Intellinet Ethernet Switch - 5 Ports - Gigabit Ethernet - 10Base-T, 100Base-TX, 1000Base-T - 2 Layer Supported - 85 W PoE Budget - - - (509220)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Features: Auto Sensing,Auto-negotiation,Flow Control,Fanless,Plug and Play,Surge Protection
Total Number of Network Ports: 5
Network (RJ-45): Yes
Uplink Port: Yes
Port/Expansion Slot Details: 4 x Gigabit Ethernet PoE+,1 x Gigabit Ethernet PoE++
Media Type Supported: Twisted Pair
Ethernet Technology: Gigabit Ethernet
Network Technology: 10Base-T,100Base-TX,1000Base-T
Switching Capacity: 1.25 GB/s
Layer Supported: 2
Networking Standards: IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3bt,IEEE 802.3u,IEEE 802.3x
PoE (RJ-45) Port: Yes
PoE Budget: 85 W
Input Voltage: 50 V DC,57 V DC
Power Source: PoE++
Product Material: Plastic
Form Factor: Wall Mountable,Pole Mount
Height: 2.56" (65 mm)
Width: 8.11" (206 mm)
Length: 11.77" (299 mm)
Weight (Approximate): 1.42 lb (645 g)
- Cascade to other network devices through the uplink port to expand your local area network
- Quickly and easily set up a wired network with 5 networking ports
- Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
- With Wall mounting feature, you can conveniently install the switch while keeping the wires and cables organized
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
[custom-specifications]
| Specifications | |
| Manufacturer | IC INTRACOM |
| Manufacturer Part Number | 509220 |
| Manufacturer Website Address | http://www.icintracom.com |
| Brand Name | Intellinet |
| Product Name | Ethernet Switch |
| Product Type | Ethernet Switch |
| Technical Information | |
| Features | Auto Sensing,Auto-negotiation,Flow Control,Fanless,Plug and Play,Surge Protection |
| Interfaces/Ports | |
| Total Number of Network Ports | 5 |
| Network (RJ-45) | Yes |
| Uplink Port | Yes |
| Port/Expansion Slot Details | 4 x Gigabit Ethernet PoE+,1 x Gigabit Ethernet PoE++ |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10Base-T,100Base-TX,1000Base-T |
| Switching Capacity | 1.25 GB/s |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3bt,IEEE 802.3u,IEEE 802.3x |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 85 W |
| Input Voltage | 50 V DC,57 V DC |
| Power Source | PoE++ |
| Physical Characteristics | |
| Product Material | Plastic |
| Form Factor | Wall Mountable,Pole Mount |
| Height | 2.56" (65 mm) |
| Width | 8.11" (206 mm) |
| Length | 11.77" (299 mm) |
| Weight (Approximate) | 1.42 lb (645 g) |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
Additional-pdf4
Additional-pdf1
Additional-pdf3
Additional-pdf2
Additional-pdf5
[/custom-user-manual]
