Kantech KT-PTC1640UG Transformer - 40 VA - 110 V AC Input - 16 V AC Output - Plug-in Form Factor
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Product Overview
The Kantech KT-PTC1640UG transformer is a dedicated power conversion device engineered for access control, security, and low-voltage electrical applications. This transformer steps down standard 110 V AC line voltage to a safe 16 V AC output, providing the precise power requirements for door access controllers, electric locks, and other security hardware.
With a 40 VA power rating, this unit delivers sufficient capacity for typical single-door or small-scale installations while maintaining compact plug-in convenience. Manufactured by Johnson Controls under the Kantech brand, this transformer combines industrial-grade reliability with straightforward installation, making it a practical choice for integrators and facility managers.
Technical Overview
This transformer operates as a step-down device, converting 110 V AC input to 16 V AC output with a total power capacity of 40 volt-amps. The plug-in form factor eliminates the need for hardwiring, allowing for quick deployment and flexible placement near the connected equipment.
The design prioritizes electrical isolation and stable output voltage, ensuring consistent performance for sensitive security electronics. No active cooling or complex management interfaces are required, resulting in a maintenance-free operation suitable for continuous duty in commercial environments.
This section brings together practical product details such as Power Rating, Input Voltage, Output Voltage, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Key Product Advantages
The KT-PTC1640UG transformer offers several distinct benefits for security and low-voltage power applications. Its plug-in form factor simplifies installation compared to hardwired alternatives, reducing labor time and allowing for easier repositioning if system layouts change.
Voltage Compatibility
Accepts standard 110 V AC input common in North American commercial buildings, delivering a regulated 16 V AC output ideal for access control hardware.
- Matches typical line voltage
- Provides safe low-voltage output
Compact Power Delivery
The 40 VA rating supplies adequate power for single-door controllers or small security systems without oversized infrastructure.
- Sufficient for common applications
- Avoids unnecessary capacity overhead
Reliable Performance
Built to Johnson Controls' industrial standards, this transformer ensures consistent operation in continuous-use environments like office buildings, schools, and retail facilities.
- Industrial-grade components
- Designed for 24/7 operation
Deployment / Use Cases
This transformer is primarily deployed in access control and security system installations where low-voltage power conversion is required. It serves as the power supply for electric strikes, magnetic locks, and door controllers that operate on 16 V AC.
Typical installations include commercial office entryways, school security doors, retail store access points, and healthcare facility controlled entries. The plug-in design makes it particularly suitable for retrofit projects where minimizing electrical work is a priority, or in locations where a dedicated transformer can be placed discreetly near the controlled hardware.
Access Control Systems
Provides power to Kantech and compatible door access controllers, enabling secure entry management for single doors or small zones.
Security Hardware Support
Supplies consistent low-voltage power to electric locks, strikes, and other security devices that require 16 V AC operation.
Highlights
- 40 VA power rating for access control and security applications
- Converts 110 V AC input to 16 V AC output
- Plug-in form factor for easy installation without hardwiring
- Manufactured by Johnson Controls under the Kantech brand
- Ideal for powering door controllers, electric locks, and strikes
- Suitable for commercial, educational, and retail security systems
- Compact design with no active cooling required
- Maintenance-free operation for continuous duty environments
Specifications
| Specifications | |
|---|---|
| Manufacturer | Johnson Controls |
| Manufacturer Part Number | KT-PTC1640UG |
| Brand Name | Kantech |
| Product Name | Transformer |
| Product Type | Transformer |
| Technical Information | |
| Power Rating | 40 VA |
| Power Description | |
| Input Voltage | 110 V AC |
| Output Voltage | 16 V AC |
| Physical Characteristics | |
| Form Factor | Plug-in |
FAQ
What is the power rating of the Kantech KT-PTC1640UG transformer?
This transformer has a 40 VA (volt-amp) power rating, which indicates its total capacity for delivering power to connected low-voltage devices. This rating is sufficient for typical single-door access control systems or small security installations.
What input voltage does this transformer require?
The KT-PTC1640UG requires 110 V AC input, which is the standard line voltage in North American commercial and residential buildings. This makes it compatible with typical electrical outlets without requiring special voltage conversion equipment.
What output voltage does this transformer provide?
It delivers 16 V AC output, which is a common low-voltage requirement for many access control devices like electric strikes, magnetic locks, and door controllers. This stepped-down voltage provides safe operation for security hardware.
How is this transformer installed?
This transformer features a plug-in form factor, meaning it connects directly to a standard electrical outlet. The low-voltage output wires then connect to the security equipment, eliminating the need for hardwiring to electrical panels and simplifying installation compared to traditional transformers.
What types of systems is this transformer designed for?
It is designed primarily for access control and security systems, including door entry controllers, electric locks, strikes, and other hardware that operates on 16 V AC power. Common applications include commercial buildings, schools, retail stores, and healthcare facilities.
Does this transformer require any special maintenance?
No special maintenance is required. The transformer is designed for continuous duty operation with passive cooling and no moving parts, making it essentially maintenance-free once installed. Regular visual inspection of connections is recommended as part of overall system maintenance.
