Intellinet Gigabit Fiber SFP Optical Transceiver Module - For Data Networking, Optical Network - 1 x LC Duplex 1000Base-SX Network - - (508742)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Application/Usage: Data Networking,Optical Network
Features: Digital Diagnostics Monitoring Interface (DDMI),Digital Optical Monitoring (DOM)
Total Number of Ports: 1
Connector Type: LC Duplex
Interfaces/Ports Details: 1 x LC Duplex 1000Base-SX Network
Media Type Supported: Optical Fiber
Fiber Optic Cable Core/Cladding Specification: 50/125 µm,62.5/125 µm
Fiber Optic Cable Wavelength: 850 nm
Fiber Mode Supported: Multi-mode
Ethernet Technology: Gigabit Ethernet
Network Technology: 1000Base-SX
Maximum Distance Supported: 0.55 km (0.34 Mile)
Maximum Data Transfer Rate: 1 Gbit/s
Product Color: Silver
Product Material: Metal
Form Factor: Hot-pluggable
Height: 0.47" (12 mm)
Width: 0.55" (14 mm)
Length: 2.24" (57 mm)
Weight (Approximate): 0.71 oz (20 g)
Compatibility:
MSA Compliant
- With 1000Base-SX technology, enjoy up to 1000Mbps data transfer rate over optical fiber cable
- Gigabit Ethernet port for ultra-fast network speeds
- Optical fiber cable compatible - Spans afar and provides speedy data transmission rates between servers and network components
- Typically used for short distance, multi-mode fiber optic is ideal to carry data and transmit audio/video applications within a building
[custom-specifications]
| Specifications | |
| Manufacturer | IC INTRACOM |
| Manufacturer Part Number | 508742 |
| Manufacturer Website Address | http://www.icintracom.com |
| Brand Name | Intellinet |
| Product Name | Gigabit Fiber SFP Optical Transceiver Module |
| Product Type | SFP |
| Technical Information | |
| Application/Usage | Data Networking,Optical Network |
| Features | Digital Diagnostics Monitoring Interface (DDMI),Digital Optical Monitoring (DOM) |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | LC Duplex |
| Interfaces/Ports Details | 1 x LC Duplex 1000Base-SX Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Optic Cable Core/Cladding Specification | 50/125 µm,62.5/125 µm |
| Fiber Optic Cable Wavelength | 850 nm |
| Fiber Mode Supported | Multi-mode |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-SX |
| Maximum Distance Supported | 0.55 km (0.34 Mile) |
| Maximum Data Transfer Rate | 1 Gbit/s |
| Physical Characteristics | |
| Product Color | Silver |
| Product Material | Metal |
| Form Factor | Hot-pluggable |
| Height | 0.47" (12 mm) |
| Width | 0.55" (14 mm) |
| Length | 2.24" (57 mm) |
| Weight (Approximate) | 0.71 oz (20 g) |
| Miscellaneous | |
| Compatibility | MSA Compliant |
[/custom-specifications]
