HPE P74440-005 ProLiant MicroServer Gen11 Ultra Micro Tower Server - Xeon E-2434 3. 40 GHz - 32 GB RAM - 4 TB HDD
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The ProLiant MicroServer Gen11 leverages the Intel C262 chipset to coordinate communication between the Xeon E-2434 processor, memory, storage, and expansion components. The processor includes 12 MB of cache to accelerate frequently accessed data, while the DDR5 memory architecture delivers improved bandwidth over previous generations.
Storage connectivity is implemented through a dedicated Serial ATA/600 controller that supports the installed 4 TB hard drive and additional drives in the available bays. The 7200 RPM spindle speed balances capacity with responsive data access for typical server workloads.
Expansion capabilities include two PCIe slots: one PCIe Gen5 x16 low-profile slot and one PCIe Gen4 x8 low-profile slot. These allow for the addition of network adapters, storage controllers, or specialized accelerator cards to tailor the server to specific application requirements.
Relevant factors for this section include Number of Processors Supported, Number of Processors Installed, Processor Type, Chipset Manufacturer. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The Ultra Micro Tower form factor combines enterprise server capabilities with a footprint suitable for office environments, retail locations, or constrained data center spaces. This design eliminates the need for dedicated server racks while maintaining the reliability and management features expected from HPE ProLiant systems.
Comprehensive Security Framework
Built-in security features include UEFI Secure Boot, Immutable Silicon Root of Trust, FIPS 140-2 validation, Common Criteria certification, and TPM 2.0. These technologies help protect against firmware attacks and ensure secure boot processes.
- Configurable for PCI DSS compliance
- Secure erase of NAND/user data
- Firmware rollback capability
Enhanced Physical Security
The server includes multiple physical security options to prevent unauthorized access to components and data.
- Front bezel lock feature
- Standard padlock slot
- Kensington lock slot
- Power cord clip
Deployment / Use Cases
The ProLiant MicroServer Gen11 is engineered for environments where full-size rack servers are impractical but enterprise-grade reliability remains essential. Its compact dimensions and quiet operation make it suitable for placement in office closets, retail back rooms, or small network cabinets.
Typical deployments include file and print serving for small offices, lightweight database hosting, network infrastructure services like DNS or DHCP, and dedicated application servers for business software. The four Gigabit Ethernet ports enable network segmentation, link aggregation, or connection to multiple network segments without additional hardware.
Small Business Infrastructure
Provides centralized storage, user authentication, and application hosting for businesses with 10-50 employees. The 4 TB storage capacity accommodates document repositories, email archives, and backup targets.
Branch Office Server
Delivers local services at remote locations while maintaining connectivity to central data centers. The compact form factor fits in wiring closets or under-desk locations common in branch offices.
Physical Profile
The Ultra Micro Tower chassis measures 6.06" (153.92 mm) in height, 10.28" (261.11 mm) in width, and 9.82" (249.43 mm) in depth, with an approximate weight of 17.57 lb (7.97 kg). These compact dimensions allow placement on desktops, shelves, or in compact server enclosures where traditional tower or rack servers would not fit.
The external 180 W power adapter reduces internal heat generation and contributes to the server's quiet operation profile. The C5 power connector and included 6-foot power cord provide reliable power delivery without consuming valuable internal chassis space.
- Width
- 10.28" (261.11 mm)
- Depth
- 9.82" (249.43 mm)
- Height
- 6.06" (153.92 mm)
- Weight
- 17.57 lb (7970.07 g)
What's in the Box
The server ships with all necessary components for immediate deployment in typical business environments.
Highlights
- Intel Xeon E-2434 quad-core processor at 3.40 GHz with 12 MB cache
- 32 GB DDR5 SDRAM with ECC error checking for data integrity
- 4 TB 7200 RPM hard drive with Serial ATA/600 interface
- Four 3.5" large form factor drive bays for storage expansion
- Ultra Micro Tower form factor for space-constrained deployments
- Four Gigabit Ethernet ports for network connectivity
- Two PCIe expansion slots (Gen5 x16 and Gen4 x8)
- Comprehensive security features including TPM 2.0 and UEFI Secure Boot
- Supports Windows Server and Linux operating systems
- 180 W external power adapter with universal voltage input
Specifications
| Specifications | |
|---|---|
| Manufacturer | Hewlett Packard Enterprise |
| Manufacturer Part Number | P74440-005 |
| Brand Name | HPE |
| Product Line | ProLiant |
| Product Series | MicroServer Gen11 |
| Product Name | ProLiant MicroServer Gen11 Server |
| Product Type | Server |
| Processor | |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | Xeon |
| Processor Model | E-2434 |
| Processor Core | Quad-core (4 Core) |
| Processor Speed | 3.40 GHz |
| Cache | 12 MB |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C262 |
| Memory | |
| Standard Memory | 32 GB |
| Maximum Memory Supported | 128 GB |
| Memory Technology | DDR5 SDRAM |
| Total Number of Memory Slots | 4 |
| Number of Occupied Memory Slots | 1 |
| Error Checking | ECC |
| Signal Processing | Unregistered (Unbuffered) |
| Storage | |
| Total Hard Drive Capacity | 4 TB |
| Hard Drive Interface | Serial ATA/600 |
| Hard Drive RPM | 7200 |
| Controllers | |
| Controller Type | Serial ATA/600 |
| Controller Model | Intel VROC |
| I/O Expansions | |
| Number of Total Expansion Bays | 4 |
| Number of 3.5" Bays | 4 |
| Number of LFF Bays | 4 |
| Hot Swappable Bays | No |
| Total Number of Expansion Slots | 2 |
| PCI Express Details | (1) PCIe Gen5 low-profile slot (PCIe5 x16) Low Profile,(1) PCIe Gen4 low-profile slot (PCIe4 x8) Low Profile |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Interfaces/Ports | |
| Total Number of USB Ports | 6 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 4 |
| VGA | Yes |
| DisplayPort | Yes |
| Operating System | |
| Operating System Supported | Windows Server,Linux |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Number of Power Supplies Supported | 1 |
| Number of Power Supplies Installed | 1 |
| Plug/Connector Type | C5 |
| Maximum Power Supply Wattage | 180 W |
| Redundant Power Supply | No |
| Miscellaneous | |
| Package Contents | ProLiant MicroServer Gen11 Server 1 x 180W External Power Adapter 6 ft/1.83m C5 Power Cord |
| Security Features | UEFI Secure Boot and Secure Start support Immutable Silicon Root of Trust FIPS 140-2 validation Common Criteria certification Configurable for PCI DSS compliance Ability to rollback firmware Secure erase of NAND/User data TPM (Trusted Platform Module) 2.0 Gen 11 Front bezel lock feature, standard Padlock slot, standard Kensington Lock slot, standard Power cord clip, standard |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Physical Characteristics | |
| Form Factor | Ultra Micro Tower |
| Height | 6.06" (153.92 mm) |
| Width | 10.28" (261.11 mm) |
| Depth | 9.82" (249.43 mm) |
| Weight (Approximate) | 17.57 lb (7970.07 g) |
| Warranty | |
| Limited Warranty | 1 Year |
| Additional Warranty Information | Server warranty includes 1-year parts, 1-year labor, and 1-year onsite support with next business day response. Warranty repairs may be accomplished using Customer Self Repair (CSR) parts. These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when customers decline to replace a Mandatory CSR part, 2) Optional CSR parts are also designed for easy replacement but may involve added complexity. Customers may choose to have Hewlett Packard Enterprise replace Optional CSR parts at no charge. 3) A trained, authorized service engineer must service non-CSR parts. |
User Manual
FAQ
What is the maximum memory capacity of this HPE MicroServer?
The HPE ProLiant MicroServer Gen11 supports up to 128 GB of DDR5 SDRAM across its four memory slots. The system ships with 32 GB installed in one slot, leaving three additional slots available for memory expansion. This capacity supports memory-intensive applications and virtualization workloads in small business environments.
How many hard drives can this server accommodate?
This server includes four 3.5" large form factor drive bays, all of which support standard SATA hard drives. The system ships with one 4 TB 7200 RPM hard drive installed, leaving three bays available for additional storage expansion. The bays are not hot-swappable, requiring system shutdown for drive installation or replacement.
What expansion slots are available on this MicroServer?
The server provides two PCI Express expansion slots: one PCIe Gen5 x16 low-profile slot and one PCIe Gen4 x8 low-profile slot. These slots accommodate standard low-profile expansion cards for additional networking, storage controllers, or specialized computing accelerators, allowing customization for specific application requirements.
What operating systems are supported by this HPE server?
The ProLiant MicroServer Gen11 supports both Windows Server and Linux operating systems. This compatibility provides flexibility for organizations to deploy their preferred server platform, whether for Microsoft-based environments, open-source solutions, or mixed infrastructure deployments requiring interoperability between different operating systems.
What security features does this server include?
Security features include UEFI Secure Boot and Secure Start support, Immutable Silicon Root of Trust, FIPS 140-2 validation, Common Criteria certification, configurable PCI DSS compliance, firmware rollback capability, secure erase of NAND/user data, and TPM 2.0. Physical security options include front bezel lock, padlock slot, Kensington lock slot, and power cord clip.
What is the form factor and dimensions of this server?
The server uses an Ultra Micro Tower form factor measuring 6.06" (153.92 mm) in height, 10.28" (261.11 mm) in width, and 9.82" (249.43 mm) in depth, with an approximate weight of 17.57 lb (7.97 kg). This compact design allows placement in office environments, retail locations, or other spaces where traditional server racks are not available or practical.
