HPE P58417-B21 ProLiant DL380 G11 2U Rack Server - 1x Xeon Gold 6430 2. 10 GHz 32-Core - 64 GB DDR5 RAM - 8 x 2. 5" Hot-Swap Bays
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
At the core of the DL380 G11 is a single Intel Xeon Gold 6430 processor operating at 2.10 GHz with 32 cores and 60 MB of L3 cache. The Intel C741 chipset provides the foundation for memory and I/O, supporting up to 32 DDR5 DIMM slots with ECC and registered buffering for data integrity. The installed 64 GB of DDR5 SDRAM offers high bandwidth and efficiency for memory-intensive applications.
Storage flexibility comes from eight 2.5" small form factor bays, all hot-swappable for maintenance without downtime, managed by a Serial ATA controller. Three PCIe expansion slots (x8, x16, x8) allow for network, storage, or accelerator card additions. Networking includes dual-speed 10/25 Gigabit Ethernet ports for high-throughput data center connectivity.
This section brings together practical product details such as Number of Processors Installed, Processor Type, Processor Generation, Chipset Manufacturer, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The ProLiant DL380 G11 combines modern hardware with HPE's management and security ecosystem to reduce operational complexity. Its 2U density optimizes rack space while delivering substantial compute and storage capacity for virtualized environments, databases, and business applications.
Advanced Security
Hardware-rooted security includes UEFI Secure Boot, immutable silicon root of trust, FIPS 140-2 validation, Common Criteria certification, and support for AES/3DES encryption. Tamper-free updates and secure recovery protect firmware integrity.
- UEFI Secure Boot
- FIPS 140-2 Validated
- Common Criteria Certified
Reliable Power & Cooling
A 1 kW hot-swappable power supply ensures high availability, with support for a second unit for redundancy. The 2U chassis provides efficient airflow and thermal management for sustained performance.
- 1 kW Hot-Swap PSU
- 120/230 V AC Input
- Redundant Capable
Deployment / Use Cases
This server is suited for IT environments where density, performance, and manageability are priorities. Its configuration supports general-purpose server roles, mid-tier virtualization hosts, and storage-heavy applications.
Typical deployments include virtual machine hosts in private clouds, database servers for transactional systems, file and application servers in medium to large businesses, and infrastructure nodes for DevOps or containerized workloads. The 8-bay storage capacity allows for RAID configurations to balance performance and redundancy.
Virtualization Host
With 32 cores and 64 GB of DDR5 memory, the DL380 G11 can host multiple virtual machines, making it ideal for consolidating physical servers or running hypervisors like VMware vSphere or Microsoft Hyper-V.
Storage Server
Eight hot-swappable 2.5" bays provide ample storage for file serving, backup targets, or NAS duties when paired with appropriate drives and RAID configurations.
Physical Profile
Designed for standard 19-inch racks, the DL380 G11 occupies 2U of vertical space with dimensions of 3.44 inches in height, 17.64 inches in width, and 28.62 inches in depth. Its weight of approximately 72.75 pounds includes the chassis, installed components, and power supply.
The rack-mount form factor includes tool-less rails and a cable management arm for simplified installation and maintenance. The compact 2U height maximizes rack density while allowing sufficient airflow for cooling high-performance components.
- Width
- 17.64" (448.06 mm)
- Depth
- 28.62" (726.95 mm)
- Height
- 2U
- Weight
- 72.75 lb (33000 g)
What's in the Box
The package includes all necessary components for immediate deployment into a rack environment.
Highlights
- Intel Xeon Gold 6430 32-core 2.10 GHz processor with 60 MB cache
- 64 GB of DDR5 SDRAM ECC registered memory for reliable performance
- 8 hot-swappable 2.5" drive bays for flexible storage expansion
- 10/25 Gigabit Ethernet ports for high-speed network connectivity
- HPE iLO 6 remote management for out-of-band administration
- 2U rack form factor with tool-less rails for easy installation
- 1 kW hot-swappable power supply with 120/230 V AC input
- Supports Windows Server, Linux distributions, and Citrix XenServer
- Comprehensive hardware security with UEFI Secure Boot and FIPS validation
- ENERGY STAR 3.0 certified for energy efficiency
Specifications
| Specifications | |
|---|---|
| Manufacturer | Hewlett Packard Enterprise |
| Manufacturer Part Number | P58417-B21 |
| Brand Name | HPE |
| Product Line | ProLiant |
| Product Series | DL380 G11 |
| Product Name | ProLiant DL380 G11 Server |
| Product Type | Server |
| Processor | |
| Number of Processors Installed | 1 |
| Processor Type | Xeon Gold |
| Processor Generation | 4th Gen |
| Processor Model | 6430 |
| Processor Core | Dotriaconta-core (32 Core) |
| Processor Speed | 2.10 GHz |
| Cache | 60 MB |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C741 |
| Memory | |
| Standard Memory | 64 GB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 32 |
| Number of Occupied Memory Slots | 2 |
| Error Checking | ECC |
| Signal Processing | Registered (Buffered) |
| Controllers | |
| Controller Type | Serial ATA |
| I/O Expansions | |
| Number of Total Expansion Bays | 8 |
| Number of Internal 2.5" Bays | 8 |
| Number of SFF Bays | 8 |
| Hot Swappable Bays | Yes |
| Total Number of Expansion Slots | 3 |
| PCI Express Details | PCIe Slots 3-slots (x8, x16, x8) |
| Display & Graphics | |
| Graphics Memory Capacity | 16 MB |
| Network & Communication | |
| Ethernet Technology | 10 Gigabit Ethernet,25 Gigabit Ethernet |
| Interfaces/Ports | |
| Total Number of USB Ports | 4 |
| Number of USB 3.0 Ports | 3 |
| VGA | Yes |
| Remote Management | Yes |
| Remote Management Controller | HPE iLO 6 |
| Operating System | |
| Operating System Supported | Windows Server,Red Hat Enterprise Linux,SuSE Linux Enterprise Server,Ubuntu Server,Oracle Linux,Citrix XenServer |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 1 |
| Plug/Connector Type | C13/C14 |
| Maximum Power Supply Wattage | 1 kW |
| Hot Swappable Power Supply | Yes |
| Miscellaneous | |
| Package Contents | ProLiant DL380 G11 Server 6-foot IEC C-13/C-14 Jumper Cord SFF Easy Install Rail Kit Cable Management Arm |
| Security Features | UEFI Secure Boot and Secure Start support Tamper-free updates - components digitally signed and verified Immutable Silicon Root of Trust Ability to rollback firmware FIPS 140-2 validation Secure erase of NAND/User data Common Criteria certification Configurable for PCI DSS compliance Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser Support for Commercial National Security Algorithms (CNSA) Secure Recovery - recover critical firmware to known good state on detection of compromised firmware |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Energy Efficiency Certification | ENERGY STAR 3.0 |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Physical Characteristics | |
| Form Factor | Rack |
| Rack Height | 2U |
| Height | 3.44" (87.38 mm) |
| Width | 17.64" (448.06 mm) |
| Depth | 28.62" (726.95 mm) |
| Weight (Approximate) | 72.75 lb (33000 g) |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 3/3/3: Server Warranty includes three years of parts, three years of labor, and three years of onsite support coverage. |
User Manual
FAQ
What processor is installed in this HPE ProLiant DL380 G11 server?
This server includes one Intel Xeon Gold 6430 processor with 32 cores running at a base frequency of 2.10 GHz. It features 60 MB of L3 cache and is based on the 4th Gen Intel Xeon Scalable architecture, providing high core density and efficiency for enterprise workloads.
How much memory is installed and what type does it use?
The server comes with 64 GB of DDR5 SDRAM installed across two of its 32 available memory slots. The memory is ECC (Error-Correcting Code) and registered (buffered), ensuring data integrity and stability in mission-critical environments. DDR5 technology offers higher bandwidth and improved power efficiency compared to previous generations.
How many drive bays does this server have and are they hot-swappable?
It has eight 2.5" small form factor drive bays, all of which are hot-swappable. This allows you to replace or add drives without powering down the server, minimizing downtime for storage maintenance or expansion. The bays are managed by a Serial ATA controller.
What networking capabilities are included?
The DL380 G11 includes Ethernet ports supporting both 10 Gigabit Ethernet and 25 Gigabit Ethernet speeds. This dual-speed capability provides high-throughput connectivity suitable for data center networks, virtualization clusters, and storage area networks, reducing bottlenecks for data-intensive applications.
What remote management features are available?
HPE's Integrated Lights-Out 6 (iLO 6) provides comprehensive remote management. This includes out-of-band access for power control, hardware monitoring, virtual media, and remote console functionality even if the operating system is unresponsive. iLO 6 enhances administrative efficiency and reduces the need for physical access to the server.
What is the power supply configuration and warranty?
The server includes one 1 kW hot-swappable power supply that supports input voltages of 120 V AC or 230 V AC. It is designed to support a second power supply for redundancy. HPE backs this server with a 3-year warranty covering parts, labor, and onsite support, providing peace of mind for business deployments.
What processor or CPU is listed for this server or storage platform?
This product uses the Xeon Gold processor for everyday performance and multitasking.
What processor speed is listed?
This product uses the 2.10 GHz processor for everyday performance and multitasking.
