Lantronix Managed Hardened Gigabit Ethernet PoE+ Switch - 8 Ports - Manageable - Gigabit Ethernet - 10/100/1000Base-T, 1000Base-X - 2 (SISPM1040-384-LRT-C)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Total Number of Network Ports: 8
Network (RJ-45): Yes
Uplink Port: No
Modular: Yes
Stack Port: No
Port/Expansion Slot Details: 8 x Gigabit Ethernet PoE+,4 x Gigabit Ethernet Expansion Slot
Media Type Supported: Twisted Pair,Optical Fiber
Ethernet Technology: Gigabit Ethernet
Network Technology: 10/100/1000Base-T,1000Base-X
Total Number of Expansion Slots: 4
Expansion Slot Type: SFP
Shared SFP Slot: No
Number of SFP Slots: 4
Layer Supported: 2
Networking Standards: IEEE 802.3,IEEE 802.3u,IEEE 802.3z,IEEE 802.3ab,IEEE 802.3x,IEEE 802.3ad,IEEE 802.1p,IEEE 802.1Q,IEEE 802.1w,IEEE 802.1s,IEEE 802.1x,IEEE 802.1ab,IEEE 802.1ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3ah,IEEE 802.3ag,IEEE 802.1D
Manageable: Yes
PoE (RJ-45) Port: Yes
PoE Budget: 240 W
Input Voltage: 57 V DC,44 V DC
Power Source: Power Supply,DC
Redundant Power Supply Supported: Yes
Power Consumption: 11.10 W
Product Color: Black
Form Factor: Desktop,Wall Mountable,DIN Rail Mountable
Height: 5.40" (137.16 mm)
Width: 2.40" (60.96 mm)
Depth: 5.30" (134.62 mm)
Weight (Approximate): 2.20 lb (997.90 g)
Country of Origin: Taiwan
TAA Compliant: Yes
Limited Warranty: 5 Year
- Expand your network capacity with the help of 8 networking ports and transfer your data quickly and easily
- Built-in power supply to ensure all components are being supplied with accurate voltage
- With leading Layer 2 support, experience enhanced convenience, secure business operations, and a borderless network experience
- The desktop installation makes it ideal for deployments outside the wiring closet
- Managed switch provides a reliable foundation for your network
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
[custom-specifications]
| Specifications | |
| Manufacturer | Lantronix, Inc |
| Manufacturer Part Number | SISPM1040-384-LRT-C |
| Manufacturer Website Address | http://www.lantronix.com |
| Brand Name | Lantronix |
| Product Model | SISPM1040-384-LRT-C |
| Product Name | Managed Hardened Gigabit Ethernet PoE+ Switch |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 8 |
| Network (RJ-45) | Yes |
| Uplink Port | No |
| Modular | Yes |
| Stack Port | No |
| Port/Expansion Slot Details | 8 x Gigabit Ethernet PoE+,4 x Gigabit Ethernet Expansion Slot |
| Media & Performance | |
| Media Type Supported | Twisted Pair,Optical Fiber |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T,1000Base-X |
| I/O Expansions | |
| Total Number of Expansion Slots | 4 |
| Expansion Slot Type | SFP |
| Shared SFP Slot | No |
| Number of SFP Slots | 4 |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3,IEEE 802.3u,IEEE 802.3z,IEEE 802.3ab,IEEE 802.3x,IEEE 802.3ad,IEEE 802.1p,IEEE 802.1Q,IEEE 802.1w,IEEE 802.1s,IEEE 802.1x,IEEE 802.1ab,IEEE 802.1ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3ah,IEEE 802.3ag,IEEE 802.1D |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 240 W |
| Input Voltage | 57 V DC,44 V DC |
| Power Source | Power Supply,DC |
| Redundant Power Supply Supported | Yes |
| Power Consumption | 11.10 W |
| Physical Characteristics | |
| Product Color | Black |
| Form Factor | Desktop,Wall Mountable,DIN Rail Mountable |
| Height | 5.40" (137.16 mm) |
| Width | 2.40" (60.96 mm) |
| Depth | 5.30" (134.62 mm) |
| Weight (Approximate) | 2.20 lb (997.90 g) |
| Miscellaneous | |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | 5 Year |
[/custom-specifications]
[custom-options]
| Product | Transition Networks Industrial DIN Rail Mounted Power Supply - DIN Rail Mountable - 48 V DC, 55 V DC Output - 240 W - 94% Efficiency |
| SKU | 25104 |
| Sale Price | $471.95 |
| Product | Lantronix Enclosure Door Contact Alarm - Wired - 60 V DC - Audible |
| SKU | EDCA-DIO-01 |
| Sale Price | $133.95 |
[/custom-options]
