Intellinet Gigabit Ethernet Media Converter - 1 x Network (RJ-45) - 1 x SC Ports - DuplexSC Port - Multi-mode - 850 nm Fiber - Gigabit (508544)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
- Gigabit Ethernet Media Converter
- External Power Adapter
- Instructions
Total Number of Ports: 2
Network (RJ-45): Yes
Number of Network (RJ-45) Ports: 1
Number of SC Ports: 1
SC Port Type: Duplex
Media Type Supported: Twisted Pair,Optical Fiber
Fiber Mode Supported: Multi-mode
Fiber Optic Cable Wavelength: 850 nm
Maximum Distance Supported: 0.55 km (0.34 Mile)
Fiber Optic Cable Core/Cladding Specification: 62.5/125 µm,50/125 µm
Ethernet Technology: Gigabit Ethernet
Network Technology: 10/100/1000Base-T,1000Base-SX,10Base-T,100Base-TX,1000Base-X,10/100/1000Base-TX
Power Source: Power Adapter
Plug/Connector Type: DC Jack
Form Factor: Compact,Desktop,Wall Mountable,Rack-mountable,Chassis Mount
Height: 2.76" (70 mm)
Width: 3.70" (94 mm)
Depth: 1.02" (26 mm)
Weight (Approximate): 10.58 oz (300 g)
Package Contents:
Environmental Compliance: Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin: China
Limited Warranty: 3 Year
- One 10/100/1000 RJ45 port supporting a maximum distance of 100 m (300 ft.)
- One 1000Base-SX fiber SC multi-mode port supporting a maximum distance of 550 m (1,800 ft.)
- Supports full-duplex and half-duplex modes with autonegotiation
[custom-specifications]
| Specifications | |
| Manufacturer | IC INTRACOM |
| Manufacturer Part Number | 508544 |
| Manufacturer Website Address | http://www.icintracom.com |
| Brand Name | Intellinet |
| Product Name | Gigabit Ethernet Media Converter |
| Product Type | Transceiver/Media Converter |
| Interfaces/Ports | |
| Total Number of Ports | 2 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Number of SC Ports | 1 |
| SC Port Type | Duplex |
| Media & Performance | |
| Media Type Supported | Twisted Pair,Optical Fiber |
| Fiber Mode Supported | Multi-mode |
| Fiber Optic Cable Wavelength | 850 nm |
| Maximum Distance Supported | 0.55 km (0.34 Mile) |
| Fiber Optic Cable Core/Cladding Specification | 62.5/125 µm,50/125 µm |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T,1000Base-SX,10Base-T,100Base-TX,1000Base-X,10/100/1000Base-TX |
| Power Description | |
| Power Source | Power Adapter |
| Plug/Connector Type | DC Jack |
| Physical Characteristics | |
| Form Factor | Compact,Desktop,Wall Mountable,Rack-mountable,Chassis Mount |
| Height | 2.76" (70 mm) |
| Width | 3.70" (94 mm) |
| Depth | 1.02" (26 mm) |
| Weight (Approximate) | 10.58 oz (300 g) |
| Miscellaneous | |
| Package Contents |
|
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | 3 Year |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
Additional-pdf1
Additional-pdf3
Additional-pdf2
[/custom-user-manual]
