Product Features
Specification Compliance: ATX12V/EPS12V
Efficiency: 90%
Number of Fans: 1
Modular: Yes
Input Voltage: 120 V AC,230 V AC
Number of +12V Rails: 1
Output Voltage: 5 V DC,12 V DC,3.3 V DC,-12 V DC
Output Voltage Detail: 5 V DC @ 22 A,12 V DC @ 54.2 A,3.3 V DC @ 22 A,-12 V DC @ 0.3 A,5 V DC @ 3 A
Output Current: 22 A,54.20 A,300 mA,3 A
Output Power: 650 W
Form Factor: Internal
Height: 3.39" (86 mm)
Width: 5.91" (150 mm)
Weight (Approximate): 2.35 kg
Country of Origin: Taiwan
Environmentally Friendly: Yes
Energy Efficiency Certification: 80 Plus Gold
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Limited Warranty: 5 Year
[custom-specifications]
| Specifications | |
| Manufacturer | In Win Development, Inc |
| Manufacturer Part Number | P65 |
| Manufacturer Website Address | http://www.in-win.us |
| Brand Name | In Win |
| Product Series | P |
| Product Model | IW-PS-P650W |
| Product Name | IW-PS-P650W Power Supply |
| Product Type | Power Supply |
| Technical Information | |
| Specification Compliance | ATX12V/EPS12V |
| Efficiency | 90% |
| Number of Fans | 1 |
| Modular | Yes |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Number of +12V Rails | 1 |
| Output Voltage | 5 V DC,12 V DC,3.3 V DC,-12 V DC |
| Output Voltage Detail | 5 V DC @ 22 A,12 V DC @ 54.2 A,3.3 V DC @ 22 A,-12 V DC @ 0.3 A,5 V DC @ 3 A |
| Output Current | 22 A,54.20 A,300 mA,3 A |
| Output Power | 650 W |
| Physical Characteristics | |
| Form Factor | Internal |
| Height | 3.39" (86 mm) |
| Width | 5.91" (150 mm) |
| Weight (Approximate) | 2.35 kg |
| Miscellaneous | |
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| Energy Efficiency Certification | 80 Plus Gold |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 5 Year |
[/custom-specifications]
