HPE P72983-005 ProLiant DL380 G11 2U Rack Server - 1x Xeon Silver 4510 2. 40GHz 12-Core - 64GB DDR5 RAM - 4. 80TB SAS HDD - 8x Hot-Swap Bays - Dual 1kW
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This ProLiant DL380 G11 server features a single Intel Xeon Silver 4510 processor with 12 cores operating at 2.40GHz base frequency and 30MB of L3 cache. The platform supports a second processor for future expansion, allowing organizations to scale compute performance as workload demands increase.
Memory architecture utilizes DDR5 SDRAM technology with registered/buffered modules for enhanced signal integrity and capacity scaling. The installed 64GB configuration occupies just 2 of the available memory slots, leaving substantial room for memory expansion up to the platform's 8TB maximum supported capacity.
This section brings together practical product details such as Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The DL380 G11 balances immediate performance with long-term infrastructure flexibility. The 8-bay storage design accommodates both current 2-drive configuration and future expansion to maximize storage density within the 2U rack space. Hot-swappable components throughout—from drive bays to power supplies—enable maintenance without service interruption.
Enterprise Management
HPE iLO 6 provides comprehensive remote management with Secure Boot, UEFI Shell, workload profiling, and mass deployment capabilities through Redfish-compliant RESTful APIs.
- Secure Boot & Secure Start
- PXE boot with IPv6 support
- Workload performance optimization
Storage Flexibility
The MR408i-o Gen11 controller supports both SAS and SATA drives with RAID functionality, while 8 hot-swappable bays allow mixed drive configurations and easy capacity upgrades.
- 12Gb/s SAS interface
- Support for >2.2TB boot drives
- Hot-swappable drive replacement
Deployment / Use Cases
The ProLiant DL380 G11 serves as an ideal platform for virtualized environments, mid-tier database applications, and business-critical application hosting. Its balanced configuration of compute, memory, and storage resources makes it suitable for consolidation projects where multiple workloads share physical infrastructure.
Organizations deploying this server can leverage it for Microsoft Hyper-V or VMware vSphere virtualization hosts, Microsoft SQL Server or MySQL database instances, file and print services, or as an application server for enterprise resource planning (ERP) and customer relationship management (CRM) systems. The 2U form factor optimizes rack space utilization in standard data center cabinets.
Virtualization Host
With 12 processor cores and 64GB of DDR5 memory, this server can host multiple virtual machines for server consolidation projects.
Business Application Server
The combination of SAS storage performance and enterprise management features supports reliable operation of line-of-business applications.
Physical Profile
Designed for standard 19-inch rack cabinets, the DL380 G11 occupies 2 rack units (2U) of vertical space with dimensions of 3.44" height, 17.64" width, and 28.62" depth. The 72.75-pound weight reflects the server's robust construction and component density. The included ProLiant DL3XX Gen11 Easy Install Rail 3 Kit simplifies rack mounting and service access in data center environments.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 2U, 17.64" (448 mm), 28.62" (727 mm), 72.75 lb (33000 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 17.64" (448 mm)
- Depth
- 28.62" (727 mm)
- Height
- 2U
- Weight
- 72.75 lb (33000 g)
What's in the Box
The server ships with all necessary components for immediate deployment in a rack environment.
Highlights
- Intel Xeon Silver 4510 12-core processor at 2.40GHz with 30MB cache
- 64GB DDR5 SDRAM memory with registered/buffered modules
- 4.80TB total storage via 2x 2.4TB 12Gb/s SAS hard drives (10,000 RPM)
- 8 hot-swappable 2.5" drive bays for storage expansion
- Dual 1kW hot-swappable redundant power supplies
- 4 Gigabit Ethernet ports for network connectivity
- HPE iLO 6 remote management with Redfish API support
- 2U rack-mount form factor for data center deployment
- Support for Windows Server, Linux, and other enterprise operating systems
- 3-year warranty with parts, labor, and next-business-day onsite support
Specifications
| Specifications | |
|---|---|
| Manufacturer | Hewlett Packard Enterprise |
| Manufacturer Part Number | P72983-005 |
| Brand Name | HPE |
| Product Line | ProLiant |
| Product Series | DL380 G11 |
| Product Name | ProLiant DL380 G11 Server |
| Product Type | Server |
| Processor | |
| Number of Processors Supported | 2 |
| Number of Processors Installed | 1 |
| Processor Type | Xeon Silver |
| Processor Generation | 5th Gen |
| Processor Model | 4510 |
| Processor Core | Dodeca-core (12 Core) |
| Processor Speed | 2.40 GHz |
| Cache | 30 MB |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C741 |
| Memory | |
| Standard Memory | 64 GB |
| Maximum Memory Supported | 8 TB |
| Memory Technology | DDR5 SDRAM |
| Number of Occupied Memory Slots | 2 |
| Signal Processing | Registered (Buffered) |
| Storage | |
| Number of Hard Drives | 2 |
| Total Hard Drive Capacity | 4.80 TB |
| Hard Drive Interface | 12Gb/s SAS |
| Hard Drive RPM | 10000 |
| Controllers | |
| Controller Type | Serial ATA/600,12Gb/s SAS |
| Controller Model | MR408i-o Gen11 |
| RAID Supported | Yes |
| I/O Expansions | |
| Number of Total Expansion Bays | 8 |
| Number of Internal 2.5" Bays | 8 |
| Number of SFF Bays | 8 |
| Hot Swappable Bays | Yes |
| Total Number of Expansion Slots | 3 |
| PCI Express Details | 3-slots (x8, x16, x8) as standard |
| Display & Graphics | |
| Graphics Memory Capacity | 16 MB |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Interfaces/Ports | |
| Total Number of USB Ports | 4 |
| Number of USB 2.0 Ports | 1 |
| Number of USB 3.0 Ports | 2 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 4 |
| VGA | Yes |
| Remote Management | Yes |
| Remote Management Controller | HPE iLO 6 |
| Operating System | |
| Operating System Supported | Windows Server,Red Hat Enterprise Linux,SuSE Linux Enterprise Server,Oracle Linux,Ubuntu Server |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 2 |
| Plug/Connector Type | C13/C14 |
| Maximum Power Supply Wattage | 1 kW |
| Redundant Power Supply | Yes |
| Hot Swappable Power Supply | Yes |
| Miscellaneous | |
| Package Contents | ProLiant DL380 G11 Server 6-foot IEC C-13/C-14 Jumper Cord ProLiant DL3XX Gen11 Easy Install Rail 3 Kit |
| Security Features | Secure Boot and Secure Start enable for enhanced security Embedded UEFI Shell Operating system specific functionality Mass Configuration Deployment Tool using iLO RESTful API that is Redfish API Conformant Support for > 2.2 TB (using GPT) boot drives PXE boot support for IPv6 networks USB 3.0 Stack Workload Profiles for simple performance optimization |
| Energy Star | Yes |
| Energy Efficiency Compliance | Energy-related Products Directive Lot 9 (ErP Lot 9) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Physical Characteristics | |
| Form Factor | Rack |
| Rack Height | 2U |
| Height | 3.44" (87.50 mm) |
| Width | 17.64" (448 mm) |
| Depth | 28.62" (727 mm) |
| Weight (Approximate) | 72.75 lb (33000 g) |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | Server warranty includes 3-year parts, 3-year labor, 3-year onsite support with next business day response. |
User Manual
FAQ
What processor does this HPE ProLiant DL380 G11 server include?
This server includes one Intel Xeon Silver 4510 processor with 12 cores (dodeca-core) operating at a base frequency of 2.40GHz. The processor features 30MB of L3 cache and is based on Intel's 5th Gen Xeon Scalable architecture. The platform supports adding a second processor for future performance expansion.
How much memory is installed and what type does it use?
The server comes with 64GB of DDR5 SDRAM installed across 2 memory slots using registered (buffered) modules. This memory technology provides improved data rates and signal integrity compared to previous generations. The platform supports memory expansion up to 8TB maximum capacity as workload requirements grow.
What storage configuration does this server have?
This configuration includes 4.80TB of total storage capacity delivered through two 2.4TB 12Gb/s SAS hard drives operating at 10,000 RPM. The storage is managed by an MR408i-o Gen11 controller that supports both SAS and SATA interfaces with RAID functionality for data protection.
How many drive bays are available for expansion?
The ProLiant DL380 G11 provides 8 hot-swappable 2.5" small form factor (SFF) drive bays. Currently 2 bays are occupied with the included hard drives, leaving 6 empty bays available for immediate or future storage expansion. All bays support hot-swap replacement for maintenance without server downtime.
What remote management capabilities does this server offer?
The server includes HPE iLO 6 (Integrated Lights-Out) remote management technology. This provides comprehensive out-of-band management including power control, hardware monitoring, virtual media, and remote console access. iLO 6 implements the Redfish API standard for programmatic management and supports features like Secure Boot, UEFI Shell, and workload performance profiling.
What power supply configuration does this server use?
This server includes two 1-kilowatt (1kW) hot-swappable power supplies configured for redundancy. The power supplies use standard C13/C14 connectors and support both 120V and 230V AC input voltages. The hot-swappable design allows replacement of a failed power supply without powering down the server, maintaining continuous operation.
What processor or CPU is listed for this server or storage platform?
This product uses the 1 processor for everyday performance and multitasking.
What processor speed is listed?
This product uses the 2.40 GHz processor for everyday performance and multitasking.
