI Secure Boot, TPM 2.0, and FIPS 140-3 validation (in progress). Granular security controls and tamper-free updates ensure compliance and protection against threats.
- Immutable Silicon Root of Trust
- Smart card and Kerberos 2-factor authentication
- Secure firmware recovery and rollback
Scalable Storage Architecture
With nine total expansion bays, including eight hot-swappable 2.5" SFF bays, the server supports significant storage growth. The RAID-capable controller allows for data redundancy and performance optimization across drives.
- Hot-swappable drive bays for easy maintenance
- Support for both SATA and SAS drives
- Flexible storage configurations
Deployment / Use Cases
This server is well-suited for medium to large enterprises deploying virtualized environments, database servers, or application hosting platforms. Its balance of compute, memory, and storage makes it effective for consolidating workloads and improving resource utilization.
Common deployments include Microsoft Hyper-V or VMware ESXi virtualization hosts, SQL Server or Oracle database instances, and web application servers. The redundant power supplies and remote management capabilities ensure high availability and simplify administration in data center or colocation facilities.
Virtualization Host
The 16-core processor and 128 GB of RAM provide ample resources for running multiple virtual machines, while the fast SSD storage reduces latency for guest OS operations.
Business Application Server
Ideal for hosting ERP, CRM, or collaboration software, with Gigabit Ethernet ensuring responsive network performance and the 1U design fitting seamlessly into existing rack infrastructure.
Physical Profile
The DL360 Gen11 adopts a standard 1U rack-mount form factor, measuring 1.69 inches in height, 17.11 inches in width, and 29.65 inches in depth. This compact design allows for high-density deployments in data center racks, with a weight of approximately 45.06 pounds.
The server includes integrated rails for easy installation, and the hot-swappable drive bays and power supplies facilitate maintenance without downtime. The front-accessible design simplifies drive and component access in crowded rack environments.
- Width
- 17.11" (434.60 mm)
- Depth
- 29.65" (753.10 mm)
- Height
- 1U
- Weight
- 45.06 lb (20440 g)
What's in the Box
The package includes all necessary components for immediate deployment and integration into your server infrastructure.
Highlights
- Intel Xeon Silver 4514Y hexadeca-core (16-core) processor at 2 GHz
- 128 GB of DDR5 SDRAM with ECC and registered buffering
- 1.92 TB total SSD storage across two drives with Serial ATA/600 interface
- Nine total expansion bays, including eight hot-swappable 2.5" SFF bays
- Dual 1 kW hot-swappable redundant power supplies for continuous uptime
- Four Gigabit Ethernet ports and five USB ports for connectivity
- HPE iLO 6 remote management with advanced security features
- Support for Windows Server, Linux, and other enterprise operating systems
- 1U rack-mount form factor for high-density deployment
- 3-year warranty with parts, labor, and next-business-day onsite support
Specifications
| Specifications | |
|---|---|
| Manufacturer | Hewlett Packard Enterprise |
| Manufacturer Part Number | P72992-005 |
| Brand Name | HPE |
| Product Line | ProLiant |
| Product Series | DL360 Gen11 |
| Product Name | ProLiant DL360 Gen11 Server |
| Product Type | Server |
| Processor | |
| Number of Processors Supported | 2 |
| Number of Processors Installed | 1 |
| Processor Type | Xeon Silver |
| Processor Generation | 5th Gen |
| Processor Model | 4514Y |
| Processor Core | Hexadeca-core (16 Core) |
| Processor Speed | 2 GHz |
| Cache | 30 MB |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C741 |
| Memory | |
| Standard Memory | 128 GB |
| Maximum Memory Supported | 8 TB |
| Memory Technology | DDR5 SDRAM |
| Number of Occupied Memory Slots | 4 |
| Error Checking | ECC |
| Signal Processing | Registered (Buffered) |
| Storage | |
| Number of Solid State Drives | 2 |
| Total Solid State Drive Capacity | 1.92 TB |
| Solid State Drive Interface | Serial ATA/600 |
| Controllers | |
| Controller Type | Serial ATA/600,12Gb/s SAS |
| Controller Model | MR408i-o Gen11 |
| RAID Supported | Yes |
| I/O Expansions | |
| Number of Total Expansion Bays | 9 |
| Number of External 5.25" Bays | 1 |
| Number of Internal 2.5" Bays | 8 |
| Number of SFF Bays | 8 |
| Hot Swappable Bays | Yes |
| Total Number of Expansion Slots | 2 |
| PCI Express Details | Slot 1 x16 PCIe 5.0 - Full Height; Slot 2 x16 PCIe 5.0 - Low Profile |
| Display & Graphics | |
| Graphics Memory Capacity | 16 MB |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Interfaces/Ports | |
| Total Number of USB Ports | 5 |
| Number of USB 2.0 Ports | 1 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 4 |
| VGA | Yes |
| Remote Management | Yes |
| Remote Management Controller | HPE iLO 6 |
| Operating System | |
| Operating System Supported | Windows Server,Red Hat Enterprise Linux,SuSE Linux Enterprise Server,Oracle Linux,Linux,Ubuntu |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 2 |
| Plug/Connector Type | C13/C14 |
| Maximum Power Supply Wattage | 1 kW |
| Redundant Power Supply | Yes |
| Hot Swappable Power Supply | Yes |
| Miscellaneous | |
| Package Contents | ProLiant DL380 G11 Server 6-foot IEC C-13/C-14 Jumper Cord ProLiant DL3XX Gen11 Easy Install Rail 3 Kit |
| Security Features | UEFI Secure Boot and Secure Start support Immutable Silicon Root of Trust FIPS 140-3 validation (iLO 6 certification in progress) Common Criteria certification (iLO 6 certification in progress) Configurable for PCI DSS compliance Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser Support for Commercial National Security Algorithms (CNSA) iLO Security Modes Granular control over iLO interfaces Smart card (PIV/CAC) and Kerberos based 2-factor Authentication Tamper-free updates - components digitally signed and verified Secure Recovery - recover critical firmware to known good state on detection of compromised firmware Ability to rollback firmware Secure erase of NAND/User Data TPM 2.0 (Trusted Platform Module 2.0) |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Energy Efficiency Certification | ENERGY STAR 4.0 |
| Energy Efficiency Compliance | Energy-related Products Directive Lot 9 (ErP Lot 9) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Physical Characteristics | |
| Form Factor | Rack |
| Rack Height | 1U |
| Height | 1.69" (42.90 mm) |
| Width | 17.11" (434.60 mm) |
| Depth | 29.65" (753.10 mm) |
| Weight (Approximate) | 45.06 lb (20440 g) |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | Server warranty includes 3-year parts, 3-year labor, 3-year onsite support with next business day response. |
User Manual
FAQ
What processor is installed in this HPE ProLiant DL360 Gen11 server?
The server includes one Intel Xeon Silver 4514Y processor, which is a 5th Gen hexadeca-core (16-core) CPU operating at 2 GHz with 30 MB of cache. This processor provides robust performance for enterprise workloads like virtualization and database hosting.
How much memory does this server support, and what type is installed?
The server comes with 128 GB of DDR5 SDRAM installed across four memory slots, using ECC and registered buffering for data integrity. It supports a maximum memory capacity of 8 TB, allowing for significant future expansion as workload demands increase.
What storage configuration and capacity does this server offer?
This configuration includes 1.92 TB of total SSD storage, achieved through two solid-state drives. The storage uses a Serial ATA/600 interface and is managed by an MR408i-o Gen11 controller that supports RAID for data redundancy and performance optimization.
How many drive bays are available for expansion?
The server has nine total expansion bays: eight internal 2.5" small form factor (SFF) bays that are hot-swappable, and one external 5.25" bay. This design allows for flexible storage upgrades and easy maintenance without powering down the system.
What remote management features are included?
The server features HPE iLO 6 for comprehensive out-of-band management. This includes secure remote access, health monitoring, and advanced security capabilities such as UEFI Secure Boot, TPM 2.0, and support for smart card authentication, ensuring reliable administration and compliance.
What power supply configuration does this server use?
It includes two 1 kW hot-swappable power supplies that are redundant, meaning if one fails, the other continues to provide power without interruption. The power supplies support input voltages of 120 V AC and 230 V AC, making the server suitable for global deployment.
What processor or CPU is listed for this server or storage platform?
This product uses the 1 processor for everyday performance and multitasking.
What processor speed is listed?
This product uses the 2 GHz processor for everyday performance and multitasking.
